1. ആമുഖവും അവസാനവുംview
The Hozelock Multi-Jet Spray Gun Pro (Model 2694 0000) is designed for intensive watering and cleaning tasks. It features a durable construction, ergonomic design, and seven distinct spray patterns for versatile use in your garden. This manual provides essential information for the safe and effective operation, maintenance, and troubleshooting of your spray gun.
Figure 1: Hozelock Multi-Jet Spray Gun Pro, showing the multi-pattern nozzle and ergonomic handle.
2 സുരക്ഷാ വിവരങ്ങൾ
- Always ensure the water supply is turned off before connecting or disconnecting the spray gun from the hose.
- Do not aim the spray gun at people or animals, especially when using high-pressure spray patterns.
- സ്പ്രേ തോക്ക് കുട്ടികൾക്ക് ലഭ്യമാകാതെ സൂക്ഷിക്കുക.
- Store the spray gun in a dry, frost-free environment during winter months to prevent damage from freezing water.
- Do not attempt to modify the spray gun. Use only as intended.
3. പാക്കേജ് ഉള്ളടക്കം
Your Hozelock Multi-Jet Spray Gun Pro package includes:
- 1 x Hozelock Multi-Jet Spray Gun Pro
4. ഉൽപ്പന്ന സവിശേഷതകൾ
- നീണ്ടുനിൽക്കുന്ന നിർമ്മാണം: Features a stainless steel connection for enhanced longevity.
- എർഗണോമിക് ഡിസൈൻ: Soft-touch handle and trigger provide comfortable use, even during extended periods.
- ലോക്ക് ചെയ്യാവുന്ന ട്രിഗർ: The trigger can be locked in the 'on' position to reduce hand strain during continuous watering.
- ക്രമീകരിക്കാവുന്ന ഫ്ലോ നിയന്ത്രണം: A rear dial allows for precise adjustment of water flow from 50% to 100%.
- Seven Spray Patterns: Offers a variety of spray options for different gardening and cleaning tasks.
5. സജ്ജീകരണം
- Ensure your garden hose is equipped with a compatible quick-connect fitting.
- Align the quick-connect fitting on your hose with the stainless steel connector at the base of the spray gun.
- Push the hose fitting firmly onto the spray gun connector until it clicks securely into place.
- Gently pull on the spray gun to ensure the connection is secure before turning on the water supply.
Figure 2: Connecting the spray gun to a garden hose.
6. പ്രവർത്തന നിർദ്ദേശങ്ങൾ
6.1. Activating Water Flow
Once connected to a water supply, squeeze the trigger to activate water flow. The flow rate is directly controlled by how much you depress the trigger. Release the trigger to stop the water flow.
6.2. Locking the Trigger
For continuous watering without holding the trigger, push the red lever located above the trigger forward until it locks into position. To release the lock, simply push the red lever back.
6.3. Adjusting Water Flow
The rear flow control dial allows you to adjust the overall water output. Rotate the dial to increase or decrease the flow from 50% to 100% of the available water pressure.
Figure 3: Operating the spray gun for garden watering.
6.4. സ്പ്രേ പാറ്റേണുകൾ തിരഞ്ഞെടുക്കൽ
The Hozelock Multi-Jet Spray Gun Pro offers seven distinct spray patterns. To change the pattern, rotate the yellow nozzle head clockwise or counter-clockwise until the desired pattern aligns with the indicator.
Figure 4: Visual representation of the seven spray patterns.
The available spray patterns and their typical uses are:
- 1. Cone: അതിലോലമായ ചെടികൾക്കും പൂക്കൾക്കും നനയ്ക്കാൻ അനുയോജ്യമായ, സൗമ്യവും വീതിയുള്ളതുമായ സ്പ്രേ.
- 2. Jet: A powerful, concentrated stream suitable for cleaning stubborn dirt or reaching distant areas.
- 3. Mist: A fine, soft spray perfect for seedlings, young plants, or humidifying.
- 4. Fan: A wide, flat spray for rinsing surfaces or general watering of larger areas.
- 5. Shower: A soft, full spray for general watering of established plants and shrubs.
- 6. Aerated: A soft, bubbly flow providing gentle, aerated water for sensitive plants.
- 7. ഫ്ലാറ്റ്: A broad, flat spray designed for efficient coverage of larger areas.
7. പരിപാലനം
- ഡ്രെയിനിംഗ്: After each use, turn off the water supply and squeeze the trigger to drain any remaining water from the spray gun. This helps prevent mineral buildup and frost damage.
- നോസൽ വൃത്തിയാക്കൽ: Periodically inspect the nozzle head for debris or mineral deposits. If blockages occur, gently clean the small holes with a soft brush or a fine needle.
- സംഭരണം: During colder months, store the spray gun indoors in a dry, frost-free location. Exposure to freezing temperatures can cause internal components to crack or burst.
- ഓ-വളയങ്ങൾ: Over time, the internal O-rings may wear out, leading to leaks. While Hozelock does not typically sell replacement O-rings directly, compatible replacements may be found at hardware stores.
8. പ്രശ്നപരിഹാരം
| പ്രശ്നം | സാധ്യമായ കാരണം | പരിഹാരം |
|---|---|---|
| No water flow or weak flow |
|
|
| കണക്ഷനുകളിൽ നിന്ന് വെള്ളം ചോരുന്നു |
|
|
| Irregular or inconsistent spray pattern |
|
|
9 സ്പെസിഫിക്കേഷനുകൾ
- ബ്രാൻഡ്: ഹോസെലോക്ക്
- മോഡൽ നമ്പർ: 2694 0000
- മെറ്റീരിയൽ: Plastic (with stainless steel connection)
- അളവുകൾ (L x W x H): 6.3 x 3.94 x 3.15 ഇഞ്ച്
- ഇനത്തിൻ്റെ ഭാരം: 7 ഔൺസ്
- ഇൻലെറ്റ് കണക്ഷൻ തരം: ബാർബ്
- ഔട്ട്ലെറ്റ് കണക്ഷൻ തരം: ബാർബ്
- ഔട്ട്ലെറ്റ് കണക്ഷൻ വലുപ്പം: 0.5 ഇഞ്ച്
- തുറമുഖങ്ങളുടെ എണ്ണം: 2
- സ്പെസിഫിക്കേഷൻ മെറ്റ്: CE
10. വാറൻ്റിയും പിന്തുണയും
For detailed warranty information, product registration, or to contact customer support, please visit the official Hozelock website or consult your retailer. Keep your proof of purchase for any warranty claims.
