1. ആമുഖം
Thank you for choosing the Morecam Wireless Video Doorbell Camera with Chime. This device provides enhanced home security and convenience, allowing you to monitor your doorstep, communicate with visitors, and receive alerts directly on your smartphone. This manual will guide you through the setup, operation, and maintenance of your new doorbell camera.
Image 1.1: Morecam Wireless Video Doorbell Camera and Chime with smartphone view.
2. ഉൽപ്പന്നം കഴിഞ്ഞുview
2.1 പ്രധാന സവിശേഷതകൾ
- 1080P HD Video & 2K Resolution: Clear and detailed video monitoring.
- മനുഷ്യ കണ്ടെത്തൽ: Advanced PIR motion detection to minimize false alerts.
- രാത്രി കാഴ്ച: കുറഞ്ഞ വെളിച്ചത്തിൽ മെച്ചപ്പെട്ട ദൃശ്യപരത.
- 2-വേ ഓഡിയോ: Communicate directly with visitors from your smartphone.
- ബാറ്ററി പവർ: Long-lasting battery for wireless convenience.
- വയർലെസ് മണിനാദം: Receive indoor alerts when the doorbell is pressed.
- IP65 കാലാവസ്ഥാ പ്രതിരോധം: Durable design for outdoor use in various weather conditions.
- ഒന്നിലധികം സംഭരണ ഓപ്ഷനുകൾ: Supports cloud storage (with trial) and local Micro SD card (up to 128GB, not included).
2.2 പാക്കേജ് ഉള്ളടക്കം
- Morecam Wireless Video Doorbell Camera
- വയർലെസ് മണിനാദം
- മൌണ്ടിംഗ് ബ്രാക്കറ്റ്
- മൗണ്ടിംഗ് സ്ക്രൂകളും വാൾ ആങ്കറുകളും
- സുരക്ഷാ സ്ക്രൂഡ്രൈവർ
- യുഎസ്ബി ചാർജിംഗ് കേബിൾ
- ഉപയോക്തൃ മാനുവൽ
3. സജ്ജീകരണ ഗൈഡ്
Follow these steps for easy self-installation and initial setup of your Morecam doorbell camera.
- Charge the Doorbell Camera: Before installation, fully charge the doorbell camera using the provided USB cable. A full charge ensures optimal performance and battery life.
- Download the CloudEdge App: ഇതിനായി തിരയുക "CloudEdge" in your smartphone's app store (iOS or Android) and download the application. This app is essential for controlling and monitoring your doorbell camera.
- Connect to Wi-Fi and Scan QR Code: Open the CloudEdge app, create an account, and follow the in-app instructions to add your device. You will be prompted to connect the doorbell to your 2.4GHz Wi-Fi network and scan a QR code displayed on your phone with the doorbell camera.
- ഡോർബെൽ ഇൻസ്റ്റാൾ ചെയ്യുക: Secure the mounting bracket to your desired location using the provided screws and wall anchors. Then, attach the doorbell camera to the bracket and secure it with the special security screwdriver to prevent theft.
Image 3.1: Visual guide for the four-step self-installation process.
4. പ്രവർത്തന നിർദ്ദേശങ്ങൾ
4.1 തത്സമയം View ഒപ്പം ടു-വേ ഓഡിയോയും
Open the CloudEdge app to access the live video feed from your doorbell camera at any time. Use the microphone icon in the app to enable two-way audio, allowing you to speak with visitors at your door and hear their responses.
Image 4.1: Demonstrates the two-way audio feature, allowing communication with visitors.
4.2 മോഷൻ ഡിറ്റക്ഷനും അലേർട്ടുകളും
The doorbell camera features smart PIR human detection. When motion is detected, you will receive instant message alerts on your smartphone. You can adjust the sensitivity of the motion detection within the CloudEdge app settings to suit your environment.
Image 4.2: Illustrates the smart human detection feature and instant message alerts.
Image 4.3: Diagram showing the range and functionality of smart PIR motion detection.
4.3 നൈറ്റ് വിഷൻ
The doorbell camera is equipped with night vision capabilities, providing clear video footage even in complete darkness. This ensures continuous monitoring of your property 24/7.
4.4 Video Storage Options
Your Morecam doorbell camera offers two primary storage methods for recorded video:
- ക്ലൗഡ് സംഭരണം: A 7-day free trial is typically available. Cloud storage allows you to access recordings from anywhere with an internet connection.
- Local Micro SD Card: The device supports a Micro SD card up to 128GB (not included) for local storage of recordings. This provides a reliable backup and continuous recording without a subscription.
Image 4.4: Depicts the two available storage options: Cloud Storage and Micro SD card.
