Lumary Smart LED String Light 16.5m with Remote Control

1. ആമുഖം

This manual provides essential information for the safe and efficient use of your Lumary Smart LED String Light. Please read it thoroughly before installation and operation, and retain it for future reference.

Figure 1: Lumary Smart String Light product packaging and components.

2. സുരക്ഷാ നിർദ്ദേശങ്ങൾ

• വൈദ്യുതി വിതരണം വോളിയം ഉറപ്പാക്കുകtage matches the product's requirements (110V AC).
• Do not attempt to repair or modify the product yourself. Refer all servicing to qualified personnel.
• Keep the product away from open flames and extreme heat sources.
• Ensure all connections are secure before plugging into a power outlet.
• Do not immerse the power adapter or control box in water, despite the IP65 rating for the string light itself.
• Always unplug the string light from the power source before cleaning or performing any maintenance.
• This product is designed for outdoor use but should be installed in a manner that minimizes exposure to severe weather conditions.

3. പാക്കേജ് ഉള്ളടക്കം

പാക്കേജിൽ എല്ലാ ഇനങ്ങളും ഉണ്ടെന്ന് ഉറപ്പാക്കുക:

• 1x Lumary Smart LED String Light (16.5m with 15 bulbs)
• 1x Spare LED Bulb
• 1x Smart Controller
• 1x പവർ അഡാപ്റ്റർ
• 1x റിമോട്ട് കൺട്രോൾ
• 1x ഉപയോക്തൃ മാനുവൽ (ഈ പ്രമാണം)

4. സജ്ജീകരണം

4.1 ഫിസിക്കൽ ഇൻസ്റ്റലേഷൻ

1. Unpack the string light and all components.
2. Carefully uncoil the string light, ensuring no tangles or damage to the cable or bulbs.
3. Mount the string light in your desired outdoor location. The cable is designed to withstand outdoor elements.
4. Connect the smart controller to the string light.
5. Connect the power adapter to the smart controller.
6. Ensure the power adapter is placed in a dry location, protected from direct water exposure.

Figure 2: Component overview and dimensions. The string light measures 16.5m (56ft) with 15 bulbs. The plug wire is 0.98m, and the distance from the smart controller to the first bulb is 1.7m.

Figure 3: Detailed dimensions and layout of the string light.

4.2 ആപ്പ് ഇൻസ്റ്റാളേഷനും ജോടിയാക്കലും

1. Download the "Lumary" app from your smartphone's app store.
2. Register or log in to your Lumary account.
3. Plug the string light into a power outlet. The lights should begin to flash, indicating pairing mode.
4. In the Lumary app, follow the on-screen instructions to add a new device.
5. Ensure your smartphone is connected to a 2.4GHz Wi-Fi network. The Lumary Smart LED String Light only supports 2.4GHz Wi-Fi.
6. Once connected, you can control the lights via the app.

4.3 വോയ്‌സ് അസിസ്റ്റന്റ് ഇന്റഗ്രേഷൻ

The Lumary Smart LED String Light is compatible with Alexa and Google Assistant.

1. Ensure your string light is successfully paired with the Lumary app.
2. നിങ്ങളുടെ Alexa അല്ലെങ്കിൽ Google Home ആപ്പ് തുറക്കുക.
3. "കഴിവുകൾ" അല്ലെങ്കിൽ "Google-ൽ പ്രവർത്തിക്കുന്നു" വിഭാഗത്തിലേക്ക് നാവിഗേറ്റ് ചെയ്യുക.
4. ഇതിനായി തിരയുക and enable the "Lumary" skill/service.
5. Link your Lumary account when prompted.
6. Discover devices. Your Lumary Smart LED String Light should now appear in your voice assistant app.
7. You can now use voice commands such as "Alexa, turn on the string light" or "Hey Google, change string light to red."

Figure 4: Voice control in action with Alexa.

5. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

5.1 നിയന്ത്രണ മോഡുകൾ

Your Lumary Smart LED String Light offers multiple control options:

• Lumary App: Full control over colors, brightness, scenes, and scheduling.
• റിമോട്ട് കൺട്രോൾ: Included remote for basic functions like on/off, mode changes, and dimming.
• Switch Box: The physical control box on the string light allows for basic on/off and mode changes without network connectivity.
• ശബ്ദ നിയന്ത്രണം: Integrate with Alexa or Google Assistant for hands-free operation.

ചിത്രം 5: ഓവർview of the four available control modes.

5.2 Color and Brightness Adjustment

• RGBAiWW Technology: The string light features RGBAiWW technology, allowing for a wide spectrum of colors, including 16 million color options and dedicated warm white modes.
• വ്യക്തിഗത ബൾബ് നിയന്ത്രണം: Each bulb can be controlled independently via the Lumary app. You can turn individual bulbs on/off, change their color, and adjust brightness from 1% to 100%.
• ഗ്രൂപ്പ് നിയന്ത്രണം: Create groups within the Lumary app to manage multiple string lights or sections simultaneously with a single command.

5.3 Scene Modes and Music Synchronization

• Preset Scenes: The Lumary app offers over 8 preset scene modes to instantly set the ambiance for various occasions.
• DIY Scenes: Customize and save your own scene modes by adjusting colors and brightness to your preference.
• സംഗീത സമന്വയം: The string light can change colors in sync with music rhythms or game sounds, enhancing your entertainment experience.

5.4 ടൈമറും ഷെഡ്യൂളിംഗും

Use the Lumary app to set schedules for your string lights:

• ടൈമർ പ്രവർത്തനം: Set a timer for the lights to automatically turn on or off after a specified duration.
• ഷെഡ്യൂളിംഗ്: Create daily or weekly schedules for the lights to activate or deactivate at specific times, such as turning on in the evening and off in the morning.

6. പരിപാലനം

6.1 ഈട് സവിശേഷതകൾ

• IP65 വാട്ടർപ്രൂഫ്: The string light and control box are rated IP65, providing protection against dust and water jets, making them suitable for outdoor use in various weather conditions.
• തകരാത്ത ബൾബുകൾ: The robust PC plastic bulbs are designed to be shatterproof, resisting impacts and drops.
• Stronger Cable: The string light features a 22 AWG (3-conductor) cable, enhancing its durability and resistance to wind, rain, and snow.
• Parallel Technology: Designed with parallel wiring, if one bulb breaks, the remaining bulbs will continue to function without interruption.

Figure 6: Lumary's durable design features compared to standard string lights.

6.2 ബൾബ് മാറ്റിസ്ഥാപിക്കൽ

The string light comes with 15 dimmable 1W LED bulbs and 1 spare bulb. If a bulb needs replacement:

1. Ensure the string light is unplugged from the power source.
2. Carefully unscrew the faulty bulb.
3. Screw in a new compatible LED bulb.
4. Dispose of the old bulb responsibly.

7. പ്രശ്‌നപരിഹാരം

8 സ്പെസിഫിക്കേഷനുകൾ

Figure 7: EU Energy Label. For more details, refer to the EPREL ഡാറ്റാബേസ്.

Figure 8: Product Data Sheet with detailed technical information. For more details, refer to the EPREL ഡാറ്റാബേസ്.

9. വാറണ്ടിയും പിന്തുണയും

Specific warranty information for the Lumary Smart LED String Light is not provided in the product data. For warranty details, technical support, or replacement parts, please contact Lumary customer service directly or refer to the official Lumary webസൈറ്റ്.

Information regarding the availability of spare parts and guaranteed software updates is not available in the provided product data.
