Mobiclinic Electric Underblanket Instruction Manual

1. ആമുഖം

This manual provides essential information for the safe and effective use of your Mobiclinic Electric Underblanket. Please read all instructions carefully before first use and retain for future reference. This underblanket is designed to provide warmth and comfort for single beds.

2 സുരക്ഷാ വിവരങ്ങൾ

നിങ്ങളുടെ സുരക്ഷയാണ് പരമപ്രധാനം. ഇനിപ്പറയുന്ന മുന്നറിയിപ്പുകളും മുൻകരുതലുകളും പാലിക്കുക:

• അമിത ചൂടാക്കൽ സംരക്ഷണം: The electric underblanket is equipped with a safety system that automatically switches off after 3 hours of continuous use to prevent overheating.
• Always use the underblanket with bedding (sheets, duvet) covering it.
• Do not fold, crease, or bunch the underblanket excessively during use. Ensure it lies flat on the mattress.
• Do not insert pins or other sharp objects into the underblanket.
• Keep the control unit dry and away from water or moisture. Do not operate if the underblanket or control unit is wet.
• Do not use for very young children (0-3 years) or persons insensitive to heat.
• Regularly inspect the underblanket and power cord for any signs of wear or damage. If damaged, do not use and contact customer support.
• Unplug the underblanket from the mains when not in use or before cleaning.

This image visually reinforces the safety features of the Mobiclinic Electric Underblanket, showing a user sleeping while highlighting the automatic shut-off after 3 hours of use and the built-in overheat protection.

3. ഉൽപ്പന്ന സവിശേഷതകൾ

• അളവുകൾ: Designed for single beds, measuring 150 x 80 cm.
• കുറഞ്ഞ വൈദ്യുതി ഉപഭോഗം: Operates at 60W, comparable to or less than a standard light bulb.
• താപനില നിയന്ത്രണം: Features 3 adjustable temperature levels for personalized warmth.
• യാന്ത്രിക ഷട്ട്-ഓഫ്: Enhances safety by automatically turning off after 3 hours of continuous use.
• Detachable Control Unit: Allows for easy removal of the control for convenient cleaning.
• സുരക്ഷിത ഫിറ്റ്: Equipped with elastic bands to securely attach the underblanket to the mattress, preventing slipping.
• മെറ്റീരിയൽ: Made from soft and skin-friendly polyester fabric.

പ്രയോജനങ്ങൾ:

• Provides relief for muscle and joint discomfort.
• May contribute to improved blood circulation.
• Aids in enhancing overall sleep quality.
• Offers an energy-efficient way to stay warm.

This infographic details the various benefits of using the electric underblanket, such as relief for muscles and joints, improved blood circulation, enhanced sleep quality, and energy efficiency. A person is shown sleeping peacefully on the blanket.

4. സജ്ജീകരണം

1. അൺപാക്ക്: Carefully unpack the electric underblanket and its components. Ensure there is no visible damage.
2. സ്ഥാനനിർണ്ണയം: Place the underblanket directly on your mattress. Spread it out evenly, ensuring it lies completely flat without any folds, creases, or wrinkles.
3. മെത്തയിലേക്ക് സുരക്ഷിതമാക്കുക: Use the elastic bands located at the corners of the underblanket to secure it firmly to your mattress. This prevents the underblanket from shifting or slipping during use.
4. Add Bedding: Cover the electric underblanket with your regular bed sheets and any additional bedding (e.g., duvet, blankets).
5. കൺട്രോൾ യൂണിറ്റ് ബന്ധിപ്പിക്കുക: Attach the detachable control unit securely to the connection point on the underblanket.
6. പവർ കണക്ഷൻ: ഒരു സാധാരണ 230V ഇലക്ട്രിക്കൽ ഔട്ട്ലെറ്റിലേക്ക് പവർ കോർഡ് പ്ലഗ് ചെയ്യുക.

