1. ആമുഖം
Welcome to the instruction manual for your ORTUR Laser Master 2 Pro S2-lu2-2 Laser Engraver. This device is designed for precise engraving and cutting of various materials, offering advanced features and enhanced safety. Please read this manual thoroughly before operation to ensure safe and efficient use of your machine.
പ്രധാനപ്പെട്ട സുരക്ഷാ വിവരങ്ങൾ
This product contains a Class 4 laser. Direct exposure to the laser beam can cause severe eye damage and skin burns. Always wear the provided safety goggles during operation. Never look directly into the laser beam. Ensure proper ventilation and fire safety measures are in place. Keep children and pets away from the operating area.
Figure 1: The ORTUR Laser Master 2 Pro S2-lu2-2 laser engraver, showcasing its design and an example of a detailed engraving on wood.
2 പ്രധാന സവിശേഷതകൾ
The ORTUR Laser Master 2 Pro S2-lu2-2 is equipped with several advanced features to enhance your engraving and cutting experience:
- New Upgrade Pro Model 1600mW: Enhanced reliability, smoother engraving, faster speed, and higher accuracy for refined products.
- Overall Optimization: Optimized mechanical structure for longer service life and stable long-term operation.
- Advanced Motherboard: Features the latest OLM-PRO-V10 motherboard for smoother, more delicate engraving and higher precision.
- Upgraded Circuit System: 24V വോളിയംtage system for lower current and increased safety.
- Ortur Laser 1.8 Firmware: The most advanced laser engraving machine firmware, optimizing motion algorithms and increasing maximum stepper motor speed from 4000mm/min to 10000mm/min.
- Second-Generation FAC Laser Module (LU2-2): Features a smaller focal point of only 0.07*0.06mm, allowing for finer details and the ability to cut through 3mm plywood and 6mm pine board in a single pass.
- വലിയ കൊത്തുപണി പ്രദേശം: 400 x 400 mm working area.
- കരുത്തുറ്റ നിർമ്മാണം: അലുമിനിയം പ്രോfile frame and structured cabling ensure a solid structure and smooth operation.
- Synchronizing Shaft Mechanical Structure: Prevents out-of-sync issues on Y rails during high-speed engraving.
- പുതിയ നേത്ര സംരക്ഷണ ഡിസൈൻ: Laser protective cover filters out 98% UV light, reducing the need for additional goggles.
Enhanced Safety Protection System
- Flame Detector & Buzzer Alarm: Automatically stops and beeps if flame is detected.
- അടിയന്തരമായി നിർത്തുക: Dedicated switch for immediate shutdown in emergencies.
- സജീവ സ്ഥാന സംരക്ഷണം: Laser beam stops if unauthorized movement is detected via a G-sensor.
- ലേസർ ബീം സുരക്ഷാ ഗാർഡ്: Laser beam stops if computer system halts or USB cable disconnects.
- എക്സ്പോഷർ ദൈർഘ്യം കണ്ടെത്തലും പരിമിതിയും: Laser beam automatically stops after a period of inactivity to prevent fire.
- പവർ കൺട്രോൾ സിസ്റ്റം: Cuts power to the laser module if disconnected from power.
ചിത്രം 2: ഓവർview of the six integrated safety protection features.
Figure 3: A detailed breakdown of the safety mechanisms, illustrating how the machine responds to various unsafe conditions.
3. സജ്ജീകരണവും അസംബ്ലിയും
The ORTUR Laser Master 2 Pro S2-lu2-2 comes with pre-assembled parts, significantly simplifying the setup process. Most users can complete the assembly within 10-20 minutes.
അസംബ്ലി ഘട്ടങ്ങൾ (ജനറൽ ഓവർview):
- എല്ലാ ഘടകങ്ങളും അൺപാക്ക് ചെയ്ത് പാക്കിംഗ് ലിസ്റ്റുമായി താരതമ്യം ചെയ്യുക.
- Assemble the main frame components according to the included quick start guide.
- Mount the laser module onto the gantry.
- Connect all necessary cables (power, USB, motor cables).
- Ensure the machine is placed on a stable, level surface in a well-ventilated area.
For detailed, step-by-step assembly instructions, please refer to the official assembly guide provided with your product or visit the Ortur support website. It is crucial to follow these instructions precisely to ensure proper functionality and safety.
4. പ്രവർത്തന നിർദ്ദേശങ്ങൾ
The ORTUR Laser Master 2 Pro S2-lu2-2 is compatible with popular laser control software such as LaserGRBL and LightBurn, supporting Windows 7/8/XP/10/11 and Mac operating systems.
Figure 4: The engraver's compatibility with various operating systems and software.
Basic Operation Workflow:
- സോഫ്റ്റ്വെയർ ഇൻസ്റ്റാളേഷൻ: Install your preferred laser control software (LaserGRBL or LightBurn) on your computer.
- ഉപകരണം ബന്ധിപ്പിക്കുക: Connect the laser engraver to your computer via USB.
- മെറ്റീരിയൽ പ്ലേസ്മെൻ്റ്: Place the material to be engraved or cut onto the working area. Ensure it is flat and secured.
- ഫോക്കസ് അഡ്ജസ്റ്റ്മെന്റ്: Adjust the laser focus according to the material thickness. The LU2-2 module has a small focal spot for precision.
- ഡിസൈൻ തയ്യാറാക്കൽ: സോഫ്റ്റ്വെയറിനുള്ളിൽ നിങ്ങളുടെ ഡിസൈൻ ഇറക്കുമതി ചെയ്യുക അല്ലെങ്കിൽ സൃഷ്ടിക്കുക.
