ഫൈൻഡർ 140182300000PAS മൾട്ടിഫംഗ്ഷൻ ടൈമർ/സ്റ്റെയർകേസ് റിലേ യൂസർ മാനുവൽ

1. ആമുഖം

This manual provides comprehensive instructions for the installation, operation, and maintenance of the Finder 140182300000PAS Multifunction Timer/Staircase Relay. Please read this manual carefully before installation and use to ensure proper function and safety.

2 സുരക്ഷാ വിവരങ്ങൾ

WARNING: Electrical shock hazard. Installation and maintenance should only be performed by qualified personnel in accordance with all local and national electrical codes.

• ഉപകരണം ഇൻസ്റ്റാൾ ചെയ്യുന്നതിനോ സർവീസ് ചെയ്യുന്നതിനോ മുമ്പ് എല്ലായ്പ്പോഴും പവർ വിച്ഛേദിക്കുക.
• Ensure the device is installed in a suitable enclosure to protect against environmental factors.
• Verify correct wiring connections to prevent damage to the device or connected equipment.
• നിർദ്ദിഷ്ട വോളിയം കവിയരുത്tagഇ, നിലവിലെ റേറ്റിംഗുകൾ.

3. ഉൽപ്പന്നം കഴിഞ്ഞുview

The Finder 140182300000PAS is a versatile multifunction timer and staircase relay designed for various electrical control applications. It features a 230V operating voltage, a 1 NO (normally open) contact, and a 16A current rating. Its compact design allows for easy integration into electrical panels.

ചിത്രം 1: ഫ്രണ്ട് view of the Finder 140182300000PAS Multifunction Timer/Staircase Relay. This image shows the device's casing, terminals, and the adjustable timer dial.

ചിത്രം 2: Example application of the Finder 140182300000PAS controlling staircase lighting. The relay is shown in an inset, demonstrating its use in a typical residential or commercial setting.

ചിത്രം 3: Another application example, showing the Finder 140182300000PAS managing lighting for a modern spiral staircase. This highlights the device's suitability for various architectural lighting designs.

4. സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും

4.1 ഭൗതിക അളവുകൾ

Refer to the dimensional drawing for precise measurements to ensure proper fit and mounting.

ചിത്രം 4: Dimensional drawing for the Type 14.01 relay, showing height, width, and depth in millimeters. This diagram is crucial for planning installation space.

4.2 വയറിംഗ് ഡയഗ്രമുകൾ

The Finder 140182300000PAS supports both 3-wire and 4-wire connection types. Select the appropriate diagram for your installation.

ചിത്രം 5: Wiring Diagram Type 14.01 for a 3-wire connection. This diagram illustrates how to connect the relay to the power supply and load using a 3-wire configuration, typically for staircase lighting with a common neutral.

ചിത്രം 6: Wiring Diagram Type 14.01 for a 4-wire connection. This diagram shows the connections for a 4-wire setup, which might be used in systems requiring separate control wires for the relay and the load.

5. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

5.1 Timer Adjustment

The device features an adjustable timer dial on its front face. To set the desired timing duration:

1. Locate the orange dial labeled 'T(min)' on the front of the relay.
2. Rotate the dial to align the indicator with the desired time setting (e.g., 5, 10, 15, 20 minutes).
3. The selected time will determine how long the connected load remains active after activation.

5.2 Multifunction Operation

The Finder 140182300000PAS operates as both a staircase timer and a multifunction relay. When activated (e.g., by a push-button switch), the relay will close its contact, powering the connected load for the duration set on the timer. It can be used for applications such as:

• Staircase lighting control.
• Timed ventilation systems.
• General purpose timed switching.

6. പരിപാലനം

The Finder 140182300000PAS is designed for long-term, maintenance-free operation. However, periodic checks are recommended:

• Ensure all wiring connections remain secure.
• ഉപകരണം പൊടിയിൽ നിന്നും അവശിഷ്ടങ്ങളിൽ നിന്നും മുക്തമാക്കുക.
• Inspect for any signs of physical damage or overheating.
• If the device is exposed to harsh environments, consider more frequent inspections.

WARNING: Always disconnect power before performing any maintenance or inspection.

7. പ്രശ്‌നപരിഹാരം

If the device is not functioning as expected, consider the following:

• No power to the load: Check the main power supply, circuit breaker, and all wiring connections. Ensure the device is receiving 230V.
• Timer not activating: Verify the input signal (e.g., from the push-button switch) is correctly connected and functioning.
• Incorrect timing duration: Re-check the setting on the 'T(min)' dial.
• ഉപകരണം അമിതമായി ചൂടാക്കൽ: Ensure the load current does not exceed 16A. Check for proper ventilation around the device.

If issues persist after checking these points, consult a qualified electrician or contact Finder customer support.

8 സ്പെസിഫിക്കേഷനുകൾ

8.1 സർട്ടിഫിക്കേഷനുകൾ

The product complies with various international standards.

ചിത്രം 7: Product certifications, including CE, UKCA, EAC, and Q-Mark, indicating compliance with European, UK, Eurasian, and quality standards respectively.

9. വാറൻ്റിയും പിന്തുണയും

വാറന്റി വിവരങ്ങൾക്കും സാങ്കേതിക പിന്തുണയ്ക്കും, ദയവായി ഔദ്യോഗിക ഫൈൻഡർ പരിശോധിക്കുക. webനിങ്ങളുടെ സൈറ്റിൽ ബന്ധപ്പെടുക അല്ലെങ്കിൽ നിങ്ങളുടെ പ്രാദേശിക വിതരണക്കാരനെ ബന്ധപ്പെടുക. വാങ്ങിയതിന്റെ തെളിവായി നിങ്ങളുടെ വാങ്ങൽ രസീത് സൂക്ഷിക്കുക.