4.5 Video Quality Demonstration
The doorbell camera provides high-definition video quality, ensuring clear identification of visitors and events.
Video 4.5: A short demonstration of the J1 doorbell camera's video quality, showcasing clarity and detail.
Image 4.6: Comparison illustrating the superior clarity of 2K resolution over 1080P.
5. പരിപാലനം
5.1 ബാറ്ററി ചാർജിംഗ്
The doorbell camera is powered by a rechargeable battery. When the battery level is low, you will receive a notification via the CloudEdge app. Disconnect the doorbell from its mounting bracket and charge it using the provided USB cable. A full charge can last up to 120 days depending on usage and motion detection frequency.
Image 5.1: Highlights the long standby time and stable connection of the doorbell camera.
5.2 കാലാവസ്ഥാ പ്രതിരോധം
The Morecam doorbell camera is rated IP65 for weather resistance, meaning it is protected against dust and low-pressure water jets. While designed for outdoor use, avoid submerging the device in water or exposing it to extreme weather conditions for prolonged periods.
Image 5.2: Illustrates the IP65 weather resistance, showing protection against rain, snow, and dust.
5.3 വൃത്തിയാക്കൽ
To maintain optimal performance, periodically clean the camera lens and the doorbell surface with a soft, dry cloth. Do not use abrasive cleaners or solvents.
6. പ്രശ്നപരിഹാരം
- Doorbell not connecting to Wi-Fi:
- Ensure your Wi-Fi network is 2.4GHz. The doorbell does not support 5GHz networks.
- Check your Wi-Fi signal strength at the installation location. If weak, consider moving your router or using a Wi-Fi extender.
- Verify that you have entered the correct Wi-Fi password.
- Try resetting the doorbell camera and repeating the setup process in the CloudEdge app. - Poor video quality or grainy images:
- Ensure the camera lens is clean and free from dust or smudges.
- Check your Wi-Fi connection stability. A weak or unstable connection can affect video streaming quality.
- Verify that the camera is set to its highest resolution (2K) in the app settings. - Battery not holding charge or draining quickly:
- Ensure the doorbell is fully charged before initial use. Charging can take several hours.
- Frequent motion detections, live view access, and two-way audio usage can reduce battery life. Adjust motion detection sensitivity and recording duration in the app.
- Ensure the charging cable and adapter are functioning correctly. - No motion detection alerts:
- Check the motion detection settings in the CloudEdge app. Ensure it is enabled and sensitivity is set appropriately.
- Verify that app notifications are enabled on your smartphone.
- Ensure there are no obstructions blocking the camera's view or the PIR sensor. - മണിനാദം മുഴങ്ങുന്നില്ല:
- Ensure the chime is plugged into a power outlet and is within range of the doorbell camera.
- Check the chime's pairing status with the doorbell. Refer to the chime's specific instructions for re-pairing if necessary.
7 സ്പെസിഫിക്കേഷനുകൾ
| ഫീച്ചർ | വിശദാംശങ്ങൾ |
|---|---|
| മോഡൽ നമ്പർ | J1 |
| വീഡിയോ ക്യാപ്ചർ റെസല്യൂഷൻ | 1080p, 2K |
| കണക്റ്റിവിറ്റി ടെക്നോളജി | വയർലെസ് (വൈ-ഫൈ) |
| പവർ ഉറവിടം | ബാറ്ററി പവർ |
| ബാറ്ററി ശേഷി | 5000 മില്ലിampമണിക്കൂർ (mAh) |
| നൈറ്റ് വിഷൻ റേഞ്ച് | 32 അടി |
| പ്രത്യേക സവിശേഷതകൾ | 2-Way Audio, HD Resolution, Night Vision, Human Detection |
| ഇൻഡോർ/ഔട്ട്ഡോർ ഉപയോഗം | ഔട്ട്ഡോർ |
| അന്താരാഷ്ട്ര സംരക്ഷണ റേറ്റിംഗ് | IP65 |
| ഉൽപ്പന്ന അളവുകൾ | 2.2 x 1.4 x 5.3 ഇഞ്ച് |
| ഇനത്തിൻ്റെ ഭാരം | 15.5 ഔൺസ് |
8. വാറൻ്റിയും പിന്തുണയും
Morecam is committed to providing high-quality products and excellent customer service. For warranty information, technical assistance, or any product-related inquiries, please contact our professional technical support team. We aim for quick responses and solutions tailored to your needs.
- Professional Technical Team
- ദ്രുത പ്രതികരണം
- Support Tailored to Your Needs
Please refer to the product packaging or Morecam's official website for specific contact details and the most up-to-date warranty policy.
