HSM 390.3 HS BDL (L6) Cross-Cut Shredder User Manual

ആമുഖം

This manual provides essential information for the safe and efficient operation, setup, and maintenance of your HSM 390.3 HS BDL (L6) cross-cut shredder. Please read these instructions carefully before using the device and retain them for future reference.

The HSM 390.3 HS BDL (L6) is designed for shredding paper, CDs, and credit cards, providing high-security cross-cut destruction for sensitive documents and media.

സുരക്ഷാ നിർദ്ദേശങ്ങൾ

WARNING: Failure to follow these safety instructions may result in injury or damage to the shredder.

• Keep hands, loose clothing, jewelry, and long hair away from the paper entry slot.
• Do not insert metal objects such as paper clips, staples, or binders into the paper entry slot, unless explicitly stated by the manufacturer for specific models. This model is designed for paper, CDs, and credit cards.
• Unplug the shredder from the power outlet before moving, cleaning, or performing any maintenance.
• Do not allow children or pets near the shredder during operation.
• Operate the shredder only on a stable, level surface.
• Do not operate the shredder if the power cord is damaged or if the machine is malfunctioning.
• Ensure the waste bin is properly inserted before operation.
• Avoid overloading the shredder beyond its specified sheet capacity (12 sheets per pass for paper).

സജ്ജമാക്കുക

1. അൺപാക്ക് ചെയ്യുന്നു: Carefully remove the shredder from its packaging. Retain packaging materials for future transport or storage.
2. പ്ലേസ്മെൻ്റ്: Position the shredder on a stable, level surface near a grounded electrical outlet. Ensure adequate ventilation around the unit.
3. വേസ്റ്റ് ബിൻ ഇൻസ്റ്റാളേഷൻ: Ensure the 39-gallon waste bin is correctly seated within the shredder cabinet. The shredder will not operate if the bin is not properly closed or full.
4. പവർ കണക്ഷൻ: ഒരു സാധാരണ ഇലക്ട്രിക്കൽ ഔട്ട്ലെറ്റിലേക്ക് പവർ കോർഡ് പ്ലഗ് ചെയ്യുക.

Figure 1: A typical HSM cross-cut shredder, similar to the HSM 390.3 HS BDL (L6) model. This image shows the main unit with the paper entry slot and control panel visible on top, and a handle on the side for accessing the waste bin.

പ്രവർത്തന നിർദ്ദേശങ്ങൾ

പവർ ചെയ്യുന്നത് ഓൺ/ഓഫ്

• To turn on the shredder, locate the main power switch (usually on the back or side) and set it to the "ON" position.
• The shredder typically has a standby mode. To activate shredding, ensure the control panel is set to "AUTO".
• To turn off the shredder, set the main power switch to the "OFF" position.

ഷ്രെഡിംഗ് പേപ്പർ

1. Ensure the shredder is powered on and in "AUTO" mode.
2. Insert up to 12 sheets of paper (80 gsm) straight into the paper entry slot. The automatic start/stop feature will detect the paper and begin shredding.
3. Once the paper has passed through, the shredder will automatically stop.
4. Avoid feeding crumpled or folded paper, as this can reduce capacity and increase the risk of jams.

Shredding CDs and Credit Cards

• Locate the dedicated slot for CDs/credit cards (if separate from the paper slot).
• Insert one CD or credit card at a time into the designated slot. The shredder will automatically engage and destroy the media.
• Do not attempt to shred multiple CDs or credit cards simultaneously.

Automatic Start/Stop and Overload Protection

• The shredder features an automatic start/stop function, activating when paper is detected and stopping when shredding is complete.
• If too much paper is inserted, the overload protection system will activate, and the shredder may stop or reverse to prevent damage. Reduce the amount of paper and try again.

ചിത്രം 2: ക്ലോസപ്പ് view of the control panel on an HSM shredder. This panel typically includes indicators for power, waste bin full, and overload, along with buttons for auto, reverse, and forward operation.

മെയിൻ്റനൻസ്

വേസ്റ്റ് ബിൻ ശൂന്യമാക്കുന്നു

• When the waste bin is full, the shredder will typically indicate this and cease operation.
• പവർ ഔട്ട്‌ലെറ്റിൽ നിന്ന് ഷ്രെഡർ ഊരിമാറ്റുക.
• Carefully pull out the waste bin. Dispose of the shredded material.
• മാലിന്യ ബിൻ ശരിയായ സ്ഥാനത്ത് ക്ലിക്കായി വരുന്നത് വരെ സുരക്ഷിതമായി വീണ്ടും വയ്ക്കുക.

ഷ്രെഡറിൽ എണ്ണ തേയ്ക്കൽ

Regular oiling is crucial for maintaining the shredder's performance and extending its lifespan, especially for cross-cut models. Use only shredder oil specifically designed for paper shredders.

1. With the shredder in "AUTO" mode, apply a thin, continuous line of shredder oil across the entire paper entry slot.
2. Feed a few sheets of paper through the shredder to distribute the oil evenly across the cutting cylinders.
3. Repeat this process after every 30 minutes of continuous shredding or at least once a week for moderate use.

പുറംഭാഗം വൃത്തിയാക്കൽ

• വൃത്തിയാക്കുന്നതിന് മുമ്പ് ഷ്രെഡർ പ്ലഗ് ഊരിയിടുക.
• ഒരു മൃദുവായ, ഡി ഉപയോഗിച്ച് ബാഹ്യ പ്രതലങ്ങൾ തുടയ്ക്കുകamp തുണി. ഉരച്ചിലുകളുള്ള ക്ലീനറുകളോ ലായകങ്ങളോ ഉപയോഗിക്കരുത്.
• Ensure no liquids enter the shredder mechanism.

ട്രബിൾഷൂട്ടിംഗ്

സ്പെസിഫിക്കേഷനുകൾ

വാറൻ്റിയും പിന്തുണയും

For warranty information, technical support, or service inquiries, please refer to the official HSM website or contact your authorized HSM dealer. Keep your purchase receipt as proof of purchase for warranty claims.

You can typically find contact information and detailed warranty terms on the manufacturer's official webസൈറ്റ്: www.hsm.eu
