ആമുഖം
The Logitech Rally Mic Pod Hub is designed to enhance microphone placement flexibility in conference room environments. It serves as an alternative to daisy-chaining multiple mic pods directly, offering three connections for various configurations of mic pods or additional hubs. This design facilitates cleaner cable management and optimized microphone positioning for meeting participants.
ബോക്സിൽ എന്താണുള്ളത്
- ലോജിടെക് റാലി മൈക്ക് പോഡ് ഹബ്
സജ്ജമാക്കുക
The Rally Mic Pod Hub allows for flexible microphone deployment. Follow these steps for installation:
- Positioning the Hub: Determine the optimal location for the Mic Pod Hub, typically under the conference table, to minimize visible cabling.
- Connecting Mic Pods: Connect up to three Rally Mic Pods or additional Mic Pod Hubs to the available ports on the main Mic Pod Hub. Use the provided cables to ensure secure connections.
- കേബിൾ മാനേജുമെന്റ്: Utilize under-table mounting hardware (if applicable) and grommets to route cables discreetly, maintaining a clean and organized conference table surface.
- സിസ്റ്റം ഇൻ്റഗ്രേഷൻ: Connect the Mic Pod Hub system to your Logitech Rally conference system according to the main system's instructions. The hub itself is USB powered and integrates with the Rally system via USB.
ചിത്രം: A user interacting with a Logitech Rally Mic Pod on a conference table. The Mic Pod Hub facilitates the connection of such mic pods, allowing for flexible placement and cable management.
പ്രവർത്തിക്കുന്നു
The Rally Mic Pod Hub itself is a passive connectivity device and does not require direct user operation. Its function is to facilitate the connection and communication of Rally Mic Pods with the main Rally system. Operation of the connected mic pods, such as muting, is performed directly on the mic pods themselves.
- Mic Pod Functionality: Each connected Rally Mic Pod features a mute button and indicator light. Press the button to mute or unmute the microphone.
- RightSound™ Technology: The Rally system, in conjunction with the mic pods, utilizes RightSound™ technology for automatic recalibration of the mic matrix, ensuring consistent echo cancellation, noise suppression, and beamforming performance.
മെയിൻ്റനൻസ്
The Logitech Rally Mic Pod Hub requires minimal maintenance. Adhere to the following guidelines:
- വൃത്തിയാക്കൽ: Use a soft, dry cloth to clean the exterior of the hub. Avoid abrasive cleaners or solvents.
- കേബിൾ സമഗ്രത: Periodically inspect all connected cables for any signs of wear or damage. Replace damaged cables immediately to ensure optimal performance.
- പരിസ്ഥിതി വ്യവസ്ഥകൾ: Ensure the hub is operated within recommended temperature and humidity ranges to prevent damage.
ട്രബിൾഷൂട്ടിംഗ്
If you encounter issues with your Rally Mic Pod Hub, consider the following troubleshooting steps:
- No Audio from Mic Pods:
- Verify all cables connecting the mic pods to the hub, and the hub to the Rally system, are securely seated.
- Ensure the mic pods are not muted (check the indicator light on the mic pod).
- Confirm the Rally system is properly configured and recognized the connected mic pods.
- ഇടയ്ക്കിടെയുള്ള ഓഡിയോ:
- അയഞ്ഞ കേബിൾ കണക്ഷനുകൾ പരിശോധിക്കുക.
- Ensure there are no sources of electromagnetic interference near the cables or hub.
- ഹബ് തിരിച്ചറിഞ്ഞിട്ടില്ല:
- Ensure the hub is correctly connected to the Rally system and receiving power (USB powered).
- Refer to the Logitech Rally system's manual for specific connectivity requirements and troubleshooting.
If problems persist, contact Logitech Support for further assistance.
സ്പെസിഫിക്കേഷനുകൾ
| ഫീച്ചർ | വിശദാംശങ്ങൾ |
|---|---|
| ബ്രാൻഡ് | ലോജിടെക് |
| മോഡലിൻ്റെ പേര് | റാലി മൈക്ക് പോഡ് ഹബ് |
| മോഡൽ നമ്പർ | 939-001647 |
| കണക്റ്റിവിറ്റി ടെക്നോളജി | Proprietary (for Mic Pods), USB (for system integration/power) |
| കണക്റ്റർ തരം | Proprietary for Mic Pods, USB for system |
| നിറം | കറുപ്പ് |
| ഇനത്തിൻ്റെ അളവുകൾ | 4 x 4 x 0.6 ഇഞ്ച് (10.16 x 10.16 x 1.52 സെ.മീ) |
| ഇനത്തിൻ്റെ ഭാരം | 240 ഗ്രാം (0.53 പൗണ്ട്) |
| എൻക്ലോഷർ മെറ്റീരിയൽ | ലോഹം |
| ശുപാർശ ചെയ്യുന്ന ഉപയോഗങ്ങൾ | Conference rooms, meeting rooms |
| വാറൻ്റി | 2-വർഷ പരിമിതമായ ഹാർഡ്വെയർ വാറൻ്റി |
വാറൻ്റി വിവരങ്ങൾ
This Logitech Rally Mic Pod Hub is covered by a 2-വർഷ പരിമിതമായ ഹാർഡ്വെയർ വാറൻ്റി. This warranty covers defects in materials and workmanship under normal use. For full terms and conditions, please refer to the official Logitech warranty documentation or visit the Logitech support webസൈറ്റ്.
പിന്തുണ
For technical assistance, product information, or warranty claims, please visit the official Logitech support webസൈറ്റ്:
നിങ്ങൾക്ക് സഹായകരമായ ഉറവിടങ്ങൾ, പതിവുചോദ്യങ്ങൾ, ഡ്രൈവർ ഡൗൺലോഡുകൾ എന്നിവയും അവരുടെ സൈറ്റിൽ കണ്ടെത്താനാകും. webസൈറ്റ്.
