1Mii RCA ബ്ലൂടൂത്ത് 5.3 അഡാപ്റ്റർ യൂസർ മാനുവൽ

ആമുഖം

Thank you for choosing the 1Mii RCA Bluetooth 5.3 Adapter (Model ML302+). This versatile 2-in-1 device functions as both a Bluetooth transmitter and receiver, enabling seamless wireless audio connectivity for a wide range of devices. Whether you want to stream audio from your non-Bluetooth TV to wireless headphones or transform your wired speakers into a Bluetooth-enabled system, the ML302+ provides a high-fidelity, low-latency solution.

Image: The 1Mii ML302+ Bluetooth adapter, a compact black device with control buttons and audio ports.

സുരക്ഷാ വിവരങ്ങൾ

Please read the following safety guidelines carefully before using the device:

• ഇടപെടൽ ഒഴിവാക്കാൻ ഉപകരണം മറ്റ് വയർലെസ് ഉപകരണങ്ങൾക്ക് സമീപം വയ്ക്കുന്നത് ഒഴിവാക്കുക.
• Keep the battery away from extreme temperatures and humidity.
• Do not dispose of the battery in regular trash; follow local regulations for battery disposal.
• ഉപകരണം സ്വയം ഡിസ്അസംബ്ലിംഗ് ചെയ്യുകയോ പരിഷ്കരിക്കുകയോ നന്നാക്കാൻ ശ്രമിക്കുകയോ ചെയ്യരുത്. ഇത് വാറന്റി അസാധുവാക്കുകയും സുരക്ഷാ അപകടങ്ങൾ ഉണ്ടാക്കുകയും ചെയ്തേക്കാം.
• ഉപകരണം വെള്ളത്തിൽ നിന്നോ മറ്റ് ദ്രാവകങ്ങളിൽ നിന്നോ സൂക്ഷിക്കുക.

പാക്കേജ് ഉള്ളടക്കം

നിങ്ങളുടെ പാക്കേജിൽ എല്ലാ ഇനങ്ങളും ഉണ്ടെന്ന് ഉറപ്പാക്കുക:

• 1Mii Bluetooth Transmitter Receiver (ML302+)
• ഇൻസ്ട്രക്ഷൻ മാനുവൽ
• 3.5 എംഎം ഓഡിയോ കേബിൾ
• ആർസിഎ ഓഡിയോ കേബിൾ
• ടൈപ്പ്-സി പവർ കോർഡ്

Image: A visual representation of the ML302+ adapter and its included accessories: instruction manual, 3.5mm audio cable, RCA audio cable, and Type-C power cord.

ഉൽപ്പന്നം കഴിഞ്ഞുview

The 1Mii ML302+ is designed for maximum versatility, offering both transmitting and receiving capabilities:

• ട്രാൻസ്മിറ്റർ (TX) മോഡ്: Convert non-Bluetooth audio sources (TV, PC, Projector, Treadmills) into Bluetooth-enabled devices, allowing them to connect to Bluetooth headphones or speakers.
• റിസീവർ (RX) മോഡ്: Enable non-Bluetooth audio devices (Home Stereo, Speakers, Car Stereo) to receive Bluetooth audio from your smartphone or tablet.
• ബ്ലൂടൂത്ത് 5.3: Provides stable, fast, and reliable connections.
• aptX കുറഞ്ഞ ലേറ്റൻസി: Ensures synchronized audio and video, minimizing lip-sync delay when paired with compatible devices.
• ഇരട്ട കണക്ഷൻ: Connect two Bluetooth headphones simultaneously in TX mode, or two devices in RX mode.
• വോളിയം നിയന്ത്രണം: Integrated buttons for easy audio level adjustment.
• നീണ്ട ബാറ്ററി ലൈഫ്: ഒറ്റ ചാർജിൽ 30 മണിക്കൂർ വരെ തുടർച്ചയായ ഉപയോഗം.

Image: Diagram illustrating the 2-in-1 functionality, showing how the device acts as a transmitter for TVs/PCs to headphones/speakers, and as a receiver for phones/tablets to wired earphones/speakers/car stereos.

സജ്ജമാക്കുക

1 ഉപകരണം ചാർജ് ചെയ്യുന്നു

Before first use, fully charge the ML302+ using the provided Type-C power cord and a standard USB power adapter (not included). The device has a built-in Lithium Polymer battery. You can check the battery level by pressing the Bluetooth button 3 times (LEDs flash 1-5 times, each flash = 20% battery level).

2. Selecting Operating Mode (TX/RX)

Locate the TX/OFF/RX switch on the side of the device. Slide the switch to the desired mode:

• TX (ട്രാൻസ്മിറ്റർ) മോഡ്: To send audio from a non-Bluetooth device (e.g., TV) to Bluetooth headphones/speakers.
• RX (റിസീവർ) മോഡ്: To receive audio from a Bluetooth device (e.g., smartphone) and play it through wired speakers/car stereo.

3. Connecting to Your Audio Source/Device

The ML302+ supports both 3.5mm AUX and RCA connections. Choose the appropriate cable based on your device's audio output/input ports.

