കിച്ചൺ എയ്ഡ് പ്രോഗ്രാം ചെയ്യാവുന്ന വയർഡ് പ്രോബ് തെർമോമീറ്റർ KQ906 ഉപയോക്തൃ മാനുവൽ

1. ആമുഖം

The KitchenAid Programmable Wired Probe Thermometer KQ906 is designed to assist in accurately monitoring food temperatures during cooking. This device features a wired probe for use in ovens or grills, a digital display, and programmable settings for various types of meat and desired doneness. It also includes a timer function for versatile kitchen use.

ചിത്രം 1.1: KitchenAid Programmable Wired Probe Thermometer KQ906. This image displays the main unit with its digital screen, the stainless steel probe, and the connecting silicone cord with a cord wrap.

2. പാക്കേജ് ഉള്ളടക്കം

പാക്കേജിൽ എല്ലാ ഘടകങ്ങളും ഉണ്ടെന്ന് ഉറപ്പാക്കുക:

• 1 x KitchenAid Programmable Wired Probe Thermometer (Main Unit)
• 1 x Stainless Steel Probe with Silicone Cord
• 1 x Silicone Cord Wrap
• ഉപയോക്തൃ മാനുവൽ (ഈ പ്രമാണം)

3. സജ്ജീകരണം

3.1 ബാറ്ററി ഇൻസ്റ്റാളേഷൻ

1. Locate the battery compartment on the back of the thermometer unit.
2. ബാറ്ററി കവർ തുറക്കുക.
3. Insert two AAA 1.5V batteries, ensuring correct polarity (+/-) as indicated inside the compartment.
4. ബാറ്ററി കവർ സുരക്ഷിതമായി അടയ്ക്കുക.

ചിത്രം 3.1: പിൻഭാഗം view of the thermometer showing the battery compartment. The image displays the open battery compartment with slots for two AAA batteries and the battery cover.

3.2 പ്രാരംഭ പവർ ഓൺ

After battery installation, the unit should power on automatically. If not, locate the power switch (often combined with COOK/TIMER/OFF selector) and slide it to the 'COOK' or 'TIMER' position.

3.3 പ്രോബ് കണക്ഷൻ

Insert the stainless steel probe's jack into the designated port on the side of the main thermometer unit. Ensure a firm connection.

ചിത്രം 3.2: കഴിഞ്ഞുview of the KitchenAid thermometer highlighting its features and dimensions. This image illustrates the thermometer's programmable nature, oven-proof silicone cord, magnetic back, and timer range, along with its physical dimensions and temperature range.

4. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

The thermometer offers two primary modes: തെർമോമീറ്റർ മോഡ് ഒപ്പം ടൈമർ മോഡ്. These modes function independently and cannot be used simultaneously. Programming one will disable the other.

4.1 Thermometer Mode (COOK)

1. Slide the switch on the back of the unit to the 'COOK' position.
2. Select Meat Type: Press the 'Meat' button to cycle through preset protein options: Beef, Pork, Fish, Veal, Lamb, Chicken, Turkey, Hamburger, and PGM (custom).
3. Select Doneness (Taste): After selecting a meat type, press the 'Taste' button to choose the desired doneness (e.g., Rare, Medium, Well). For 'PGM' (custom), you can manually set the target temperature.
4. അന്വേഷണം തിരുകുക: Carefully insert the stainless steel probe into the thickest part of the food, avoiding bone or gristle. Ensure the probe tip is fully embedded.
5. താപനില നിരീക്ഷിക്കുക: The display will show the current internal temperature of the food and the set target temperature.
6. അലാറം: An audible alarm will sound when the food reaches the preset target temperature.

ചിത്രം 4.1: The thermometer unit placed outside an oven, with its probe inserted into food cooking inside. This demonstrates how to monitor internal food temperature without opening the oven door.

ചിത്രം 4.2: A hand interacting with the thermometer's display buttons while the probe is inserted into food within an oven. This illustrates the process of setting or checking temperature parameters during cooking.

4.2 ടൈമർ മോഡ്

1. Slide the switch on the back of the unit to the 'TIMER' position.
2. സമയം സജ്ജമാക്കുക: Use the 'Min' and 'Sec' buttons to set the desired countdown time (up to 99 minutes, 59 seconds).
3. ആരംഭിക്കുക/നിർത്തുക: Press the Play/Pause button (often labeled with a triangle/two vertical bars icon) to start or pause the timer.
4. എണ്ണുക: The timer can also function as a count-up timer if not set for a countdown.
5. അലാറം: An alarm will sound when the countdown timer reaches zero.

5. Important Notes and Safety Precautions

• പ്രോബ് പ്ലേസ്മെൻ്റ്: Digital thermometers are designed for continuous monitoring during cooking. The probe can remain in the food inside the oven or grill.
• ചൂട് എക്സ്പോഷർ: The main thermometer unit (display) is അല്ല meant to be left inside the oven or grill. The plastic and electronic components can be damaged by excessive heat.
• Probe Temperature Limits: The wired probe should not be exposed to temperatures exceeding 482°F (250°C) or come into direct contact with flames.
• Handling Hot Probe: The probe will be hot after use. Always use oven mitts or potholders when handling the hot probe.
• Timer and Thermometer: Remember that the thermometer and timer functions are independent and cannot be used simultaneously. Activating one will disable the other.

6. പരിപാലനവും ശുചീകരണവും

6.1 ക്ലീനിംഗ് നിർദ്ദേശങ്ങൾ

• പ്രധാന യൂണിറ്റ്: Hand wash only. Do not immerse the main thermometer unit in water or place it in a dishwasher. For best results, wipe the unit with a damp തുണി നന്നായി ഉണക്കുക.
• അന്വേഷണം: The stainless steel probe can be cleaned with warm, soapy water. Rinse thoroughly and dry completely before storage.

6.2 സംഭരണം

Utilize the integrated silicone cord wrap to neatly store the probe's cord, preventing tangles and damage. Store the thermometer in a dry place away from extreme temperatures.

ചിത്രം 6.1: The KitchenAid thermometer displayed on a wooden cutting board, accompanied by garlic cloves and rosemary sprigs. This image showcases the product in a typical kitchen setting.

7. പ്രശ്‌നപരിഹാരം

If you encounter issues with your KitchenAid Programmable Wired Probe Thermometer, refer to the following common solutions:

• No Display/Unit Not Turning On:
  • ബാറ്ററി പോളാരിറ്റി പരിശോധിക്കുക.
  • ബാറ്ററികൾ പുതിയവ ഉപയോഗിച്ച് മാറ്റിസ്ഥാപിക്കുക.
  • Ensure the power switch is in the 'COOK' or 'TIMER' position.
• കൃത്യമല്ലാത്ത താപനില വായനകൾ:
  • Ensure the probe is fully inserted into the thickest part of the food, avoiding bone.
  • Verify the probe cord is securely connected to the main unit.
  • Check if the probe or cord has visible damage.
• അലാറം മുഴങ്ങുന്നില്ല:
  • Confirm the target temperature or timer duration is correctly set.
  • Ensure the unit is in the correct mode (COOK for temperature, TIMER for timer).
• Timer or Thermometer Not Working Simultaneously:
  • This is normal operation. The unit is designed to function in one mode at a time. Select either 'COOK' or 'TIMER' mode.

8 സ്പെസിഫിക്കേഷനുകൾ

9. വാറൻ്റിയും പിന്തുണയും

For warranty information, product support, or to inquire about replacement parts, please refer to the official KitchenAid website or contact KitchenAid customer service directly. Keep your purchase receipt as proof of purchase.

Webസൈറ്റ്: www.kitchenaid.com
