WOBANE Under Counter Light Dimmable LED Under Cabinet Lighting Manual

ആമുഖം

Thank you for choosing the WOBANE Under Counter Light Dimmable LED Under Cabinet Lighting kit. This manual provides detailed instructions for the safe and efficient installation, operation, and maintenance of your new lighting system. Please read this manual thoroughly before use and retain it for future reference.

ഉൽപ്പന്നം കഴിഞ്ഞുview

The WOBANE Under Counter Light kit features 6 dimmable LED strip light bars, a remote control, and all necessary accessories for easy installation. Designed for various indoor applications, it provides bright, adjustable 6000K white light with timing functions.

ചിത്രം 1: Before and after installation of WOBANE under cabinet lights in a kitchen, showing enhanced illumination.

സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും

This LED lighting kit is designed for simple, tool-free installation. Follow these steps for optimal setup:

1. ഉപരിതലം തയ്യാറാക്കുക: Ensure the installation surface is clean, dry, and smooth. Wipe away any dust or grease.
2. പ്ലാൻ ലേഔട്ട്: Determine the desired layout for your LED strips. The kit includes 6 pre-cut strips, each 20 inches long, totaling 9.8 ft. You can connect them in various configurations:
   • Option 1 (One Line): Connect all strips in a single line for a total length of 9.8 ft.
   • Option 2 (Two Lines): Connect strips to form two parallel lines, each approximately 4.9 ft.
   • Option 3 (Three Lines): Connect strips to form three parallel lines, each approximately 3.3 ft.
3. Apply Strips: Peel off the adhesive backing from each LED strip and firmly press it onto the desired surface.
4. Use Connectors (Optional): For corners or to bridge gaps, use the included 'U' style or straight connectors. These flexible connectors allow for various configurations without cutting the strips.
5. സുരക്ഷിത കേബിളുകൾ: Use the provided cable holders to keep wiring tidy and secure.
6. Connect to Adapter: Connect the LED strips to the LED controller, then connect the controller to the 24W adapter.
7. പവർ ഓൺ: Plug the adapter into a standard 110V power outlet.

ചിത്രം 2: Visual guide for easy installation steps.

ചിത്രം 3: Various connection options for LED strip length customization.

ചിത്രം 4: Flexible connectors for custom layouts, including corners and combining strips.

പ്രവർത്തന നിർദ്ദേശങ്ങൾ

Your WOBANE LED Under Cabinet Lighting kit comes with an RF wireless remote control for convenient operation. The remote has a range of up to 60 feet and can control multiple kits.

വിദൂര നിയന്ത്രണ പ്രവർത്തനങ്ങൾ:

• ഓൺ/ഓഫ്: ലൈറ്റുകൾ ഓണാക്കാൻ 'ഓൺ' ബട്ടണും അവ ഓഫ് ചെയ്യാൻ 'ഓഫ്' ബട്ടണും അമർത്തുക.
• തെളിച്ച ക്രമീകരണം: Use the up/down arrow buttons to adjust the brightness. There are 10 adjustable levels and 4 pre-set brightness options (100%, 75%, 50%, 25%).
• ടൈമിംഗ് ഓഫ്: Set a timer for the lights to automatically turn off after 3, 5, 15, 30, or 60 minutes.
• ചലനാത്മക പ്രവർത്തനങ്ങൾ: The remote includes hot buttons for various dynamic lighting effects.
• Re-match Function: To pair multiple light kits to one remote, or to re-pair a remote: When the light strip is off, long press the button on the LED controller until the light flashes. Then, use the remote to turn it on/off. This will match the remote to the controller.

ചിത്രം 5: Features and functions of the RF wireless remote control.

ചിത്രം 6: Instructions for re-matching the remote control to the LED strips.

മെയിൻ്റനൻസ്

To ensure the longevity and optimal performance of your WOBANE LED Under Cabinet Lights, follow these simple maintenance guidelines:

• വൃത്തിയാക്കൽ: Disconnect the power before cleaning. Use a soft, dry cloth to gently wipe the LED strips and controller. Avoid using abrasive cleaners or solvents, as these can damage the product.
• പരിശോധന: Periodically check the adhesive for secure attachment. Reapply or reinforce if necessary. Inspect cables for any signs of wear or damage.
• സംഭരണം: If storing the lights for an extended period, ensure they are clean, dry, and stored in a cool, dry place away from direct sunlight.

ട്രബിൾഷൂട്ടിംഗ്

If you encounter any issues with your WOBANE LED Under Cabinet Lights, refer to the following common troubleshooting tips:

• ലൈറ്റുകൾ ഓണാക്കുന്നില്ല:
  • പവർ അഡാപ്റ്റർ ഒരു വർക്കിംഗ് ഔട്ട്ലെറ്റിൽ സുരക്ഷിതമായി പ്ലഗ് ചെയ്തിട്ടുണ്ടെന്ന് ഉറപ്പാക്കുക.
  • Check all connections between the LED strips, controller, and adapter.
  • Verify the remote control battery is functional and correctly inserted.
• റിമോട്ട് കൺട്രോൾ പ്രതികരിക്കുന്നില്ല:
  • Ensure there are no obstructions between the remote and the LED controller.
  • Replace the remote control battery if it is low.
  • Try the re-match function as described in the Operating Instructions to re-pair the remote with the controller.
• പൊരുത്തമില്ലാത്ത തെളിച്ചം:
  • Check for loose connections along the LED strips.
  • Ensure the power adapter is providing sufficient power (24W adapter can support up to 14PCS/22.96ft of WOBANE LED light bars).

If the problem persists after trying these steps, please contact WOBANE customer support for assistance.

സ്പെസിഫിക്കേഷനുകൾ

ചിത്രം 7: Detailed dimensions and components of the WOBANE LED lighting kit.

വാറൻ്റി വിവരങ്ങൾ

This WOBANE product comes with a പരിമിത വാറൻ്റി. For specific terms and conditions, please refer to the product packaging or contact WOBANE customer support.

ഉപഭോക്തൃ പിന്തുണ

For further assistance, technical support, or warranty inquiries, please visit the official WOBANE store or contact their customer service department.
