iDPRT MT890 പോർട്ടബിൾ വയർലെസ് പ്രിന്റർ യൂസർ മാനുവൽ

1. ആമുഖം

The iDPRT MT890 is a portable, inkless thermal printer designed for convenient printing on the go. It utilizes advanced inkless technology, eliminating the need for ink cartridges or toner. This manual provides detailed instructions to help you get started and make the most of your device.

പ്രധാന സവിശേഷതകളിൽ ഇവ ഉൾപ്പെടുന്നു:

• Advanced Inkless Technology: High-speed thermal printing without ink or toner.
• Innovative Built-in Roll Paper Design: Supports A4, US Letter, and A5 sizes, with a serrated tearing knife for custom lengths.
• Free "HerePrint" App: Offers extensive functions for creative printing experiences on mobile devices.
• എളുപ്പമുള്ള കണക്റ്റിവിറ്റി: Supports Bluetooth for mobile devices (iOS, Android) and USB for laptops (Mac, Windows, Linux, Chrome OS).
• ഒതുക്കമുള്ളതും പോർട്ടബിൾ: Lightweight design (2.77 pounds) for easy transport in briefcases or backpacks.

Figure 1: The iDPRT MT890 Portable Wireless Printer in use, demonstrating its ability to print detailed images.

2. ബോക്സിൽ എന്താണുള്ളത്?

Upon unboxing your iDPRT MT890 printer, you should find the following items:

• iDPRT MT890 Portable Wireless Printer
• Thermal A4 Paper Roll (pre-installed or included separately)
• USB-C ചാർജിംഗ് കേബിൾ
• ഉപയോക്തൃ മാനുവൽ

Figure 2: The iDPRT MT890 printer shown with a roll of thermal paper, indicating the paper type used by the device.

3. ഉൽപ്പന്നം കഴിഞ്ഞുview

The iDPRT MT890 printer features a minimalist design with essential controls. It is designed for ease of use and portability.

3.1 ശാരീരിക സവിശേഷതകൾ

• പവർ ബട്ടൺ: Located on the top surface, used for turning the device on/off and initiating certain functions.
• സ്റ്റാറ്റസ് ഇൻഡിക്കേറ്റർ ലൈറ്റ്: Provides visual feedback on power, battery, and connection status.
• Paper Output Slot: Where printed documents exit the printer.
• യുഎസ്ബി-സി പോർട്ട്: For charging and wired connection to computers.
• Paper Release Latches: Located on the sides, used to open the printer for paper loading.

Figure 3: The compact dimensions of the iDPRT MT890 printer, highlighting its portability.

4. സജ്ജീകരണം

4.1 പ്രിന്റർ ചാർജ് ചെയ്യുന്നു

1. Connect the provided USB-C cable to the printer's charging port.
2. Plug the other end of the USB-C cable into a compatible USB power adapter or a computer's USB port.
3. The status indicator light will show charging status (e.g., red for low battery, green for fully charged).

4.2 തെർമൽ പേപ്പർ ലോഡുചെയ്യുന്നു

1. Locate the paper release latches on both sides of the printer.
2. Press both latches simultaneously to open the printer cover.
3. Insert the thermal paper roll into the designated slot, ensuring the printing side faces upwards.
4. Pull a small amount of paper out of the roll, extending it past the paper output slot.
5. പ്രിന്റർ കവർ അതിന്റെ സ്ഥാനത്ത് ക്ലിക്ക് ആകുന്നതുവരെ ദൃഢമായി അടയ്ക്കുക.

Figure 4: Illustrates the process of loading thermal paper into the iDPRT MT890 printer.

5. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

5.1 പവർ ഓൺ/ഓഫ്

• പവർ ഓണാക്കാൻ: Long press the power button until the status indicator light illuminates.
• പവർ ഓഫ് ചെയ്യാൻ: Long press the power button until the status indicator light turns off.

