VSYSTO Q3pro Motorcycle Dash Camera User Manual

ആമുഖം

This manual provides detailed instructions for the installation, operation, and maintenance of your VSYSTO Q3pro Motorcycle Dash Camera. Please read this manual thoroughly before using the product to ensure proper function and safety. The VSYSTO Q3pro is a dual 2K camera system designed for motorcycles, featuring 5G WiFi for high-speed video download, tire pressure sensors, an OLED wired controller, and parking monitoring capabilities.

ബോക്സിൽ എന്താണുള്ളത്

• Host with bracket
• 2 Cameras (Front and Rear)
• ജിപിഎസ് മൊഡ്യൂൾ
• വയർഡ് കൺട്രോളർ
• Tire Pressure Sensors (2 units)
• ACC പവർ കേബിൾ
• USB കേബിൾ
• ക്യാമറ ബ്രാക്കറ്റുകൾ
• ഹോസ്റ്റ് ബ്രാക്കറ്റ്
• USB Test Cable (0.5m/1.6ft)
• TF Card Slot Screw
• കേബിൾ ബന്ധങ്ങൾ
• കേബിൾ ക്ലിപ്പുകൾ
• റെഞ്ച്

Note: The memory card is not included and needs to be purchased separately.

സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും

1. മെമ്മറി കാർഡ് ഇൻസ്റ്റാളേഷൻ

The memory card is essential for recording. Please purchase a compatible microSD card (up to 512GB, U3 or above recommended).

1. Open the cover of the main unit.
2. Insert the front of the memory card into the card slot.
3. Insert the provided screw and tighten it with the wrench to secure the cover.

2. Initial Connection and Testing

Before permanent installation, it is recommended to test all components.

1. Connect the cameras, GPS, wired controller, and USB test cable to their corresponding ports on the main unit.
2. Ensure all interfaces are tightened securely.
3. Use a 5V 2A charger or power bank with the USB test cable to power the system.
4. Verify that the system powers on and functions correctly. If it works properly, proceed with motorcycle installation.

3. Host Bracket Installation

The main unit (host) can be installed using its bracket.

1. Insert the small piece into the screw.
2. Align the bracket with the bracket hole on the host.
3. Insert the screw and tighten it with the wrench.
4. Use adhesive tape to stick the host in an appropriate position on the motorcycle (e.g., under the seat or in the trunk).

4. ക്യാമറ ബ്രാക്കറ്റ് ഇൻസ്റ്റാളേഷൻ

Install the cameras using the provided brackets. Ensure the arrow label on the camera faces upwards and the arc side faces forward.

1. Insert the small piece into the screw.
2. Install the bracket onto the camera.
3. Insert the base into the circular bracket.
4. Insert the screw and tighten it with a wrench.
5. Adjust the bracket angle as needed and tighten the screw.
6. Attach the camera with its bracket to the appropriate position on the motorcycle using adhesive tape or screws.

5. Wired Controller Bracket Installation

The wired controller can be installed using two methods:

1. രീതി 1: Fasten the Velcro to the upper and lower sides of the controller with screws.
2. രീതി 2: Select an appropriate gasket according to the handlebar condition, then fix the controller with screws.

6. ACC Power Cable Connection

The ACC power cable connects the dash camera system to your motorcycle's power supply. The red wire connects to the positive pole of the motorcycle battery, the black wire to the negative pole, and the yellow wire to the ACC line.

7. GPS Module Installation

Install the GPS module in an unobstructed place, keeping it about 30cm away from the camera to avoid signal interference.

ചിത്രം: GPS Information. This image illustrates the GPS module and its recommended placement for optimal signal reception.

8. Tire Pressure Sensors Installation

The tire pressure sensors monitor your motorcycle's tire pressure. Install them on the front and rear tires as indicated (F for front, R for rear) using the provided wrench and gaskets.

ചിത്രം: Mini Tire Pressure Sensors. This image displays the tire pressure sensors, gaskets, and wrench, along with common tire issues they help prevent.

പ്രവർത്തന നിർദ്ദേശങ്ങൾ

1. Wired Controller Operation

The OLED wired controller provides quick access to various functions and displays important information.

• മുകളിലേക്കുള്ള ബട്ടൺ: Short press to switch tire pressure units (Bar/Psi). Long press to enter/exit tire pressure threshold setting. Long press in main interface to reset WiFi password.
• ശരി ബട്ടൺ: Short press in main interface to switch between tire pressure, speed, longitude/latitude, and main interfaces. Short press in tire pressure interface to start pairing front tire pressure sensor.
• താഴേക്കുള്ള ബട്ടൺ: Short press to switch temperature units (°C/°F). Long press in tire pressure interface to enter tire pressure pairing interface. Long press after pairing is completed to exit.
• പി ബട്ടൺ: Short press to enter emergency recording mode. Long press in any interface to temporarily turn off motor vibration and tire pressure alarm sound.
• Red/Blue Indicator Light: Displays DVR recording status and GPS positioning status.

