ആമുഖം
This manual provides detailed instructions for the installation, operation, and maintenance of the DIGITEN DFC15 Water Flow Control System. This system is designed for precise measurement and control of water flow, suitable for various applications requiring quantitative liquid dispensing.
പാക്കേജ് ഉള്ളടക്കം
The DIGITEN DFC15 Water Flow Control System package includes the following components:
- 1 x DFC15 Controller
- 1 x G3/4" Flow Sensor
- 1 x G3/4" Electric Solenoid Valve (Normally Closed)
- 1 x DC 12V പവർ അഡാപ്റ്റർ
- 1 x താപനില സെൻസർ
- 1 x ഉപയോക്തൃ മാനുവൽ
ഒരു ഓവർview of all components included in the DIGITEN Water Flow Control System kit, featuring the DFC15 controller, G3/4" flow sensor, G3/4" solenoid valve, power adapter, and temperature sensor.
സാങ്കേതിക സവിശേഷതകൾ
DFC15 Controller
- വൈദ്യുതി ആവശ്യകത: 12VDC
- പവർ അഡാപ്റ്റർ: Input: 100-240VAC; Output: 12VDC, max 2A
- Adapter Lead Length: 1m
- കൃത്യത അളക്കുന്നു: ±1%
- Output for Solenoid Valve: 12VDC, പരമാവധി 5A
- താപനില സെൻസർ: 0-125℃/32-257℉, NTC3950, Accuracy: ±1℃/±1℉, Thread: M8
- Max Total Volume: 999999 ജി/എൽ
- Quantitative Range: 0-9999.99 G/L
- ഫ്ലോ റേറ്റ് പരിധി: 0-9999.99 LPM (GPM)
- കേബിൾ നീളം: 1m
- അളവുകൾ: 88mm x 126mm x 30mm
- ഭാരം: 200 ഗ്രാം
- പ്രവർത്തന പരിസ്ഥിതി: Temperature: 0-50℃/32-122℉; Relative Humidity: <85%
G3/4" Flow Sensor
- ആവൃത്തി: F=5.5 * Q (L / Min)
- ഫ്ലോ റേഞ്ച്: 1-60L/മിനിറ്റ്
- Allowable Compression: Water pressure 1.75 Mpa below
- സെൻസർ തരം: ഹാൾ ഇഫക്റ്റ്
- കേബിൾ നീളം: 15 സെ.മീ
- പിശക്: ± 2%
G3/4" Solenoid Valve
- പ്രവർത്തന സമ്മർദ്ദം: 0.02-0.8Mpa
സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും
Proper installation is crucial for accurate operation. Follow these steps:
- ഘടക സ്ഥാനം: Properly install the flow sensor and solenoid valve in the water line. Ensure the flow sensor and solenoid valve direction aligns with the water flow direction. An arrow on the flow sensor indicates the correct flow path.
- വയറിംഗ്: Connect the flow sensor, solenoid valve, and temperature sensor to the DFC15 controller according to the wiring diagram. Connect the 12VDC power adapter to the controller.
- പ്രാരംഭ ക്രമീകരണങ്ങൾ: Before operation, set the K value, quantitative value, and maximum alarm value on the DFC15 controller. Refer to the operating instructions for details on setting these parameters.
- പാരിസ്ഥിതിക പരിഗണനകൾ: Avoid exposing the controller to water or excessive humidity to prevent damage.
A schematic diagram illustrating the wiring connections for the DIGITEN DFC15 controller, power adapter, solenoid valve, temperature sensor, and flow sensor, along with their placement in the water line.
An illustrative diagram showing a typical installation of the DIGITEN water flow control system, with the controller, solenoid valve, and flow sensor integrated into a water pipe.
The G3/4 inch water flow sensor, highlighting the arrow indicating the correct direction of water flow for proper installation.
പ്രവർത്തന നിർദ്ദേശങ്ങൾ
Once the system is installed and initial settings are configured, follow these steps for operation:
- പ്രവർത്തനം ആരംഭിക്കുക: അമർത്തുക ഓടുക/നിർത്തുക button to initiate the control process. The controller will begin displaying the current flow volume, current flow rate, and the faucet animation will start.
- Quantitative Control: The controller will automatically turn off the solenoid valve when the total flow reaches the pre-set quantitative value. At this point, the total value display will stop, the faucet animation will cease, and the flow rate will return to zero.
- Repeat Operation: To repeat the same job, press the ഓടുക/നിർത്തുക വീണ്ടും ബട്ടൺ.
The DIGITEN DFC15 LCD display controller, illustrating its dimensions and button layout for operation.
മെയിൻ്റനൻസ്
To ensure the longevity and proper functioning of your DIGITEN DFC15 Water Flow Control System, observe the following maintenance guidelines:
- Protect the Controller: Always avoid direct contact of the controller with water or other liquids. Ensure it is installed in a dry environment.
- പതിവ് പരിശോധന: Periodically check all connections for tightness and signs of wear.
- വൃത്തിയാക്കൽ: Clean the exterior of the controller with a soft, dry cloth. Do not use abrasive cleaners or solvents.
ട്രബിൾഷൂട്ടിംഗ്
If you encounter issues with your DIGITEN DFC15 Water Flow Control System, consider the following:
- Solenoid Valve Not Actuating: If you are using a solenoid valve that requires more than 2A, ensure you are using a suitable power adapter capable of supplying up to 5A. The included power adapter is rated for a maximum of 2A.
- Inaccurate Flow Readings: Verify that the flow sensor is installed correctly with the water flow direction matching the arrow on the sensor. Check for any blockages in the flow path.
- കൺട്രോളർ ഓണാക്കുന്നില്ല: Ensure the 12VDC power adapter is securely connected to both the controller and a functional power outlet.
വാറൻ്റി
The DIGITEN DFC15 Water Flow Control System comes with a 12 മാസ വാറൻ്റി വാങ്ങിയ തീയതി മുതൽ, നിർമ്മാണ വൈകല്യങ്ങൾ ഉൾക്കൊള്ളുന്നു. വാറന്റി ക്ലെയിമുകൾക്കായി നിങ്ങളുടെ വാങ്ങിയതിന്റെ തെളിവ് സൂക്ഷിക്കുക.
പിന്തുണ
For further assistance, technical support, or warranty inquiries regarding your DIGITEN DFC15 Water Flow Control System, please contact DIGITEN customer service through their official channels.
