ആമുഖം
This manual provides detailed instructions for the safe and effective use of your OLIGHT Marauder Mini flashlight. Please read this manual thoroughly before operating the device and retain it for future reference.
Image: The OLIGHT Marauder Mini flashlight, showcasing its compact design and multi-LED head.
പാക്കേജ് ഉള്ളടക്കം
- OLIGHT Marauder Mini Flashlight (1)
- Customized Rechargeable Lithium-Ion Battery (pre-installed)
- MCC3 Magnetic Charging Cable (1)
- ലാനിയാർഡ് (1)
- Holster (1)
- ഉപയോക്തൃ മാനുവൽ (1)
സജ്ജമാക്കുക
പ്രാരംഭ ചാർജിംഗ്
The Marauder Mini comes with a pre-installed rechargeable lithium-ion battery. Before first use, fully charge the flashlight.
- Connect the MCC3 magnetic charging cable to a USB power source.
- Attach the magnetic end of the charging cable to the charging port located at the tailcap of the flashlight. The indicator on the charging cable will turn red during charging and green when fully charged.
Image: The Marauder Mini flashlight connected to a power bank via its magnetic charging cable.
ലാനിയാർഡ് അറ്റാച്ച്മെന്റ്
Attach the included lanyard to the designated lanyard hole for secure carrying and to prevent accidental drops.
പ്രവർത്തന നിർദ്ദേശങ്ങൾ
The Marauder Mini features a dual-switch system: a toggle switch for beam type selection and a rotary knob for brightness and mode adjustments.
പവർ ഓൺ/ഓഫ്
- To turn on/off: Press the rotary knob switch once.
Beam Type Selection (White Light)
Use the toggle switch located on the flashlight body to select between floodlight and spotlight modes.
- Flip the toggle switch up for spotlight mode (focused beam).
- Flip the toggle switch താഴേക്ക് for floodlight mode (wide, diffused beam).
Image: Visual comparison of the flashlight's floodlight mode (wide illumination) and spotlight mode (focused beam).
Brightness Adjustment (White Light)
Once the flashlight is on and in white light mode, rotate the knob switch to adjust brightness levels. The indicators around the knob will show the current brightness level.
- നോബ് തിരിക്കുക ഘടികാരദിശയിൽ തെളിച്ചം വർദ്ധിപ്പിക്കാൻ.
- നോബ് തിരിക്കുക എതിർ ഘടികാരദിശയിൽ തെളിച്ചം കുറയ്ക്കാൻ.
RGB ലൈറ്റ് മോഡുകൾ
The Marauder Mini features Red, Green, and Blue (RGB) light options.
- To activate RGB lights: With the flashlight on, quickly double-press the rotary knob switch.
- To cycle through RGB colors (Red, Green, Blue): While in RGB mode, rotate the knob switch.
- To return to white light: Quickly double-press the rotary knob switch again.
Image: Demonstrations of the flashlight emitting red, green, and blue light, highlighting their potential uses.
സ്ട്രോബ് മോഡ്
To activate strobe mode: With the flashlight on, quickly triple-press the rotary knob switch. Triple-press again to exit strobe mode.
ലോക്കൗട്ട് പ്രവർത്തനം
The flashlight features a smart lockout function to prevent accidental activation.
- Automatic Lockout: The flashlight will automatically lock out after 10 seconds of non-operation when it is off.
- Manual Lockout: To manually lock out the flashlight, press and hold the rotary knob switch for approximately 2 seconds until the light briefly flashes, indicating lockout mode.
- അൺലോക്ക് ചെയ്യുന്നു: To unlock, quickly rotate the rotary knob switch more than 90 degrees. The flashlight will turn on to the previously used brightness setting.
Image: Diagram illustrating the lockout and unlock procedure for the rotary knob switch.
സൂചകങ്ങൾ
The Marauder Mini features intuitive indicators around the rotary knob:
- Brightness Level Indicator: Located on the left side, shows the current white light brightness level.
- ബാറ്ററി ലെവൽ ഇൻഡിക്കേറ്റർ: Located on the right side, displays the remaining battery charge.
- Light Color Indicator: At the bottom, indicates the active RGB color mode.
