Luoran M4 Pro MP3 Player User Manual

ആമുഖം

This manual provides comprehensive instructions for the operation and maintenance of your Luoran M4 Pro MP3 Player. Designed for a rich audio-visual experience, this device combines advanced features with a user-friendly interface. Please read this manual thoroughly to ensure proper usage and to maximize the performance of your device.

ബോക്സിൽ എന്താണുള്ളത്

അൺബോക്സിംഗ് ചെയ്യുമ്പോൾ, ഇനിപ്പറയുന്ന എല്ലാ ഇനങ്ങളും ഉൾപ്പെടുത്തിയിട്ടുണ്ടെന്ന് ദയവായി ഉറപ്പാക്കുക:

• Luoran M4 Pro MP3 Player
• USB-C ചാർജിംഗ് കേബിൾ
• OTG അഡാപ്റ്റർ
• Screensaver Film (2 pieces)
• വയർഡ് ഹെഡ്‌സെറ്റ്
• നിർദ്ദേശങ്ങൾ (ഈ മാനുവൽ)

ഉൽപ്പന്നം കഴിഞ്ഞുview

Familiarize yourself with the physical components and design of your Luoran M4 Pro MP3 Player.

ചിത്രം 1: മുൻഭാഗം view of the Luoran M4 Pro MP3 Player, showcasing its 4.0-inch IPS full touchscreen display with various application icons.

Figure 2: Illustrates the sleek design of the player, highlighting its arc metal frame and tempered glass front and rear covers for durability and aesthetic appeal.

Figure 3: Close-up of the 4.0-inch IPS full touchscreen, emphasizing high color accuracy, large viewing angle, and fast response times for an enhanced visual experience.

The device features a durable arc metal frame with tempered glass on both the front and rear. It includes a USB-C charging port and two 3.5mm headphone jacks, allowing two users to listen simultaneously. A built-in speaker is also integrated for direct audio playback.

സജ്ജീകരണ ഗൈഡ്

1 ഉപകരണം ചാർജ് ചെയ്യുന്നു

Before first use, fully charge your MP3 player. Connect the provided USB-C cable to the device's USB-C port and the other end to a compatible USB power adapter (not included) or a computer's USB port. A full charge takes approximately 2.5 hours.

Figure 4: Depicts the 2000mAh battery capacity, indicating long battery life for extended music playback and standby time.

2. പവർ ഓൺ/ഓഫ്

• To Power On: Press and hold the Power button located on the side of the device until the screen illuminates.
• To Power Off: Press and hold the Power button until a power-off menu appears. Select "Power Off" to shut down the device.

3. Wi-Fi-ലേക്ക് ബന്ധിപ്പിക്കുന്നു

To access online streaming services and transfer files wirelessly, connect your device to a Wi-Fi network:

1. From the home screen, tap the "Settings" icon.
2. Select "Network & Internet" and then "Wi-Fi".
3. Toggle Wi-Fi to "On".
4. ലിസ്റ്റിൽ നിന്ന് നിങ്ങൾക്ക് ആവശ്യമുള്ള വൈഫൈ നെറ്റ്‌വർക്ക് തിരഞ്ഞെടുക്കുക.
5. Enter the network password if prompted and tap "Connect".

Figure 5: Highlights the device's Bluetooth V4.2 and Wi-Fi capabilities, enabling wireless file transfer and connectivity with Bluetooth headphones, speakers, and car stereos.

4. കൈമാറ്റം Files

You can transfer music and other files to your device via USB or Wi-Fi:

• USB കൈമാറ്റം: Connect the device to your computer using the USB-C cable. The device will appear as a removable storage drive. Drag and drop your files into the appropriate folders (e.g., "Music", "Videos").
• Wi-Fi Transfer: Utilize the pre-installed "MiniShare" or similar file transfer application on the device to share or receive files wirelessly from other Wi-Fi enabled devices.

5. Installing and Updating Applications

The Luoran M4 Pro comes with pre-installed applications such as Spotify, Audible, Pandora, Amazon Music, and Apple Music. Due to the Android 8.1 system version, some newer applications may not be compatible or require specific APK files for installation. For app updates or new installations, you may need to download APK files from trusted sources and install them manually.

Figure 6: Displays various pre-installed online streaming applications, including Spotify, Kindle, Audible, Deezer, Kobo books, iHeartRadio, Apple Music, Tidal, Podcasts Tracker, Pandora, and Amazon Music.

