1. ആമുഖം
This user manual provides detailed instructions for the safe and effective use of your DOGlinsen Dog Training Collar. This system is designed to assist in training dogs through various modes, promoting better behavior and communication between you and your pet. Please read this manual thoroughly before operating the device.
2 സുരക്ഷാ വിവരങ്ങൾ
The safety and well-being of your dog are paramount. Adhere to the following guidelines:
- പ്രായ ആവശ്യകത: This training collar is suitable for dogs at least 6 months old.
- Wearing Duration: Do not leave the collar on your dog for more than 6 hours per day to prevent skin irritation.
- ശരിയായ ഫിറ്റ്: Ensure the collar is snug but not too tight. You should be able to fit one finger comfortably between the collar and your dog's neck.
- ബന്ധപ്പെടാനുള്ള പോയിൻ്റുകൾ: Always use the silicone protective caps on the contact points to make them softer and reduce the risk of irritation. Regularly check your dog's neck for any signs of redness or sores. If irritation occurs, discontinue use immediately and consult a veterinarian.
- മേൽനോട്ടത്തിലുള്ള ഉപയോഗം: Always supervise your dog when the training collar is in use.
3. പാക്കേജ് ഉള്ളടക്കം
താഴെ ലിസ്റ്റ് ചെയ്തിരിക്കുന്ന എല്ലാ ഇനങ്ങളും നിങ്ങളുടെ പാക്കേജിൽ ഉൾപ്പെടുത്തിയിട്ടുണ്ടെന്ന് ഉറപ്പാക്കുക:
Image: All components included in the DOGlinsen Dog Training Collar package.
- 1x റിമോട്ട് ട്രാൻസ്മിറ്റർ
- 2x Receiver Collars
- 2x Adjustable Collar Belts (one black, one blue)
- 1x Micro USB Charging Cable (dual charging)
- 1x Remote Lanyard
- 8x Silicone Protective Caps
- 8x Alloy Steel Contact Points (various lengths)
- 1x ടെസ്റ്റ് ലൈറ്റ്
- 1x Retrieve Card Pin
- 1x ഉപയോക്തൃ മാനുവൽ
4. ഉൽപ്പന്ന സവിശേഷതകൾ
- വിദൂര ശ്രേണി: Up to 3300 feet (approximately 1000 meters) in open areas.
- Dog Size Compatibility: Suitable for small, medium, and large breed dogs weighing 8-120 lbs.
- പരിശീലന മോഡുകൾ: Features 5 useful modes: Beep, Vibration, Static, Light, and Automatic Bark Mode.
- ക്രമീകരിക്കാവുന്ന ലെവലുകൾ: Vibration and Static modes offer 1-100 adjustable intensity levels.
- വാട്ടർപ്രൂഫ് റേറ്റിംഗ്: IP67 waterproof receiver collars, allowing use in various weather conditions and during water activities (up to 3 ft submersion).
- Dual Display Remote: The remote features a clear dual display for easy monitoring of settings.
- മൾട്ടി-ഡോഗ് സപ്പോർട്ട്: Capable of training up to 2 dogs simultaneously with individual channel control.
- നീണ്ട ബാറ്ററി ലൈഫ്: Remote control lasts up to 180 days on a single charge, receiver collars up to 160 days, with over 200 days standby time.
Image: Collar's IP67 waterproof design and adjustable levels.
Image: Remote range and multi-dog training capability.
Image: Extended battery life of the collar and remote.
5. സജ്ജീകരണം
5.1 ഉപകരണങ്ങൾ ചാർജ് ചെയ്യുന്നു
Before first use, fully charge both the remote transmitter and the receiver collars. Use the provided dual Micro USB charging cable. A full charge typically takes about 2 hours.
- Connect the charging cable to the charging ports on the remote and receiver(s).
- Plug the USB end into a standard USB power adapter (not included).
- The battery indicator on the remote and receiver will show charging status.
5.2 Pairing the Remote and Receiver(s)
The devices are usually pre-paired from the factory. If re-pairing is needed or you are adding a second collar:
- റിമോട്ട് ട്രാൻസ്മിറ്റർ ഓണാക്കുക.
- Select the desired channel (Dog 1 or Dog 2) using the 'CH' button on the remote.
- With the receiver collar turned off, press and hold the power button on the receiver until the indicator light flashes rapidly.
- Within 10 seconds, press the 'Beep' or 'Vibration' button on the remote. The receiver light will stop flashing and remain solid, indicating successful pairing.
5.3 കോളർ ഫിറ്റിംഗ്
Proper fit is essential for the collar's effectiveness and your dog's comfort.
Image: The DOGlinsen remote and two receiver collars.
- Attach the receiver to the adjustable collar belt.
- Select the appropriate length contact points (short for short-haired dogs, long for long-haired dogs) and screw them into the receiver. Always place the silicone protective caps over the contact points.
- Place the collar around your dog's neck, ensuring the contact points touch the skin.
- Adjust the strap so it is snug but not restrictive. You should be able to slide one finger between the collar and your dog's neck. A loose collar will not deliver consistent stimulation and may cause irritation due to rubbing.
Image: Visual guide for correct collar fitting.
6. പ്രവർത്തന നിർദ്ദേശങ്ങൾ
The DOGlinsen training collar offers multiple modes to suit various training needs.
