ഉൽപ്പന്നം കഴിഞ്ഞുview
This manual provides essential information for the installation, operation, and maintenance of your Genuine OEM Toro 140-2350 Rear Drive Wheels. These wheels are designed for specific 22-inch Toro Recycler Lawn Mower models, ensuring optimal performance and durability.
Figure 1: A pair of Genuine OEM Toro 140-2350 Rear Drive Wheels, showing their robust design and tread pattern.
പ്രധാന സവിശേഷതകൾ:
- അനുയോജ്യത: Designed to fit most Toro Flex-Force Power System 60V MAX 22in Lawn Mowers, including models 21462, 21464, 21465, 21466, 21466T, 21468, 21472, 21771, 21772, 21773, 21774, and 21864.
- അളവുകൾ: Each wheel measures approximately 9.65 inches in diameter.
- നിർമ്മാണം: Made from solid plastic with hard molded rubber for durability.
- ഭാരം: Each wheel weighs approximately 1.5 lbs.
- ചവിട്ടുക: Features a skid-resistant tread pattern for improved traction.
സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും
Proper installation of the rear drive wheels is crucial for the safe and efficient operation of your lawn mower. Refer to your specific mower's service manual for detailed instructions on accessing the drive axle and removing old wheels.
ആവശ്യമായ ഉപകരണങ്ങൾ:
- Wrench or socket set (appropriate size for axle nuts)
- കയ്യുറകൾ (ശുപാർശ ചെയ്യുന്നത്)
- ക്ലീനിംഗ് തുണി
ഇൻസ്റ്റലേഷൻ ഘട്ടങ്ങൾ:
- പുതപ്പ് തയ്യാറാക്കുക: Ensure the lawn mower is turned off, the spark plug wire is disconnected (for gasoline models), or the battery is removed (for electric/battery models) to prevent accidental starting. Tilt the mower onto its side with the carburetor/battery side up to access the rear wheels.
- പഴയ ചക്രങ്ങൾ നീക്കം ചെയ്യുക: Locate the retaining nut or bolt securing the old wheel to the axle. Use the appropriate wrench or socket to loosen and remove it. Carefully slide the old wheel off the axle.
- പരിശോധിച്ച് വൃത്തിയാക്കുക: Before installing the new wheels, inspect the axle for any debris, rust, or damage. Clean the axle thoroughly with a cloth.
- പുതിയ വീലുകൾ ഇൻസ്റ്റാൾ ചെയ്യുക: Align the new Toro 140-2350 rear drive wheel with the axle. Ensure the geared side of the wheel (if applicable to your model's drive system) faces inward towards the mower body. Slide the wheel onto the axle until it is fully seated.
- ചക്രങ്ങൾ സുരക്ഷിതമാക്കുക: Reinstall the retaining nut or bolt onto the axle. Tighten it securely, but do not overtighten, as this can damage the wheel or axle. Ensure the wheel spins freely but has no excessive wobble.
- ടെസ്റ്റ് ഓപ്പറേഷൻ: Once both wheels are installed, return the mower to its upright position. Reconnect the spark plug wire or reinstall the battery. Briefly engage the self-propel mechanism (if applicable) to ensure the new wheels are functioning correctly and engaging with the drive system.
ചിത്രം 2: View of the internal gear mechanism on the Toro rear drive wheel, which engages with the mower's drive system.
ചിത്രം 3: വശം view of the wheel, highlighting the robust tread designed for skid resistance.
പ്രവർത്തന പരിഗണനകൾ
While these wheels are designed for durability, proper operating practices contribute to their longevity and the overall performance of your lawn mower.
- ഭൂപ്രദേശം: Avoid operating the mower on excessively rough or rocky terrain that could cause undue stress or damage to the wheels.
- തടസ്സങ്ങൾ: Be mindful of obstacles such as tree roots, large stones, or debris that could impact the wheels.
- സംഭരണം: When storing the mower for extended periods, ensure it is on a flat, stable surface to prevent uneven pressure on the wheels.
മെയിൻ്റനൻസ്
Regular inspection and basic maintenance will help extend the life of your Toro rear drive wheels.
- വൃത്തിയാക്കൽ: After each use, remove grass clippings, dirt, and debris from the wheels and around the axle area. A stiff brush and water can be used, but avoid high-pressure washing directly on bearings or seals.
- പരിശോധന: Periodically inspect the wheel tread for excessive wear or damage. Check for cracks in the plastic or rubber components. Ensure the wheels are securely fastened to the axle and that there is no excessive play.
- ലൂബ്രിക്കേഷൻ: While these wheels are generally maintenance-free, if your mower's axle system requires lubrication, follow your mower's specific manual for appropriate lubrication points and types. Avoid lubricating the wheel's tread.
ട്രബിൾഷൂട്ടിംഗ്
This section addresses common issues related to the rear drive wheels.
| പ്രശ്നം | സാധ്യമായ കാരണം | പരിഹാരം |
|---|---|---|
| Wheel Wobbles or is Loose | Loose retaining nut/bolt; Worn axle or wheel hub. | Tighten the retaining nut/bolt. If wobble persists, inspect the axle and wheel hub for wear and replace components as necessary. |
| Poor Traction | Worn tread; Excessive grass/mud buildup on tread. | Clean the wheel tread thoroughly. If tread is significantly worn, consider replacing the wheels. |
| Unusual Noise from Wheel | Debris caught in wheel mechanism; Worn internal gears (if applicable); Damaged wheel. | Inspect and remove any debris. If noise persists, the wheel or drive system components may be damaged and require replacement or professional service. |
| Self-Propel Not Engaging (Rear Wheels) | Incorrect installation of geared wheel; Issue with mower's drive belt or transmission. | Ensure the geared side of the wheel is correctly oriented and fully seated. Check your mower's manual for troubleshooting the self-propel system. |
സ്പെസിഫിക്കേഷനുകൾ
| ആട്രിബ്യൂട്ട് | വിശദാംശങ്ങൾ |
|---|---|
| ഭാഗം നമ്പർ | 140-2350 |
| ബ്രാൻഡ് | ടോറോ |
| വീൽ വ്യാസം | 9.65 ഇഞ്ച് |
| Wheel Size (Mower Compatibility) | 22 Inches (for compatible mower models) |
| മെറ്റീരിയൽ | Solid plastic and hard molded rubber |
| നിറം | കറുപ്പ് |
| Weight (Each Wheel) | ഏകദേശം 1.5 പൗണ്ട് |
| മാതൃരാജ്യം | യുഎസ്എ |
| Compatible Mower Models | 21462, 21464, 21465, 21466, 21466T, 21468, 21472, 21771, 21772, 21773, 21774, 21864 |
വാറൻ്റിയും പിന്തുണയും
As Genuine OEM parts, these Toro rear drive wheels are manufactured to high standards. For specific warranty information regarding this product, please refer to the original purchase documentation or contact Toro customer support directly. General Lawn is the seller for this product.
For further assistance or to inquire about other genuine Toro parts, please visit the official Toro webസൈറ്റ് ചെയ്യുകയോ അവരുടെ ഉപഭോക്തൃ സേവന വിഭാഗവുമായി ബന്ധപ്പെടുകയോ ചെയ്യുക. നിങ്ങൾക്ക് റഫർ ചെയ്യാനും കഴിയും Toro Store on Amazon.
