ഡോഗ്ട്ര 610C റീചാർജ് ചെയ്യാവുന്ന ഡോഗ് ട്രെയിനിംഗ് കോളർ യൂസർ മാനുവൽ

ആമുഖം

This manual provides comprehensive instructions for the Dogtra 610C rechargeable dog training collar. Designed for small to medium-sized dogs, the 610C features a compact receiver and a handheld transmitter with 100 levels of electrostatic stimulation and vibration. This device is intended solely for dog training purposes and must not be used on humans or other animals. Dogtra-Europe disclaims responsibility for improper use.

Image: The Dogtra 610C system, showing the handheld transmitter and the receiver collar.

ഉൽപ്പന്ന സവിശേഷതകൾ

• പരമാവധി ശ്രേണി: Up to 600 meters (approximately 650 yards).
• Stimulation Levels: 100 levels of electrostatic stimulation with seamless transitions.
• Stimulation Modes: Nick (Flash) and Constant stimulation.
• വൈബ്രേഷൻ മോഡ്: Pager (vibration only, no stimulation).
• റീചാർജ് ചെയ്യാവുന്ന ബാറ്ററികൾ: Equipped with rechargeable accumulators.
• LED സൂചകം: LED light indicates battery charge level.
• റിസീവർ ഭാരം: Collar-receiver weighs 115 grams.
• വാട്ടർപ്രൂഫ്: Both transmitter and collar-receiver are waterproof (IPX9K rated).
• കോം‌പാക്റ്റ് റിസീവർ: Suitable for small to medium-sized dogs (as small as 10 lbs).

Image: Graphic illustrating key features of the Dogtra 610C, including range, stimulation types, and dog size suitability.

പാക്കേജ് ഉള്ളടക്കം

The Dogtra 610C package includes the following components:

• ഹാൻഡ്‌ഹെൽഡ് ട്രാൻസ്മിറ്റർ
• Collar-Receiver
• 5 വി ബാറ്ററി ചാർജർ
• Splitter Cable (Double Plug)
• ഉപയോക്തൃ ഗൈഡ്

സജ്ജീകരണവും പ്രവർത്തനവും

1. ബാറ്ററികൾ ചാർജ് ചെയ്യുന്നു

Before first use, fully charge the lithium-polymer batteries in both the transmitter and receiver.

1. Connect the splitter cable to the 5V charger.
2. Plug one end of the splitter cable into the charging port of the transmitter and the other end into the charging port of the receiver.
3. ഒരു സാധാരണ മതിൽ ഔട്ട്ലെറ്റിലേക്ക് ചാർജർ പ്ലഗ് ചെയ്യുക.
4. The LED indicator on both units will glow red during charging and turn green when fully charged.
5. Charging typically takes approximately 2 hours.

2. Fitting the Receiver Collar

Proper fit of the receiver collar is crucial for effective and safe operation.

1. Ensure the dog is standing comfortably.
2. Place the receiver collar around your dog's neck so that the contact points are positioned underneath, making direct contact with the skin.
3. The collar should be snug enough that two fingers can barely fit under the strap, but not so tight as to restrict breathing or cause discomfort.
4. Trim any excess collar strap if necessary.

3. ട്രാൻസ്മിറ്റർ നിയന്ത്രണങ്ങൾ

Image: Labeled diagram of the Dogtra 610C handheld transmitter, highlighting its controls.

• Rheostat Intensity Dial: Located on top of the transmitter, this dial allows you to adjust the stimulation level from 0 (lowest) to 100 (highest). Turn clockwise to increase intensity, counter-clockwise to decrease.
• Nick Button: Delivers a single, rapid pulse of electrostatic stimulation.
• Constant Button: Delivers continuous electrostatic stimulation for up to 12 seconds, or until the button is released.
• Pager Button: Activates the vibration-only mode, providing a non-stimulating tactile sensation.

4. സിസ്റ്റം ഓപ്പറേറ്റിംഗ്

Ensure both the transmitter and receiver are powered on. The receiver typically turns on automatically when charged or by pressing a button (refer to specific instructions if not automatic).

• Selecting Stimulation Level: Use the Rheostat Intensity Dial to choose the appropriate level for your dog's temperament and training needs. Start at a low level and gradually increase until your dog responds.
• Applying Stimulation: Press the Nick, Constant, or Pager button as required for your training command.
• പരിധി: The system has a maximum range of 600 meters. Environmental factors and obstacles can affect actual range.

Image: Illustration of the Dogtra 610C's operational range, indicating up to 600 meters.

മെയിൻ്റനൻസ്

• വൃത്തിയാക്കൽ: Regularly clean the contact points on the receiver collar to ensure proper function and prevent skin irritation. Use a damp തുണിയും വീര്യം കുറഞ്ഞ സോപ്പും.
• ബാറ്ററി കെയർ: To prolong battery life, avoid fully discharging the batteries frequently. Recharge them when the LED indicator shows low battery. If storing for an extended period, charge the batteries to about 50% and recharge every few months.
• സംഭരണം: Store the unit in a cool, dry place away from extreme temperatures.

ട്രബിൾഷൂട്ടിംഗ്

If you encounter issues with your Dogtra 610C, refer to the following common troubleshooting steps:

• ശക്തിയില്ല: Ensure both the transmitter and receiver are fully charged. Check the charging connections.
• No Stimulation/Vibration:
  • Verify the receiver collar is properly fitted with contact points touching the dog's skin.
  • Increase the stimulation level using the Rheostat Intensity Dial.
  • Ensure both units are powered on and within range.
• കുറഞ്ഞ ശ്രേണി: Check for environmental interference (e.g., large metal objects, dense foliage). Ensure the transmitter antenna is not damaged.
• ചർമ്മ പ്രകോപനം: If your dog develops skin irritation, discontinue use immediately and consult a veterinarian. Ensure the collar is not worn for more than 8-10 hours per day and reposition it frequently.

സ്പെസിഫിക്കേഷനുകൾ

പ്രധാനപ്പെട്ട സുരക്ഷാ വിവരങ്ങൾ

The Dogtra 610C training collar is designed exclusively for dog training. It is not intended for use on humans or any other animals. Misuse of this product can lead to injury or harm. Dogtra-Europe assumes no responsibility for incorrect or improper use of the Dogtra training collar.

• Always use the lowest effective stimulation level.
• Do not leave the collar on your dog for more than 8-10 hours per day.
• Regularly check your dog's neck for signs of skin irritation or pressure sores.
• Never use the collar as a leash attachment point.
• കുട്ടികൾക്ക് ലഭ്യമാകാതെ സൂക്ഷിക്കുക.

Image: A dog wearing the Dogtra 610C collar, demonstrating proper fit.

വാറൻ്റിയും പിന്തുണയും

For detailed warranty information, product registration, or technical support, please visit the official Dogtra website or contact Dogtra customer service directly. Retain your proof of purchase for warranty claims.