• TX മോഡിൽ: Connect the ML302+ to the ഓഡിയോ .ട്ട് jack of your device (e.g., TV, PC) using either the 3.5mm AUX cable or the RCA cable.
• RX മോഡിൽ: Connect the ML302+ to the ഓഡിയോ IN jack of your wired audio system (e.g., home stereo, speakers) using either the 3.5mm AUX cable or the RCA cable.

ചിത്രം: ക്ലോസ്-അപ്പ് view of the ML302+ showing its 3.5mm AUX and RCA input/output ports.

Image: Diagram illustrating correct audio output connections on a TV for the ML302+, highlighting 3.5mm AUX and RCA audio out jacks.

പ്രവർത്തന നിർദ്ദേശങ്ങൾ

ട്രാൻസ്മിറ്റർ (TX) മോഡ് പ്രവർത്തനം

In TX mode, the ML302+ sends audio from your non-Bluetooth device to Bluetooth headphones or speakers.

1. Ensure the ML302+ is switched to "TX" mode and connected to your audio source's AUDIO OUT port.
2. Pairing the First Bluetooth Headphone/Speaker:
   • Press and hold the Bluetooth button #1 (labeled with a headphone icon) on the ML302+ for 2 seconds to enter pairing mode. The LED will flash red and blue.
   • Put your Bluetooth headphones/speaker into pairing mode (refer to your headphone/speaker manual for specific instructions).
   • Once successfully paired, the LED on the ML302+ for button #1 will stay solid blue.
3. Pairing the Second Bluetooth Headphone/Speaker (Optional):
   • Press and hold the Bluetooth button #2 (labeled with a headphone icon) on the ML302+ for 2 seconds to enter pairing mode. The LED will flash red and blue.
   • Put your second Bluetooth headphones/speaker into pairing mode.
   • Once successfully paired, the LED on the ML302+ for button #2 will stay solid blue.
4. Audio from your source device will now be transmitted to your connected Bluetooth headphones/speakers.

Image: A person watching TV with Bluetooth headphones connected via the ML302+, demonstrating aptX Low Latency for synchronized audio.

Image: Two people sharing audio from a tablet to two pairs of Bluetooth headphones, illustrating the dual connection feature in TX mode.

റിസീവർ (RX) മോഡ് പ്രവർത്തനം

In RX mode, the ML302+ receives audio from your Bluetooth-enabled device (e.g., smartphone) and plays it through wired speakers or a car stereo.

1. Ensure the ML302+ is switched to "RX" mode and connected to your wired audio system's AUDIO IN port.
2. Pairing with your Smartphone/Tablet:
   • The ML302+ will automatically enter pairing mode in RX mode (LED flashes red and blue).
   • On your smartphone or tablet, go to Bluetooth settings and search for "ML302+". Select it to connect.
   • Once successfully paired, the LED on the ML302+ will stay solid blue.
3. You can now stream audio wirelessly from your smartphone/tablet to your wired audio system.

Image: A family enjoying music through a wired speaker connected to the ML302+ in RX mode, streaming from a mobile device.

വോളിയം നിയന്ത്രണം

The ML302+ features dedicated volume control buttons. Use the '+' button to increase volume and the '-' button to decrease volume. For optimal sound, it is recommended to set the volume on the ML302+ to maximum and control the final output volume from your connected headphones/speakers or source device.

Official Product Video: How to use ML302+ to connect Bluetooth headphone to TV

മെയിൻ്റനൻസ്

To ensure the longevity and optimal performance of your 1Mii ML302+ adapter, follow these maintenance guidelines:

• വൃത്തിയാക്കൽ: Use a soft, dry cloth to clean the device. Avoid using abrasive cleaners, solvents, or strong chemicals, as they may damage the surface or internal components.
• സംഭരണം: ദീർഘനേരം ഉപയോഗിക്കാത്തപ്പോൾ, നേരിട്ടുള്ള സൂര്യപ്രകാശത്തിൽ നിന്നും കടുത്ത താപനിലയിൽ നിന്നും മാറി തണുത്തതും വരണ്ടതുമായ സ്ഥലത്ത് ഉപകരണം സൂക്ഷിക്കുക.
• കൈകാര്യം ചെയ്യൽ: Handle the device with care. Avoid dropping it or subjecting it to strong impacts, which can cause internal damage.
• ചാർജിംഗ്: Only use the provided Type-C power cord for charging. Do not use damaged cables or chargers.

ട്രബിൾഷൂട്ടിംഗ്

If you encounter issues with your 1Mii ML302+ adapter, please refer to the following common problems and solutions:

സ്പെസിഫിക്കേഷനുകൾ

വാറൻ്റിയും പിന്തുണയും

1Mii products typically come with a standard manufacturer's warranty. For specific warranty details, technical support, or further assistance, please refer to the official 1Mii webസൈറ്റ് അല്ലെങ്കിൽ അവരുടെ ഉപഭോക്തൃ സേവനവുമായി നേരിട്ട് ബന്ധപ്പെടുക.

You can also refer to the official User Manual (PDF) for additional information: ഉപയോക്തൃ മാനുവൽ (PDF) ഡൗൺലോഡ് ചെയ്യുക