- പാരാമീറ്റർ ക്രമീകരണങ്ങൾ: Set appropriate power, speed, and pass settings based on the material type and desired outcome.
- കൊത്തുപണി/വെട്ടൽ ആരംഭിക്കുക: Initiate the process from the software. Monitor the operation closely.
The machine supports PWM mode for precise laser control. For optimal results, experiment with settings on scrap materials before working on your final piece.
Demonstration Video: Engraving on Wood
Video 1: This video demonstrates the ORTUR Laser Master 2 Pro S2-lu2-2 in action, engraving a design onto a piece of wood. It showcases the laser module's movement and the precision of the engraving process.
ചിത്രം 5: ഉദാamples of materials suitable for engraving and cutting with the device.
5. പരിപാലനം
Regular maintenance ensures the longevity and optimal performance of your ORTUR Laser Master 2 Pro S2-lu2-2. Always disconnect power before performing any maintenance.
- വൃത്തിയാക്കൽ: Regularly clean the machine's frame, rails, and laser lens to prevent dust and debris buildup. Use a soft, lint-free cloth.
- Laser Lens: Carefully clean the laser lens with a specialized lens cleaning solution and cloth to maintain engraving quality.
- ലൂബ്രിക്കേഷൻ: Periodically lubricate the moving parts, such as the guide rails, with appropriate lubricant to ensure smooth operation.
- കേബിൾ പരിശോധന: Check all cables for wear or damage and replace if necessary.
Proper maintenance helps prevent issues and ensures consistent, high-quality results from your engraver.
6. പ്രശ്നപരിഹാരം
നിങ്ങൾ നേരിട്ടേക്കാവുന്ന പൊതുവായ പ്രശ്നങ്ങളെ ഈ വിഭാഗം അഭിസംബോധന ചെയ്യുകയും പരിഹാരങ്ങൾ നൽകുകയും ചെയ്യുന്നു.
| പ്രശ്നം | സാധ്യമായ കാരണം | പരിഹാരം |
|---|---|---|
| Machine not turning on / No power. | Power cable disconnected, power supply issue. | Ensure power cable is securely connected. Check power outlet. Verify power supply unit is functioning. |
| ലേസർ വെടിവയ്ക്കുന്നില്ല അല്ലെങ്കിൽ ദുർബലമായ ഔട്ട്പുട്ട്. | Incorrect focus, low power setting, dirty lens, laser module issue. | Adjust laser focus. Increase power setting in software. Clean the laser lens. If problem persists, contact support. Note that the 1600mW laser is optimized for engraving and lighter cutting, not heavy-duty cutting. |
| Machine stops unexpectedly during operation. | Safety features activated (e.g., Active Position Protection, Flame Detector). | Check for unauthorized movement, flames, or computer/USB connection issues. Address the cause and restart the operation. |
| കൊത്തുപണിയുടെ ഗുണനിലവാരം മോശമാണ് അല്ലെങ്കിൽ പൊരുത്തമില്ലാത്തതാണ്. | Incorrect speed/power settings, material not flat, dirty lens, loose belts. | Adjust software settings. Ensure material is flat and secured. Clean laser lens. Check and tighten belts if loose. |
| ഡെലിവറി ചെയ്യുമ്പോൾ ഭാഗങ്ങൾ നഷ്ടപ്പെട്ടു. | പാക്കേജിംഗ് പിശക് അല്ലെങ്കിൽ ഗതാഗത കേടുപാടുകൾ. | Immediately contact Ortur customer support with your order details and a list of missing components. |
| Difficulty with software or no instructions. | Lack of familiarity with laser software, missing documentation. | Refer to the official Ortur website for comprehensive user manuals, software guides, and video tutorials. Many online communities also offer support for LaserGRBL and LightBurn. |
7 സാങ്കേതിക സവിശേഷതകൾ
| സ്പെസിഫിക്കേഷൻ | മൂല്യം |
|---|---|
| ബ്രാൻഡ് | ഓര്ട്ടൂര് |
| ഉൽപ്പന്ന അളവുകൾ | 19.69"D x 21.26"W x 6.3"H |
| Active Surface Area | 20.08 x 21.56 ഇഞ്ച് |
| ഓപ്പറേഷൻ മോഡ് | ഓട്ടോമാറ്റിക് |
| ഇനത്തിൻ്റെ ഭാരം | 10.6 പൗണ്ട് (10.58 പൗണ്ട്) |
| അച്ചടി മാധ്യമം | Card stock (and various other materials as shown in features) |
| നിർമ്മാതാവ് | ഓര്ട്ടൂര് |
| ലേസർ മൊഡ്യൂൾ | LU2-2 (1600mW) |
| Focal Spot Size | 0.07*0.06 മി.മീ |
| Max Motion Speed | 10000mm/min |
| ഫേംവെയർ | Ortur Laser 1.8 |
| മദർബോർഡ് | OLM-PRO-V10 |
8. വാറൻ്റിയും പിന്തുണയും
Ortur is committed to providing excellent customer service and support for your Laser Master 2 Pro S2-lu2-2.
ഉപഭോക്തൃ പിന്തുണ:
For any questions, technical assistance, or warranty inquiries, please contact Ortur customer support. They offer round-the-clock support through various channels:
ഇമെയിൽ
തത്സമയ ചാറ്റ്
ഫേസ്ബുക്ക്
You can also visit the official Ortur store for more information and resources: Ortur Official Store
