Glideaway King Bed Heavy Duty Low Profile Center Supports Instruction Manual

1. ഉൽപ്പന്നം കഴിഞ്ഞുview

The Glideaway Heavy Duty Low Profile Center Support System (Model BB5K) is designed to provide robust and stable support for king-sized wooden bed frames. This system helps prevent sagging of mattresses and box springs, extending their lifespan and ensuring a comfortable sleep surface. It is specifically engineered for wooden bed frames that feature internal wooden lips.

Key features include 12 adjustable glide legs and 12 non-skid rubber grippers, ensuring comprehensive support and stability across the entire bed frame.

2. ഘടകങ്ങൾ

ഇൻസ്റ്റാളേഷൻ ആരംഭിക്കുന്നതിന് മുമ്പ്, എല്ലാ ഘടകങ്ങളും ഉണ്ടെന്ന് ഉറപ്പാക്കുക:

• Center Support Beams (metal rails)
• Adjustable Glide Legs (12 units)
• Non-Skid Rubber Grippers (12 units)
• മൗണ്ടിംഗ് ഹാർഡ്‌വെയർ (ബോൾട്ടുകൾ, നട്ടുകൾ, വാഷറുകൾ)

Refer to the diagram below for a visual representation of the system components.

This diagram provides an overhead view of the Glideaway King Bed Center Support System, illustrating the arrangement of the main support beams and the twelve adjustable legs.

3. ഇൻസ്റ്റാളേഷൻ ഗൈഡ്

Follow these steps to correctly install your Glideaway King Bed Center Support System:

1. കിടക്ക ഫ്രെയിം തയ്യാറാക്കുക: Ensure your king-sized wooden bed frame is assembled and stable. The support system is designed to fit frames with internal wooden lips.
2. Assemble the Center Support Beams: Connect the metal center support beams according to the provided hardware. Ensure all bolts are securely tightened.


ഒരു ക്ലോസപ്പ് view of a bolt securing two sections of the metal center support rail. Proper tightening of these bolts is crucial for the stability and strength of the support system.

3. Attach Adjustable Glide Legs: Screw the 12 adjustable glide legs into the designated attachment points on the center support beams. Do not fully tighten them yet.

എ വിശദമായി view of one of the adjustable support legs, showing its attachment point to the metal center support beam. The leg features a threaded shaft for height adjustment and a wide base for stability.
4. പിന്തുണാ സംവിധാനത്തിന്റെ സ്ഥാനം: Carefully place the assembled center support system within your bed frame. The ends of the support beams should rest on the internal wooden lips of your headboard and footboard.
5. കാലിൻ്റെ ഉയരം ക്രമീകരിക്കുക: Adjust the height of each glide leg by rotating it until it makes firm contact with the floor. Ensure the support system is level and provides even support across the bed frame. The low profile height from the floor can be adjusted between 5 and 8 inches.
6. Apply Non-Skid Grippers: Place the non-skid rubber grippers under each adjustable leg to prevent movement and protect your flooring.


This image illustrates a non-skid rubber gripper designed to be placed under the adjustable support legs. These grippers help prevent the bed from shifting and protect flooring.

7. അന്തിമ പരിശോധന: Verify that all connections are secure and all 12 legs are firmly supporting the bed frame.

This image shows the Glideaway King Bed Center Support System fully installed within a wooden bed frame. The metal support beams span the width of the bed, with multiple adjustable legs providing central support.

4. ഉപയോഗം

Once properly installed, the Glideaway Center Support System functions passively to provide continuous support. It is designed to distribute weight evenly, preventing the mattress and box spring from sagging. The heavy-duty construction allows it to support significant weight, up to 1100 pounds.

5. പരിപാലനം

To ensure the longevity and continued performance of your support system, consider the following maintenance tips:

• ആനുകാലിക പരിശോധന: Every 6-12 months, inspect all bolts and connections to ensure they remain tight. Re-tighten any loose hardware.
• ലെഗ് അഡ്ജസ്റ്റ്മെൻ്റ്: Periodically check that all adjustable legs are still making firm contact with the floor and are level. Adjust as necessary.
• Gripper Condition: Inspect the non-skid rubber grippers for wear or damage. Replace if they are no longer effective at preventing movement.
• വൃത്തിയാക്കൽ: Wipe down metal components with a dry cloth to remove dust. Avoid using harsh chemicals that could damage the finish.

6. പ്രശ്‌നപരിഹാരം

If you encounter issues with your Glideaway Center Support System, refer to these common problems and solutions:

• Bed Sagging:
  • കാരണം: Legs may not be properly adjusted or connections are loose.
  • പരിഹാരം: Re-adjust all 12 glide legs to ensure firm contact with the floor and verify that all bolts on the support beams are securely tightened.
• ഞരക്കം അല്ലെങ്കിൽ ശബ്ദം:
  • കാരണം: Loose connections or uneven leg contact with the floor.
  • പരിഹാരം: Check and tighten all hardware. Ensure each leg is evenly supporting the frame and is not wobbling.
• Bed Shifting:
  • കാരണം: Non-skid grippers are missing, worn, or improperly placed.
  • പരിഹാരം: Ensure all 12 non-skid rubber grippers are in place under each leg and are in good condition. Replace if necessary.

7 സ്പെസിഫിക്കേഷനുകൾ

8. വാറൻ്റി വിവരങ്ങൾ

For specific warranty details regarding your Glideaway Heavy Duty Low Profile Center Support System, please refer to the documentation included with your purchase or contact Glideaway directly. Warranty terms typically cover manufacturing defects and material flaws for a specified period.

9. പിന്തുണ

If you require further assistance, have questions about installation, or need to report an issue, please contact Glideaway customer support. You can find more information and contact details on the official Glideaway website or through their Amazon store.

Visit the official Glideaway Store: Glideaway Amazon Store