ചിത്രം: കഴിഞ്ഞുview of the four primary training modes.
6.1 പരിശീലന മോഡുകൾ
- Beep Mode (
): Delivers an audible tone to get your dog's attention. This is often the first mode used for training. - Vibration Mode (
): Provides a non-harmful vibration. Levels 1-100 are adjustable. - Static Mode (
): Delivers a static stimulation. Levels 1-100 are adjustable. This mode should be used as a last resort and at the lowest effective level. - Light Mode (
): Activates a flashlight on the remote for visibility in low-light conditions. - Automatic Bark Mode (
): The collar automatically detects and corrects excessive barking without remote intervention.
Image: Features of the automatic bark mode.
6.2 റിമോട്ട് ഉപയോഗിക്കുന്നത്
The remote control allows you to switch between modes and adjust intensity levels.
- പവർ ബട്ടൺ: റിമോട്ട് ഓൺ/ഓഫ് ചെയ്യുന്നു.
- സിഎച്ച് ബട്ടൺ: Switches between Dog 1 and Dog 2 channels.
- മോഡ് ബട്ടണുകൾ: Dedicated buttons for Beep, Vibration, Static, and Light modes.
- '+' ഉം '-' ബട്ടണുകളും: Adjust intensity levels for Vibration and Static modes.
ചിത്രം: വിശദമായത് view of the remote control's display.
7. പരിശീലന നുറുങ്ങുകൾ
Effective training requires consistency and positive reinforcement.
- Start with Beep: Always begin training with the Beep mode. If your dog does not respond, move to Vibration. Static mode should be the last option.
- Lowest Effective Level: When using Vibration or Static modes, start at the lowest intensity level and gradually increase until your dog responds.
- സ്ഥിരത: Use the collar consistently with commands. Repeat and reinforce commands for better understanding.
- പോസിറ്റീവ് റൈൻഫോഴ്സ്മെൻ്റ്: Always reward your dog with treats, praise, or affection for desired behaviors.
- ഹ്രസ്വ സെഷനുകൾ: നിങ്ങളുടെ നായയുടെ ഇടപെടൽ നിലനിർത്താൻ പരിശീലന സെഷനുകൾ ചെറുതും പോസിറ്റീവുമായി നിലനിർത്തുക.
Image: Training considerations for small dogs.
Image: Training considerations for medium dogs.
Image: Training considerations for large dogs.
8. പരിപാലനം
- വൃത്തിയാക്കൽ: കോളറും റിസീവറും പരസ്യം ഉപയോഗിച്ച് തുടയ്ക്കുകamp തുണി. കഠിനമായ രാസവസ്തുക്കൾ ഉപയോഗിക്കരുത്.
- ബന്ധപ്പെടാനുള്ള പോയിൻ്റുകൾ: Regularly inspect the contact points for dirt or corrosion. Clean them as needed.
- ബാറ്ററി കെയർ: To prolong battery life, avoid fully discharging the devices frequently. Charge them when the battery indicator is low.
- സംഭരണം: Store the collar and remote in a dry, cool place when not in use.
9. പ്രശ്നപരിഹാരം
| പ്രശ്നം | സാധ്യമായ കാരണം | പരിഹാരം |
|---|---|---|
| Collar not responding to remote. | Low battery on remote or receiver; Not paired; Out of range; Incorrect channel selected. | Charge both devices; Re-pair the devices; Ensure within 3300ft range; Select correct dog channel (Dog 1/Dog 2). |
| Collar not delivering stimulation. | Contact points not touching skin; Collar too loose; Intensity level too low; Silicone caps not removed (for static). | Adjust collar fit; Ensure contact points are appropriate length and touching skin; Increase intensity level gradually; Ensure silicone caps are used for comfort, but if static is not felt, verify contact. |
| Automatic Bark Mode not working. | Mode not activated; Collar not detecting bark correctly. | Ensure Auto Bark Mode is enabled; Check collar fit and position. |
| Remote screen blinking or unresponsive. | ബാറ്ററി കുറവാണ്; സോഫ്റ്റ്വെയർ തകരാർ. | Recharge the remote; Try resetting the remote (refer to specific instructions in the included user manual if available, or power cycle). |
10 സ്പെസിഫിക്കേഷനുകൾ
- നിർമ്മാതാവ്: ഡോഗ്ലിൻസെൻ
- ഇനം മോഡൽ നമ്പർ: shock collar for small dogs 5-15lbs (Note: Product supports 8-120lb dogs as per title)
- ഉൽപ്പന്ന അളവുകൾ: 15.49 x 9.98 x 5.49 സെ.മീ; 372 ഗ്രാം
- ബാറ്ററികൾ: 3 ലിഥിയം പോളിമർ ബാറ്ററികൾ ആവശ്യമാണ് (ഉൾപ്പെടുത്തിയിരിക്കുന്നു)
- ആദ്യം ലഭ്യമായ തീയതി: സെപ്റ്റംബർ 2, 2022
11. വാറൻ്റിയും പിന്തുണയും
DOGlinsen is committed to providing quality products and customer satisfaction. If you encounter any issues with your training collar, please contact DOGlinsen customer support. Information regarding specific warranty terms and contact details can typically be found in the packaging or on the official DOGlinsen webസൈറ്റ്.