ചിത്രം: Multifunctional OLED Wired Controller. This image details the OLED display and button functions of the wired controller.

2. Parking Monitoring Function

When the motorcycle is powered off, the recorder detects vibration and automatically activates the parking monitoring function, recording for 30 seconds. The system will not start parking monitoring if the battery voltage is below 11.5V to prevent vehicle starting issues.

ചിത്രം: Parking Monitoring. This image explains the parking monitoring and low battery voltagഇ സംരക്ഷണ സവിശേഷതകൾ.

3. APP Operation (WiFi Camera)

The "WiFi Camera" mobile application (available on Google Play and APP Store) allows you to view real-time video, download, edit, and share recordings.

1. ഇതിനായി തിരയുക and install "WiFi Camera" on your smartphone.
2. Enter your phone's WiFi settings and connect to the network named starting with "MOTODV" or "VSYSTO".
3. Open the APP and click "Enter recorder" to view തത്സമയ ചിത്രം.
4. Click the icon in the upper right corner to switch between different camera views. Click the icon in the bottom right corner to display in full screen, and click again to exit.
5. Click "Online" to view files in the memory card (Normal, Event, Parking, Photo folders).
6. Click the "Edit" button in the upper right corner to delete or download video files. Download speed can reach up to 10.7M/s.
7. After downloading, go to the "Local" page to play videos.
8. When checking driving trajectory, connect to WiFi with internet access or turn on mobile data to view place names on the map. You can also view അത് പൂർണ്ണ സ്ക്രീനിൽ.
9. Click on a video to edit it (up to 30 seconds). Edited videos can be shared.
10. The settings page allows you to set loop video time, sound record, and other functions. After completing settings, restart the recorder for changes to take effect.

ചിത്രം: WiFi Connection. This image illustrates the 5G WiFi connection and app interface for video download and management.

4. Dual 2K Cameras

The system features well-made 120-degree wide-angle lenses with Starlight night vision. Dual 2K (2560*1440) 25FPS cameras provide clear video day and night. The MP4 video format ensures efficient compression and compatibility.

ചിത്രം: Dual 2K Cameras. This image highlights the dual camera setup, wide-angle view, and 2K resolution capabilities.

5. Loop Recording and Emergency Recording

Choose to record video at 1/2/3/5 minute intervals. When the SD card is full, new video will overwrite the oldest. The built-in G-sensor detects collisions and automatically records emergency locked video, protecting important footage.

ചിത്രം: Loop Recording and Emergency Recording. This image explains how loop recording manages storage and how the G-sensor triggers emergency recording.

മെയിൻ്റനൻസ്

• വൃത്തിയാക്കൽ: Use a soft, dry cloth to clean the camera lenses and main unit. Avoid abrasive cleaners or solvents.
• ഫേംവെയർ അപ്‌ഡേറ്റുകൾ: Periodically check the VSYSTO official website or the mobile app for firmware updates to ensure optimal performance and access to new features.
• മെമ്മറി കാർഡ്: Format the memory card regularly (e.g., once a month) through the app or device settings to maintain performance and prevent data corruption. Replace the memory card if it shows signs of degradation or errors.
• കേബിൾ കണക്ഷനുകൾ: Periodically check all cable connections to ensure they are secure and free from damage, especially after riding in harsh conditions.

ട്രബിൾഷൂട്ടിംഗ്

• ഉപകരണം പവർ ചെയ്യുന്നില്ല: Check all power connections, especially the ACC power cable to the battery and ACC line. Ensure the motorcycle battery has sufficient voltage.
• റെക്കോർഡിംഗ് ഇല്ല: Verify that a compatible memory card is inserted correctly and formatted. Check if loop recording is enabled.
• മോശം വീഡിയോ നിലവാരം: Ensure camera lenses are clean. Check for proper camera angle and mounting stability.
• വൈഫൈ കണക്ഷൻ പ്രശ്നങ്ങൾ: Ensure the dash camera's WiFi is enabled. Try resetting the WiFi password via the wired controller. Ensure your phone is within range.
• Tire Pressure Sensor Alarms: Check the tire pressure readings on the OLED controller. If an alarm sounds, inspect the tires for leaks or damage. Re-pair sensors if readings are inconsistent.
• Wired Controller Vibration/Alarm: This indicates an abnormal memory card or camera. Check connections and card status. Long press the P button to temporarily silence the alarm.

സ്പെസിഫിക്കേഷനുകൾ

വാറൻ്റിയും പിന്തുണയും

വാറൻ്റി

The VSYSTO Q3pro Motorcycle Dash Camera comes with a 1 വർഷത്തെ നിർമ്മാതാവിന്റെ വാറന്റി.

പിന്തുണ

For any questions, technical assistance, or warranty claims, please contact VSYSTO customer support:

• ഇമെയിൽ: support01@vsysto.com
• ഓൺലൈൻ പിന്തുണ: VSYSTO offers 24/7 support.

ചിത്രം: VSYSTO Support Information. This image highlights key support services including 24/7 support and contact email.