This image illustrates the underblanket's design for secure attachment to a mattress using elastic bands. It also emphasizes the maximum recommended usage time of 3 hours for safety and comfort.

5. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

The control unit allows you to easily manage the underblanket's functions.

• ഓണാക്കുന്നു: Press the 'On/Off' button on the control unit to activate the underblanket. The LED indicator will light up.
• താപനില ക്രമീകരിക്കൽ: Use the temperature selection buttons (typically marked 1, 2, 3) to choose your desired heat level. Level 1 provides gentle warmth, while Level 3 offers maximum heat.
• യാന്ത്രിക ഷട്ട്-ഓഫ്: For safety and energy efficiency, the underblanket will automatically turn off after 3 hours of continuous operation. If you wish to continue using it, you can simply turn it back on after a brief pause.
• ഓഫാക്കുന്നു: Press the 'On/Off' button again to switch off the underblanket. The LED indicator will turn off. Always unplug the underblanket from the mains when not in use for extended periods.

The image shows the detachable control unit for the Mobiclinic Electric Underblanket. It features an LED indicator, buttons for selecting one of three temperature levels, and highlights the automatic shut-off function after 3 hours.

6. പരിപാലനവും ശുചീകരണവും

Proper care ensures the longevity and hygiene of your electric underblanket.

1. തയ്യാറാക്കൽ: Always disconnect the underblanket from the power supply and detach the control unit before cleaning. Ensure the underblanket is completely cool.
2. മെഷീൻ വാഷിംഗ്: The electric underblanket is machine washable. Wash it at a maximum temperature of 30°C on a gentle cycle.
3. ഉണക്കൽ: Do not bleach, iron, or dry clean the underblanket. Allow it to air dry completely before re-using or storing. Do not tumble dry. Ensure no moisture remains in the heating elements or connections.
4. സംഭരണം: Store the underblanket in a cool, dry place, preferably in its original packaging or a protective bag. Avoid folding it tightly or placing heavy objects on it, which could damage the heating wires.

The image demonstrates the ease of cleaning the Mobiclinic Electric Underblanket, showing a woman putting it into a washing machine. It highlights the detachable power cord feature, which allows for machine washing at 30°C.

7. പ്രശ്‌നപരിഹാരം

എന്തെങ്കിലും പ്രശ്നങ്ങൾ നേരിടുകയാണെങ്കിൽ, താഴെപ്പറയുന്ന പൊതുവായ പ്രശ്നങ്ങളും പരിഹാരങ്ങളും പരിശോധിക്കുക:

• Underblanket does not heat:
  • പവർ കോർഡ് ഒരു പ്രവർത്തനക്ഷമമായ ഇലക്ട്രിക്കൽ ഔട്ട്ലെറ്റിൽ സുരക്ഷിതമായി പ്ലഗ് ചെയ്തിട്ടുണ്ടോ എന്ന് പരിശോധിക്കുക.
  • Ensure the detachable control unit is properly connected to the underblanket.
  • Verify that the 'On/Off' button is pressed and a temperature level is selected.
• Underblanket heats unevenly:
  • Ensure the underblanket is laid completely flat on the mattress without any folds or creases that could impede heat distribution.
• Underblanket switches off unexpectedly (before 3 hours):
  • This could indicate activation of an internal safety mechanism due to overheating or a fault. Unplug the unit, wait a few minutes, and then try turning it on again. If the issue persists, discontinue use and contact customer support.

8 സ്പെസിഫിക്കേഷനുകൾ

This image displays the Mobiclinic Electric Underblanket, highlighting its dimensions of 150 cm by 80 cm, a weight of approximately 1 kg, and key electrical specifications including 3 temperature settings, 55-60W power consumption, and 220-240V voltage. The control unit and power cord length are also visible.

9. വാറൻ്റിയും പിന്തുണയും

For detailed warranty information, product registration, or customer support, please visit the official Mobiclinic website or contact your retailer directly. Please retain your purchase receipt as proof of purchase for any warranty claims.
