1. ആമുഖം
Thank you for choosing the Back Bay Audio American EQ 40 2-in-1 Wireless & Wired Bluetooth Earbuds. These earbuds offer versatile audio experiences, allowing you to switch between wireless Bluetooth and wired connections. Designed for active lifestyles, they feature sweatproof construction, multiple sound modes, and a built-in microphone for hands-free calls.
Image 1: Back Bay Audio American EQ 40 Earbuds, showcasinഅവരുടെ മിനുസമാർന്ന ഡിസൈൻ.
2. സജ്ജീകരണം
2.1 ഇയർബഡുകൾ ചാർജ് ചെയ്യുന്നു
Before first use, fully charge your earbuds. Connect the micro USB charging cable to the charging port on the inline control module and the other end to a USB power source. The LED indicator will show charging status.
2.2 Wireless Bluetooth Pairing
- ഇയർബഡുകൾ ഓഫാക്കിയിട്ടുണ്ടെന്ന് ഉറപ്പാക്കുക.
- Press and hold the middle button on the inline control module until the LED indicator flashes blue and red, indicating pairing mode.
- നിങ്ങളുടെ ഉപകരണത്തിൽ (സ്മാർട്ട്ഫോൺ, ടാബ്ലെറ്റ്, കമ്പ്യൂട്ടർ), ബ്ലൂടൂത്ത് പ്രവർത്തനക്ഷമമാക്കി ലഭ്യമായ ഉപകരണങ്ങൾക്കായി തിരയുക.
- Select "Back Bay American EQ 40" from the list.
- കണക്ട് ചെയ്തുകഴിഞ്ഞാൽ, LED ഇൻഡിക്കേറ്റർ ഇടയ്ക്കിടെ നീല നിറത്തിൽ മിന്നിമറയും.
2.3 വയർഡ് കണക്ഷൻ
To use the earbuds in wired mode, connect the provided AUX cable to the micro USB port on the inline control module and the 3.5mm jack to your audio device. Wired mode functions without battery power, making it ideal if your earbuds are uncharged or for devices without Bluetooth.
Image 2: Comparison of wireless and wired modes, highlighting battery life differences.
3. പ്രവർത്തന നിർദ്ദേശങ്ങൾ
3.1 Inline Control Module
The inline control module features three buttons for managing your audio and calls:
- മധ്യ ബട്ടൺ: Power On/Off (long press), Play/Pause (single press), Answer/End Call (single press), Activate Voice Assistant (long press), Switch EQ Mode (double press).
- വോളിയം കൂട്ടുക (+): Increase volume (single press), Next Track (long press).
- വോളിയം ഡൗൺ (-): Decrease volume (single press), Previous Track (long press).
3.2 EQ സൗണ്ട് മോഡുകൾ
The American EQ 40 earbuds offer 5 distinct sound modes. Double-press the middle button to cycle through them. You will hear a beep when the EQ changes. The earbuds start in Mode #1 when paired to a new phone. To reset to Mode #1, "forget" the earbuds in your phone's Bluetooth settings.
- 1. Back Bay Signature: The classic American Hi-fi sound. Strong bass, natural vocals, and crisp highs.
- 2. Atlanta Bass: ഏത് റാപ്പിനെയും EDM ട്രാക്കിനെയും അടുത്ത ലെവലിലേക്ക് കൊണ്ടുപോകുന്ന ബൂമിംഗ് ബാസ്.
- 3. Stadium Rock: Tighter and punchier, this setting captures that great 80's concert sound.
- 4. Pure Podcast: Loud and clear vocals with all the boomy and harsh noise stripped out.
- 5. Clean Classical: സമ്പന്നവും പൂർണ്ണവുമായ സ്വരത്തോടുകൂടിയ തുറന്നതും വായുസഞ്ചാരമുള്ളതുമായ വ്യക്തത.
Image 3: Visual representation of the 5 distinct EQ sound modes.
3.3 Hands-Free Phone Calls
The earbuds feature an in-line microphone with CVC noise cancellation for clear calls in wireless mode. Use the middle button to answer or end calls. The microphone only functions in wireless mode.
Image 4: User demonstrating wireless phone calls with the built-in microphone.
4. സുഖവും ഫിറ്റും
The American EQ 40 earbuds come with various accessories to ensure a secure and comfortable fit, especially during physical activity.
- Stabilizer "Wings": These removable wings fit into the outer ear to prevent the earbuds from falling out during vigorous movement.
- ചെവി ടിപ്പുകൾ: A selection of isolation tips (to block outside noise) and open ear tips (to stay aware of surroundings) are included to customize your listening experience and fit.
- Collar Clips: Use these clips to secure the cable to your clothing, preventing it from bouncing while you run or exercise.
