D'Addario 19UKE02

D'Addario NS Micro Headstock Tuner (Model 19UKE02) Instruction Manual

Brand: D'Addario | Model: 19UKE02

ആമുഖം

The D'Addario NS Micro Headstock Tuner offers discreet and accurate tuning for a variety of stringed instruments. Its compact design and versatile mounting options ensure it remains unobtrusive while providing clear, precise tuning feedback.

D'Addario NS Micro Headstock Tuner, front view

ചിത്രം: മുൻഭാഗം view of the D'Addario NS Micro Headstock Tuner, showing its compact size and control buttons.

ബോക്സിൽ എന്താണുള്ളത്

പ്രധാന സവിശേഷതകൾ

സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും

The NS Micro Headstock Tuner is designed for a secure, clip-free installation directly onto your instrument's tuning machine. This method ensures the tuner is always available and discreet.

മൗണ്ടിംഗ് നിർദ്ദേശങ്ങൾ:

  1. മൗണ്ടിംഗ് പോയിന്റ് തിരിച്ചറിയുക: Locate a suitable tuning machine screw hole on the back of your instrument's headstock. No additional holes are needed.
  2. Attach Clip-Free Mount: Align the tuner's clip-free mount with the chosen screw hole. Use the provided screw to securely fasten the mount to the headstock. Ensure it is tight enough to prevent movement but do not overtighten.
  3. Insert Tuner: Slide the tuner unit onto the mounted clip. The tuner is designed to fit snugly.
  4. ക്രമീകരിക്കുക Viewഇൻ ആംഗിൾ: The tuner body can rotate 360 degrees. Adjust its position for optimal visibility while playing.
D'Addario NS Micro Headstock Tuner mounted on a guitar headstock

Image: The D'Addario NS Micro Headstock Tuner securely mounted on the back of a guitar headstock, showing its discreet placement.

D'Addario NS Micro Headstock Tuner mounted on a bass guitar headstock

Image: The D'Addario NS Micro Headstock Tuner mounted on a bass guitar headstock, demonstrating its versatility across different instruments.

പ്രവർത്തന നിർദ്ദേശങ്ങൾ

പവർ ഓൺ/ഓഫ്:

Press and hold the power button (usually located on the front or top of the tuner) for a few seconds to turn the tuner on or off.

Tuning Your Instrument:

  1. Activate Tuner: Turn on the NS Micro Headstock Tuner.
  2. Pluck a String: Pluck a single string on your instrument. The tuner will detect the vibration and display the note.
  3. ഡിസ്പ്ലേ വായിക്കുക:
    • ചുവപ്പ്: The note is significantly out of tune.
    • മഞ്ഞ: The note is close to being in tune.
    • പച്ച: The note is perfectly in tune.
  4. പിച്ച് ക്രമീകരിക്കുക: Turn your instrument's tuning peg until the display shows a green light, indicating the string is in tune.
D'Addario NS Micro Headstock Tuner display showing a note in tune

Image: Close-up of the tuner's display showing a note in tune with green indicators.

Adjusting Calibration (Hz):

The tuner's calibration can be adjusted from 410Hz to 480Hz. Refer to your instrument's specific tuning requirements or personal preference for the correct Hz setting.

Changing Display Orientation:

The display can be rotated to accommodate different mounting positions and user preferences. Press the rotation button (circular arrow icon) to cycle through the available display orientations.

വീഡിയോ പ്രദർശനം:

Video: Official D'Addario NS Micro Universal Tuner demonstration, showing its features and how to use it.

മെയിൻ്റനൻസ്

ബാറ്ററി മാറ്റിസ്ഥാപിക്കൽ:

The NS Micro Headstock Tuner is powered by a CR2032 coin cell battery. When the display dims or the tuner becomes unresponsive, it's time to replace the battery.

  1. Carefully open the battery compartment, usually located on the back or side of the tuner.
  2. പഴയ CR2032 ബാറ്ററി നീക്കം ചെയ്യുക.
  3. പോസിറ്റീവ് (+) വശം മുകളിലേക്ക് അഭിമുഖീകരിക്കുന്ന ഒരു പുതിയ CR2032 ബാറ്ററി ഇടുക.
  4. ബാറ്ററി കമ്പാർട്ട്മെൻ്റ് സുരക്ഷിതമായി അടയ്ക്കുക.

വൃത്തിയാക്കൽ:

Wipe the tuner with a soft, dry cloth to remove dust or smudges. Do not use liquid cleaners or abrasive materials.

ട്രബിൾഷൂട്ടിംഗ്

സ്പെസിഫിക്കേഷനുകൾ

ഇനത്തിൻ്റെ ഭാരം1.13 ഔൺസ്
ഉൽപ്പന്ന അളവുകൾ3 x 1.13 x 4.63 ഇഞ്ച്
മോഡൽ നമ്പർ19UKE02
ബാറ്ററികൾ1 C battery required (CR2032 type)
ബോഡി മെറ്റീരിയൽറബ്ബർ
നിറംകറുപ്പ്
മെറ്റീരിയൽ തരംറബ്ബർ
ശ്രേണി ട്യൂണിംഗ്410-480Hz (Calibration)
പ്രദർശിപ്പിക്കുകTri-color backlit screen

വാറൻ്റിയും പിന്തുണയും

For warranty information, technical support, or to register your product, please visit the official D'Addario webസൈറ്റിൽ ബന്ധപ്പെടുക അല്ലെങ്കിൽ അവരുടെ ഉപഭോക്തൃ സേവനവുമായി ബന്ധപ്പെടുക. വാറന്റി ക്ലെയിമുകൾക്കായി നിങ്ങളുടെ വാങ്ങൽ രസീത് സൂക്ഷിക്കുക.
