PGST PA96 Pet-Immune Wireless PIR Motion Detector User Manual

1. ആമുഖം

This manual provides comprehensive instructions for the installation, operation, and maintenance of the PGST PA96 Pet-Immune Wireless PIR Motion Detector. This device is designed to enhance your home security system by detecting motion while minimizing false alarms caused by pets. It must be used in conjunction with a compatible PGST alarm control panel.

2 സുരക്ഷാ വിവരങ്ങൾ

• ഡിസ്അസംബ്ലിംഗ് ചെയ്യരുത്: Attempting to disassemble or modify the sensor may void the warranty and cause damage.
• ബാറ്ററി കൈകാര്യം ചെയ്യൽ: Use only specified battery types. Ensure correct polarity when inserting batteries. Dispose of used batteries responsibly according to local regulations.
• പാരിസ്ഥിതിക സാഹചര്യങ്ങൾ: Avoid installing the sensor in direct sunlight, near heat sources, or in areas with high humidity or extreme temperatures.
• ഇടപെടൽ: Keep the sensor away from strong electromagnetic fields or radio interference sources.

3. ഉൽപ്പന്നം കഴിഞ്ഞുview

The PGST PA96 is a wireless passive infrared (PIR) motion detector featuring pet immunity. It utilizes advanced signal processing to differentiate between human movement and smaller animals, reducing nuisance alarms.

പ്രധാന സവിശേഷതകൾ:

• Low power consumption CMOS microprocessor.
• Digital wireless signal transfer.
• കുറഞ്ഞ വോളിയംtagഇ അലേർട്ട് ഫംഗ്ഷൻ.
• ഓട്ടോമാറ്റിക് താപനില നഷ്ടപരിഹാരം.
• Intelligent logic analysis to prevent false alarms.
• Anti-white light and anti-high frequency interference.
• Pet-immune detection.

ചിത്രം 3.1: Visual representation of the PGST PA96 PIR sensor's features, including Anti-EMI, Anti False Alarm, Temperature Compensation, and Anti HF Interference.

ചിത്രം 3.2: Illustration highlighting the intelligent anti-pet function of the PGST PA96 sensor, designed to prevent false alarms from household pets.

ചിത്രം 3.3: വിവിധ views of the PGST PA96 Wireless PIR Detector, showcasing അതിന്റെ രൂപകൽപ്പനയും ഘടകങ്ങളും.

4 സ്പെസിഫിക്കേഷനുകൾ

5. സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും

5.1 അൺപാക്കിംഗ്

Carefully remove the PGST PA96 PIR Motion Detector from its packaging. Verify that all components are present.

5.2 ബാറ്ററി ഇൻസ്റ്റാളേഷൻ

1. സെൻസറിന്റെ പിൻഭാഗത്തുള്ള ബാറ്ററി കമ്പാർട്ട്മെന്റ് കവർ തുറക്കുക.
2. Insert two (2) AA alkaline batteries, ensuring correct polarity (+/-).
3. ബാറ്ററി കമ്പാർട്ട്മെൻ്റ് കവർ സുരക്ഷിതമായി അടയ്ക്കുക.

5.3 ഒരു ഇൻസ്റ്റലേഷൻ സ്ഥലം തിരഞ്ഞെടുക്കുന്നു

Select an installation location based on the desired coverage area and to optimize pet immunity. The recommended installation height is 2.2 meters (approximately 7.2 feet).

• ഒപ്റ്റിമൽ പ്ലേസ്മെൻ്റ്: For wide-angle infrared detection (three-dimensional expansion detection), install the sensor to cover the desired area, typically in a living room. The detection angle is approximately 110 degrees with a range of 12 meters.
• Vertical Curtain Detection: For specific vertical curtain infrared detection, the detection angle is about 15 degrees with a range of 8 meters. This is generally installed above a door or window.
• ഒഴിവാക്കുക: Direct sunlight, areas with rapid temperature changes (e.g., near air conditioners, heaters), and areas where large objects might obstruct the detection path.