- Cable Adjuster: Slide the adjuster to shorten the cable length for a more snug fit around your neck.
- Magnetic Clasp: The earbud housings feature magnetic clasps, allowing them to connect around your neck when not in use, preventing loss.
Image 5: Various running accessories including collar clips, cable adjuster, stabilizer wings, and ear tips.
Image 6: Close-up of the removable stabilizer and magnetic clasp features.
5. ഓഡിയോ നിലവാരം
The American EQ 40 earbuds are tuned in Boston, MA, to deliver a rich, balanced sound profile with strong bass, natural midrange, and crisp highs. They are powered by Qualcomm Apt-X technology for high-fidelity wireless audio.
Image 7: Earbud showcasing "Back Bay's Signature Sound" and "Apt-X Audio" branding.
The earbuds offer impressive volume levels, ensuring your music is clear even in noisy environments. While wireless mode provides excellent sound, the wired connection can offer a slightly cleaner audio experience by eliminating potential digital noise or distortion.
വീഡിയോ 1: ഒരു ഉദ്യോഗസ്ഥൻview of the Back Bay Audio Wired + Wireless Hybrid Earbuds, demonstrating their features and functionality.
6. പരിപാലനം
6.1 Sweatproof Design
The earbuds feature an IPX-5 water resistance rating, meaning they are completely unaffected by sweat or rain. An internal nano-coating protects the electronics, making them suitable for outdoor runs or intense gym workouts.
Image 8: An athlete using the sweatproof earbuds during a workout.
6.2 ബാറ്ററി ലൈഫ്
The earbuds provide approximately 6.5 hours of wireless playtime and up to 180 hours of standby time. In wired mode, playtime is unlimited as it does not draw battery power.
7. പ്രശ്നപരിഹാരം
- ശബ്ദ/കണക്ഷൻ പ്രശ്നങ്ങളില്ല: Ensure earbuds are charged and in pairing mode (flashing blue/red). Check your device's Bluetooth settings to ensure it's connected to "Back Bay American EQ 40." If using wired mode, ensure the AUX cable is securely connected to both the earbuds and your audio device.
- Unclear EQ Mode: The earbuds provide an audible beep when switching EQ modes, but no visual indicator. Familiarize yourself with the sound profiles to identify your current mode.
- മൈക്രോഫോൺ പ്രവർത്തിക്കുന്നില്ല: The in-line microphone only functions in wireless Bluetooth mode. Ensure your earbuds are wirelessly connected for hands-free calls.
- ഇയർബഡുകൾ വീഴുന്നു: Experiment with different sizes of ear tips and stabilizer wings provided to find the most secure and comfortable fit for your ears. Use the collar clips and cable adjuster for added stability during activity.
8 സ്പെസിഫിക്കേഷനുകൾ
| ഫീച്ചർ | സ്പെസിഫിക്കേഷൻ |
|---|---|
| മോഡലിൻ്റെ പേര് | Bluetooth Hearphone (American EQ 40) |
| കണക്റ്റിവിറ്റി ടെക്നോളജി | ബ്ലൂടൂത്ത്, വയർഡ് |
| വയർലെസ് കമ്മ്യൂണിക്കേഷൻ ടെക്നോളജി | ബ്ലൂടൂത്ത് 5.0 |
| ബ്ലൂടൂത്ത് ശ്രേണി | 10 മീറ്റർ |
| ഹെഡ്ഫോണുകൾ ജാക്ക് | 3.5 mm Jack (via AUX cable) |
| ബാറ്ററി ലൈഫ് (വയർലെസ്) | 6.5 Hours (Playtime) / 180 Hours (Standby) |
| ജല പ്രതിരോധ നില | IPX-5 (Sweatproof) |
| നിയന്ത്രണ തരം | Media Control (Buttons) |
| പ്രത്യേക സവിശേഷതകൾ | Microphone Included, Noise Cancellation (CVC), PC Calling, Stereo, Wind Noise Reduction, 5 EQ Sound Settings |
| ഇനത്തിൻ്റെ ഭാരം | 0.64 ഔൺസ് |
| ഉൽപ്പന്ന അളവുകൾ | 3.5 x 1.4 x 3.9 ഇഞ്ച് |
| യു.പി.സി | 822415648345 |
9. വാറണ്ടിയും പിന്തുണയും
ഈ ഉൽപ്പന്നം എ 1 വർഷത്തെ വാറൻ്റി. To receive your free 1-year warranty, please register your headphones at backbayaudio.com/warranty.
എന്തെങ്കിലും ചോദ്യങ്ങൾക്കോ പിന്തുണയ്ക്കോ, ദയവായി ഇമെയിൽ ചെയ്യുക support@backbayaudio.com.