Figure 7: Shows the interface for managing installed applications, including options to uninstall them.

6. ഒരു മൈക്രോ എസ്ഡി കാർഡ് ചേർക്കൽ

The device supports Micro SD cards up to 1TB for expanded storage. Locate the Micro SD card slot on the side of the device. Gently insert the card until it clicks into place. To remove, push the card inward until it springs out.

Figure 8: Illustrates the Micro SD card slot, indicating support for up to 1TB of expandable storage.

പ്രവർത്തന നിർദ്ദേശങ്ങൾ

1. ഇന്റർഫേസ് നാവിഗേറ്റ് ചെയ്യുന്നു

The Luoran M4 Pro features a full touchscreen for intuitive navigation. Swipe left or right to browse through app pages, tap icons to open applications, and use the navigation buttons at the bottom of the screen (Back, Home, Recent Apps) to control your experience.

2. Playing Music and Videos

The device supports a wide range of audio and video formats. Use the pre-installed music and video players to enjoy your media:

• ഓഡിയോ ഫോർമാറ്റുകൾ: MP3, OGG, APE, FLAC, WAV, AAC, M4A, M4R, MP2, AMR, ACELP.
• വീഡിയോ ഫോർമാറ്റുകൾ: AVI, MKV, MPG, MPEG, RM, RMVB, VOB, MOV, FLV, ASF, DAT, MP4, 3GP.

Figure 9: Shows the music playback interface, indicating support for various audio formats and controls.

Figure 10: Displays the video playback interface, demonstrating the device's capability to play 720P and 1080P videos.

3. ബ്ലൂടൂത്ത് കണക്റ്റിവിറ്റി

The device features Bluetooth V4.2 for connecting to wireless headphones, speakers, or car stereos. To pair a Bluetooth device:

1. Go to "Settings" > "Connected devices" > "Bluetooth".
2. ബ്ലൂടൂത്ത് "ഓൺ" എന്നതിലേക്ക് മാറ്റുക.
3. Select "Pair new device" and choose your Bluetooth accessory from the list of available devices.
4. ആവശ്യപ്പെടുകയാണെങ്കിൽ രണ്ട് ഉപകരണങ്ങളിലും ജോടിയാക്കൽ സ്ഥിരീകരിക്കുക.

4. Using Dual Headphone Jacks

The Luoran M4 Pro is equipped with two 3.5mm headphone jacks, allowing two individuals to listen to audio simultaneously from the same device. Simply plug in two sets of wired headphones into the available ports.

5. Built-in Speaker and Equalizer

For convenient audio playback without headphones, use the built-in speaker. The device also includes an equalizer function to customize your audio experience, allowing adjustments for sweet treble, accurate mid-range, and deep bass.

Figure 11: Illustrates the built-in speaker and its equalizer capabilities, offering enhanced audio quality with adjustable treble, mid-range, and bass.

മെയിൻ്റനൻസ്

1. ബാറ്ററി പരിചരണം

To prolong battery life, avoid fully discharging the device frequently. Charge the device regularly, especially if it will be stored for an extended period. The 2000mAh battery provides ampദൈനംദിന ഉപയോഗത്തിന് le വൈദ്യുതി.

2. സ്റ്റോറേജ് മാനേജ്മെൻ്റ്

Regularly manage your device's storage. Delete unnecessary files and applications to free up the 16GB internal memory. Utilize a Micro SD card (up to 1TB) for large media libraries to ensure optimal performance.

3. നിങ്ങളുടെ ഉപകരണം വൃത്തിയാക്കൽ

Use a soft, lint-free cloth to clean the screen and body of the device. Avoid using abrasive cleaners or solvents, as these can damage the screen and finish. Keep the ports free of dust and debris.

ട്രബിൾഷൂട്ടിംഗ്

സ്പെസിഫിക്കേഷനുകൾ

വാറൻ്റിയും പിന്തുണയും

Luoran is committed to providing high-quality audio devices and stands behind its products. For any questions, technical assistance, or support inquiries regarding your Luoran M4 Pro MP3 Player, please refer to the contact information provided on the product packaging or the official Luoran webസൈറ്റ്. നിങ്ങളെ സഹായിക്കാൻ ഞങ്ങളുടെ ഉപഭോക്തൃ സേവന ടീം ലഭ്യമാണ്.

Please retain your proof of purchase for warranty claims. Specific warranty terms and conditions may vary by region and are detailed on the official Luoran support channels.