ചിത്രം 5.1: Diagram illustrating recommended installation height and detection patterns for the PGST PA96 sensor, showing both wide-angle and vertical curtain detection.

5.4 സെൻസർ ഘടിപ്പിക്കുന്നു

1. Use the provided mounting bracket and screws to secure the sensor to the wall at the chosen height.
2. Ensure the sensor is firmly attached and positioned to cover the desired area without obstructions.

5.5 Pairing with Alarm Control Panel

The PGST PA96 sensor cannot operate independently. It must be paired with a compatible PGST alarm control panel (e.g., PG-505, 103, 105, 106, 107, 108). Refer to your alarm control panel's manual for specific instructions on how to add a new wireless sensor. Generally, this involves putting the control panel into 'learning' or 'pairing' mode and then triggering the PIR sensor (e.g., by walking in front of it) to transmit its signal.

6. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

Once successfully paired with your alarm control panel, the PGST PA96 sensor will function as part of your security system.

6.1 കണ്ടെത്തൽ

When the alarm system is armed, the PIR sensor will detect motion within its coverage area. Upon detection, it will transmit a signal to the control panel.

6.2 അലാറം അറിയിപ്പ്

Upon receiving a detection signal from the PA96 sensor, the control panel will trigger the alarm according to its programmed settings. This may include sounding a siren, sending notifications to your mobile phone via SMS or app, or dialing pre-set emergency numbers.

ചിത്രം 6.1: Diagram illustrating the working principle of the PGST PA96 sensor, showing how it detects motion and communicates with an alarm panel, which then sends notifications to users.

7. പരിപാലനം

7.1 ബാറ്ററി മാറ്റിസ്ഥാപിക്കൽ

The sensor features a low voltage alert function. When the batteries are low, the sensor will send a low battery signal to the control panel. Replace the two (2) AA alkaline batteries promptly to ensure continuous operation.

1. ബാറ്ററി കമ്പാർട്ട്മെൻ്റ് കവർ തുറക്കുക.
2. പഴയ ബാറ്ററികൾ നീക്കം ചെയ്യുക.
3. Insert new AA alkaline batteries, observing correct polarity.
4. ബാറ്ററി കമ്പാർട്ട്മെൻ്റ് കവർ അടയ്ക്കുക.

7.2 വൃത്തിയാക്കൽ

Clean the sensor's lens and casing periodically with a soft, dry cloth. Do not use abrasive cleaners or solvents, as these can damage the device.

8. പ്രശ്‌നപരിഹാരം

• Sensor not detecting motion:
  • ബാറ്ററി നില പരിശോധിച്ച് ആവശ്യമെങ്കിൽ മാറ്റിസ്ഥാപിക്കുക.
  • Ensure the sensor is correctly paired with the control panel.
  • Verify that the detection path is clear of obstructions.
  • Adjust the sensor's position or angle if the coverage area is insufficient.
• തെറ്റായ അലാറങ്ങൾ:
  • Ensure the sensor is installed at the recommended height (2.2m) for optimal pet immunity.
  • Check for sources of rapid temperature changes (e.g., heating vents, direct sunlight) near the sensor.
  • Verify that no curtains or light objects are moving within the detection zone.
  • Ensure the sensor is not exposed to strong electromagnetic or radio interference.
• കുറഞ്ഞ ബാറ്ററി മുന്നറിയിപ്പ്: Replace batteries as described in Section 7.1.

9. വാറൻ്റിയും പിന്തുണയും

For warranty information and technical support, please refer to the documentation provided with your PGST alarm control panel or visit the official PGST webവാറന്റി ക്ലെയിമുകൾക്കുള്ള വാങ്ങലിന്റെ തെളിവായി നിങ്ങളുടെ വാങ്ങൽ രസീത് സൂക്ഷിക്കുക.
