OSRAM LEDguardian SAVER LIGHT PLUS

1. ആമുഖവും അവസാനവുംview

The OSRAM LEDguardian SAVER LIGHT PLUS is a versatile, multi-functional LED lamp designed to provide essential assistance in various emergency situations. This compact and powerful device combines a bright flashlight, a work light, and a highly visible emergency warning light, along with critical safety tools like a window breaker and a seatbelt cutter. It is an indispensable tool for any vehicle, offering peace of mind on the road.

Its robust design and integrated magnetic points allow for easy attachment to metal surfaces, ensuring stability during use. The included special holder provides convenient in-car storage, making it readily accessible when needed.

2 സുരക്ഷാ വിവരങ്ങൾ

Please read all safety instructions carefully before using the OSRAM LEDguardian SAVER LIGHT PLUS. Failure to follow these instructions may result in injury or damage to the product.

• ബാറ്ററി സുരക്ഷ: Use only the specified battery type (2 x AA alkaline batteries). Do not mix old and new batteries, or different types of batteries. Remove batteries if the device will not be used for an extended period to prevent leakage.
• വിൻഡോ ബ്രേക്കർ: The window breaker is designed for emergency use only. Use it with caution and only when necessary to escape a vehicle. Aim for the corners or edges of the window for best results.
• Seatbelt Cutter: The seatbelt cutter is extremely sharp. Keep fingers and other body parts clear of the blade. Use only for cutting seatbelts in emergency situations.
• പ്രകാശ സ്രോതസ്സ്: Do not stare directly into the LED light. This can cause temporary vision impairment.
• സംഭരണം: ഉപകരണം തണുത്തതും വരണ്ടതുമായ സ്ഥലത്ത് സൂക്ഷിക്കുക, നേരിട്ടുള്ള സൂര്യപ്രകാശത്തിൽ നിന്നും തീവ്രമായ താപനിലയിൽ നിന്നും അകറ്റി നിർത്തുക.

3. സവിശേഷതകൾ

• മൾട്ടി-ഫങ്ഷണൽ ഡിസൈൻ: Combines a flashlight, work light, and emergency warning light.
• ശക്തമായ പ്രകാശം: Equipped with high-quality LEDs for bright white light (105 lumens).
• Emergency Warning Lights: Features 12 amber flashing LEDs for high visibility during roadside emergencies.
• Integrated Window Breaker: A hardened tip for breaking vehicle windows in critical situations.
• Seatbelt Cutter: A sharp, protected blade for quickly cutting seatbelts.
• കാന്തിക അറ്റാച്ച്മെൻ്റ്: Three strong magnets allow secure mounting to metal surfaces.
• ഒതുക്കമുള്ളതും മോടിയുള്ളതും: Designed for portability and resilience in emergency conditions.
• സൗകര്യപ്രദമായ സംഭരണം: Includes a special holder for easy mounting inside your vehicle.

4. പാക്കേജ് ഉള്ളടക്കം

പാക്കേജിൽ എല്ലാ ഇനങ്ങളും ഉണ്ടെന്ന് ഉറപ്പാക്കുക:

• 1 x OSRAM LEDguardian SAVER LIGHT PLUS Unit
• 1 x Special Holder for in-car mounting
• ഉപയോക്തൃ മാനുവൽ (ഈ പ്രമാണം)

കുറിപ്പ്: പ്രവർത്തനത്തിന് 2 x AA ബാറ്ററികൾ ആവശ്യമാണ്, അവ പാക്കേജിൽ ഉൾപ്പെടുത്തിയിട്ടില്ല.

5. സജ്ജീകരണം

5.1 ബാറ്ററി ഇൻസ്റ്റാളേഷൻ

1. Locate the battery compartment cap at the bottom of the LEDguardian SAVER LIGHT PLUS unit.
2. Twist or unscrew the cap counter-clockwise to open the compartment.
3. Insert 2 x AA alkaline batteries, ensuring the correct polarity (+/-) as indicated inside the compartment.
4. Replace the battery compartment cap by twisting or screwing it clockwise until securely closed.

5.2 Mounting the Special Holder

The special holder can be mounted inside your vehicle using either adhesive tape or Velcro (not included, but the description mentions it's supplied with the holder). Choose a location that is easily accessible in an emergency, such as the glove compartment, door panel, or under the seat.

1. Clean the desired mounting surface thoroughly to ensure good adhesion.
2. Apply strong double-sided adhesive tape or Velcro strips to the back of the holder.
3. Press the holder firmly onto the cleaned surface for at least 30 seconds.
4. Allow the adhesive to cure for a few hours before placing the LEDguardian SAVER LIGHT PLUS into the holder.

6. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

The OSRAM LEDguardian SAVER LIGHT PLUS features a single multi-function button for controlling its various modes.

6.1 Flashlight / Work Light Function

• Press the main button once to activate the front-facing white LED flashlight. This provides focused illumination.
• Press the button again to switch to the work light mode (if applicable, this might be the same as flashlight or a broader beam).
• Press the button a third time to turn off the white light.

6.2 Emergency Warning Light Function

• From the OFF state, press the main button twice quickly to activate the amber flashing warning LEDs. These LEDs are located along the side of the unit.
• To turn off the warning lights, press the button once.
• For maximum visibility, attach the unit to a metal surface of your vehicle (e.g., roof, trunk, or side panel) using the integrated magnets.

6.3 Window Breaker Function

• In an emergency where you need to exit the vehicle and the windows are jammed, locate the hardened tip of the window breaker on the device.
• Hold the device firmly and press the tip against a corner or edge of the side window.
• Apply firm, steady pressure until the glass shatters. Be prepared for the glass to break and clear any shards before exiting.

6.4 Seatbelt Cutter Function

• In an emergency where a seatbelt is jammed, locate the protected blade of the seatbelt cutter.
• Slide the seatbelt into the cutter's slot.
• Pull the device firmly across the seatbelt to cut it. Ensure no body parts are in the path of the blade.

7. പരിപാലനം

• വൃത്തിയാക്കൽ: സോഫ്റ്റ്, ഡി ഉപയോഗിച്ച് ഉപകരണം തുടയ്ക്കുകamp തുണി. ഉരച്ചിലുകളുള്ള ക്ലീനറുകളോ ലായകങ്ങളോ ഉപയോഗിക്കരുത്.
• ബാറ്ററി മാറ്റിസ്ഥാപിക്കൽ: Replace batteries when the light output diminishes or the device stops functioning. Always replace both batteries at the same time.
• സംഭരണം: Store the device in its holder in a dry, accessible location within your vehicle.

8. പ്രശ്‌നപരിഹാരം

9 സ്പെസിഫിക്കേഷനുകൾ

10. വാറൻ്റിയും പിന്തുണയും

10.1 വാറൻ്റി വിവരങ്ങൾ

The OSRAM LEDguardian SAVER LIGHT PLUS comes with a 2-year OSRAM warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use. It does not cover damage caused by misuse, accident, unauthorized modification, or normal wear and tear.

10.2 ഉപഭോക്തൃ പിന്തുണ

For technical assistance, warranty claims, or general inquiries, please contact OSRAM customer support through their official website or the retailer from whom you purchased the product. Please have your proof of purchase and product model number ready when contacting support.

You can visit the official OSRAM store for more information: OSRAM Official Store