5.2 മൊബൈൽ ഉപകരണ കണക്ഷൻ (ബ്ലൂടൂത്ത്)

1. Download the "HerePrint" app from your device's app store. Download HerePrint App
2. Ensure your iDPRT MT890 printer is powered on.
3. Open the "HerePrint" app and follow the on-screen prompts to connect to your printer via Bluetooth. The app will guide you through the pairing process.
4. Once connected, the app will display "Printer connected."

5.3 Computer Connection (USB)

1. Download and install the appropriate MT890 driver from the official iDPRT webസൈറ്റ്. iDPRT Driver Download
2. Use the provided USB-C cable to connect the iDPRT MT890 printer to your computer.
3. Open your document or file and select "iDPRT MT890" from the printer list to initiate printing.

Figure 5: The iDPRT MT890 printer connected to both a laptop via USB and a smartphone via Bluetooth, illustrating versatile connectivity options.

5.4 പ്രമാണങ്ങൾ അച്ചടിക്കൽ

• From the "HerePrint" app or your computer's print dialogue, select the document or image you wish to print.
• Adjust print settings such as density, copies, print size (A4, A5, 4-inch), and margins as needed.
• Confirm your selections and initiate the print job. The printer will quickly produce your document.

Figure 6: The user interface of the HerePrint app, displaying options for printing pictures, documents, webpages, and accessing print history.

6. Media Handling

The iDPRT MT890 printer uses specialized thermal paper. It supports various sizes and offers flexibility for different printing needs.

• പിന്തുണയ്ക്കുന്ന വലുപ്പങ്ങൾ: US Letter, A4, and A5. The innovative roll design allows for printing on any length as needed.
• പേപ്പർ തരം: Only thermal paper is compatible. Regular A4 paper cannot be used.
• Tearing Knife: The printer includes a serrated tearing knife for easy and clean paper detachment.

Figure 7: The iDPRT MT890 printer demonstrating its compatibility with various thermal paper sizes.

Figure 8: A diagram illustrating the layered structure of high-quality thermal paper, emphasizing its durability and print quality.

7. പരിപാലനം

The iDPRT MT890 printer's inkless thermal technology significantly reduces maintenance requirements.

• No Ink/Toner Replacement: As an inkless printer, there is no need to replace ink cartridges or toner.
• വൃത്തിയാക്കൽ: Periodically wipe the exterior of the printer with a soft, dry cloth. Ensure no debris obstructs the paper path.
• സംഭരണം: Store the printer in a cool, dry place away from direct sunlight to preserve the thermal paper quality.

Figure 9: The iDPRT MT890 printer emphasizing its inkless operation, eliminating the need for ink or toner.

8. പ്രശ്‌നപരിഹാരം

If you encounter issues with your iDPRT MT890 printer, consider the following common solutions:

• പ്രിന്റർ പ്രതികരിക്കുന്നില്ല: Ensure the printer is powered on and fully charged. Check the Bluetooth or USB connection.
• മോശം പ്രിന്റ് നിലവാരം: Verify that you are using compatible thermal paper. Adjust print density settings in the "HerePrint" app or printer driver.
• പേപ്പർ ജാമുകൾ: Open the printer cover using the side latches and carefully remove any jammed paper. Ensure the paper roll is correctly installed.
• കണക്ഷൻ പ്രശ്നങ്ങൾ: For Bluetooth, ensure Bluetooth is enabled on your mobile device and the printer is within range. For USB, confirm the driver is installed correctly and the cable is securely connected.
• ആപ്പ് പ്രശ്നങ്ങൾ: Ensure the "HerePrint" app is updated to the latest version. Restart the app or your mobile device if necessary.

9 സ്പെസിഫിക്കേഷനുകൾ

10. വാറൻ്റിയും പിന്തുണയും

For warranty information, technical support, or service inquiries, please refer to the documentation included with your product or visit the official iDPRT webസൈറ്റ്. വാറൻ്റി ക്ലെയിമുകൾക്കായി നിങ്ങളുടെ വാങ്ങൽ രസീത് സൂക്ഷിക്കുക.