- Vibrating Indicator: The flashlight provides haptic feedback (vibration) when reaching the highest or lowest brightness settings.
Image: Close-up of the flashlight's control panel, highlighting the brightness, battery, and light color indicators around the rotary knob.
മെയിൻ്റനൻസ്
വൃത്തിയാക്കൽ
Regularly clean the lens and body of the flashlight with a soft, damp cloth. Avoid using abrasive materials or harsh chemicals that could damage the finish or optical components.
ഒ-റിംഗ് ലൂബ്രിക്കേഷൻ
To maintain water resistance, periodically inspect and lubricate the O-rings with silicone grease. Replace O-rings if they appear damaged or worn.
ബാറ്ററി കെയർ
Store the flashlight with a partially charged battery if not used for extended periods. Avoid fully discharging the battery frequently, as this can reduce its lifespan.
ട്രബിൾഷൂട്ടിംഗ്
ഫ്ലാഷ്ലൈറ്റ് ഓണാക്കുന്നില്ല
- ബാറ്ററി പൂർണ്ണമായി ചാർജ് ചെയ്തിട്ടുണ്ടെന്ന് ഉറപ്പാക്കുക.
- Check if the flashlight is in lockout mode. Unlock by quickly rotating the knob switch more than 90 degrees.
- Verify that the battery is correctly inserted.
Reduced Brightness or Runtime
- ബാറ്ററി ചാർജ് കുറവായിരിക്കാം. ഫ്ലാഷ്ലൈറ്റ് റീചാർജ് ചെയ്യുക.
- Clean the lens if it appears dirty, as debris can obstruct light output.
അമിത ചൂടാക്കൽ
High-lumen flashlights can generate significant heat during prolonged use at maximum output. The Marauder Mini is designed with thermal management to reduce output and prevent damage. If the flashlight becomes excessively hot, reduce the brightness level or turn it off to allow it to cool down.
സ്പെസിഫിക്കേഷനുകൾ
Image: Infographic displaying key specifications of the Marauder Mini, including max output, throw, runtime, drop test rating, battery type, and waterproof rating.
| ഫീച്ചർ | വിശദാംശങ്ങൾ |
|---|---|
| ബ്രാൻഡ് | ഓലി |
| മോഡൽ | Marauder Mini |
| Max White Brightness | 7000 ല്യൂമെൻസ് |
| പരമാവധി ബീം ദൂരം | 600 മീറ്റർ |
| പ്രകാശ സ്രോതസ്സ് തരം | LED (White, Red, Green, Blue) |
| പവർ ഉറവിടം | ബാറ്ററി പവർ (1 ലിഥിയം അയൺ ബാറ്ററി ഉൾപ്പെടുത്തിയിരിക്കുന്നു) |
| മെറ്റീരിയൽ | അലുമിനിയം അലോയ് |
| ജല പ്രതിരോധ നില | വാട്ടർപ്രൂഫ് (IPX8 റേറ്റുചെയ്തത്) |
| ഉൽപ്പന്ന അളവുകൾ | 7.17"D x 4.76"W x 3.03"H |
| ഇനത്തിൻ്റെ ഭാരം | 1.78 പൗണ്ട് |
| പ്രത്യേക സവിശേഷതകൾ | Adjustable Light Modes, High Power, Long Range, RGB lights, Magnetic Rechargeable |
White Light Performance (Floodlight)
Image: Table detailing lumen output, runtime, and beam distance for various white light floodlight and spotlight modes.
RGB Light Performance
Image: Table detailing lumen output, runtime, and beam distance for various Red, Green, and Blue light modes.
വാറൻ്റിയും പിന്തുണയും
വാറൻ്റി വിവരങ്ങൾ
The OLIGHT Marauder Mini flashlight comes with a ആജീവനാന്ത വാറൻ്റി for products purchased after January 1st, 2023. This warranty covers manufacturing defects and ensures the product's quality and performance.
ഉപഭോക്തൃ പിന്തുണ
Should you encounter any issues or have questions regarding your OLIGHT Marauder Mini, please contact OLIGHT customer support. Contact information can typically be found on the official OLIGHT website or through your purchase retailer.
