ENGWE ഫോൾഡിംഗ് 4 വീൽ മൊബിലിറ്റി സ്കൂട്ടർ യൂസർ മാനുവൽ

1. ആമുഖം

Thank you for choosing the ENGWE Folding 4 Wheel Mobility Scooter. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new mobility device. Please read this manual thoroughly before using the scooter to ensure proper understanding and to maximize its lifespan.

This scooter is designed to provide reliable and comfortable mobility for adults and seniors, featuring a robust 250W motor, a 15.5-mile range, and a comfortable, adjustable seat. Its compact and foldable design makes it convenient for transport and storage.

Image 1.1: The ENGWE Folding 4 Wheel Mobility Scooter, showcasing its overall design and features including the front basket and comfortable seat.

2. സുരക്ഷാ മാർഗ്ഗനിർദ്ദേശങ്ങൾ

Your safety is paramount. Adhere to the following guidelines to prevent injury or damage to the scooter.

• ഭാരം ശേഷി: Do not exceed the maximum weight capacity of 265 lbs (120 kg). Overloading can compromise stability and performance.
• Slope Safety: The scooter is equipped with a slope safety mechanism. Its default state is "parked" to ensure it remains motionless on inclines or declines when not actively driven. Always exercise caution on slopes.
• Anti-Roll Wheels: The design includes anti-roll wheels above the rear wheels to prevent backward tipping.
• ഭൂപ്രദേശം: The 8-inch solid tires and 5.5 inches of ground clearance allow for stable performance on various terrains such as grass, damaged concrete, and rocky roads. However, avoid excessively rough or uneven surfaces.
• പ്രവർത്തനം: Always operate the scooter with both hands on the handlebars and maintain a stable posture.
• യാത്രയ്ക്ക് മുമ്പുള്ള പരിശോധന: Before each use, inspect the tires, brakes, and battery level.
• പരിസ്ഥിതി വ്യവസ്ഥകൾ: Avoid operating the scooter in heavy rain, snow, or extreme temperatures.

Image 2.1: The scooter demonstrating its capability on different surfaces including cobbled roads, speed bumps, lawns, and gravel roads, highlighting its robust design for varied environments.

3. ഉൽപ്പന്ന ഘടകങ്ങൾ

Familiarize yourself with the main components of your ENGWE Mobility Scooter:

• Handlebar and Control Panel: Located at the front, includes speed adjustment, battery indicator, ON/OFF switch, forward/reverse controls, headlight switch, and horn.
• ക്രമീകരിക്കാവുന്ന സീറ്റ്: Features a comfortable, upholstered faux leather cushion that can swivel 360° for easy boarding and alighting. Dimensions: 18.5"L x 17.7"W x 15.8"H.
• കൈത്തണ്ടകൾ: Adjustable for user comfort.
• ഫ്രണ്ട് ബാസ്‌ക്കറ്റ്: Detachable for convenient storage of personal items.
• ഹെഡ്ലൈറ്റ്: Integrated for improved visibility.
• മോട്ടോർ: 250W electric motor.
• ബാറ്ററി: 24V 12Ah battery, providing a range of up to 15.5 miles.
• ചക്രങ്ങൾ: Four 8-inch solid tires for stability and durability.

ചിത്രം 3.1: വിശദമായത് view of the scooter's dimensions and adjustable features, including the seat height, handlebar angle, and overall length, illustrating its ergonomic design.

Image 3.2: Comparison showing the upgraded seat cushion, which is bigger, thicker, and wider (18.5" x 17.7" x 15.8") for enhanced comfort compared to the previous version.

4. സജ്ജീകരണവും അസംബ്ലിയും

The ENGWE Mobility Scooter is designed for straightforward assembly. Follow these steps to prepare your scooter for use:

1. Adjust Handlebar Angle: Unfold the handlebar and adjust it to a comfortable operating angle. Ensure it is securely locked in place.
2. Install Battery Enclosure: Place the battery enclosure into its designated compartment on the scooter's base.
3. സീറ്റ് ഇൻസ്റ്റാൾ ചെയ്യുക: Mount the seat onto the scooter's base. Ensure it clicks securely into place and can swivel freely.
4. Install the Basket: Attach the detachable front basket to the handlebar post.

After assembly, ensure all connections are secure and the scooter is stable before initial operation.

Image 4.1: Visual guide illustrating the four simple steps required to complete the assembly of the scooter: adjusting the handlebar, installing the battery enclosure, installing the seat, and attaching the basket.

5. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

Operating your ENGWE Mobility Scooter is intuitive. Follow these instructions for a safe and enjoyable ride.

5.1. നിയന്ത്രണ പാനൽ ഓവർview

Image 5.1: Diagram of the scooter's control panel, highlighting the speed adjustment knob, battery life indicator, ON/OFF switch, forward/backward controls, high beam headlight button, and horn button.

• ഓൺ/ഓഫ് സ്വിച്ച്: Press to power the scooter on or off.
• Speed Adjustment Knob: Rotate to adjust the maximum speed. The scooter has a top speed of 6.2 mph.
• ബാറ്ററി ലൈഫ് ഇൻഡിക്കേറ്റർ: A color-coded display shows the current battery status. Ensure sufficient charge before long trips.
• Forward/Reverse Controls: Use the levers on the left and right to control forward and reverse motion.
• High Beam Headlight: Press the button to turn the front headlight on or off for visibility.
• കൊമ്പ്: Press the button to sound the horn for alerting others.

5.2. ഡ്രൈവിംഗ്

• Once powered on, gently press the forward lever to begin moving. Release the lever to slow down and stop.
• To reverse, gently press the reverse lever.
• Steer by turning the handlebar.
• The scooter has a rated range of 15.5 miles per charge, suitable for daily trips and errands.

Image 5.2: Infographic highlighting key performance metrics: 15.5 miles range, 250W motor, and 15° climbing capability, ensuring a worry-free riding experience.

6. പരിപാലനം

പതിവ് അറ്റകുറ്റപ്പണികൾ നിങ്ങളുടെ സ്കൂട്ടറിന്റെ ദീർഘായുസ്സും മികച്ച പ്രകടനവും ഉറപ്പാക്കുന്നു.

• ബാറ്ററി കെയർ: Charge the battery fully after each use, especially if it will be stored for an extended period. Avoid completely draining the battery.
• വൃത്തിയാക്കൽ: പരസ്യം ഉപയോഗിച്ച് സ്കൂട്ടർ തുടയ്ക്കുകamp cloth. Avoid using harsh chemicals or abrasive cleaners. Do not spray water directly onto electrical components.
• ടയർ പരിശോധന: Regularly check the 8-inch solid tires for wear and tear. While solid tires do not require air pressure checks, inspect for any damage.
• പൊതു പരിശോധന: Periodically check all nuts, bolts, and fasteners to ensure they are tight. Inspect cables and connections for any signs of damage.
• സംഭരണം: When not in use, store the scooter in a dry, cool place, away from direct sunlight and extreme temperatures. The scooter folds compactly for easy storage (40.55"L x 19.68"W x 18.89"H).

Image 6.1: The ENGWE Mobility Scooter folded and stored in the trunk of an SUV, demonstrating its compact size and ease of transport, making it a perfect travel companion.

7. പ്രശ്‌നപരിഹാരം

This section addresses common issues you might encounter with your scooter. For problems not listed here, please contact customer support.

8 സ്പെസിഫിക്കേഷനുകൾ

Key technical specifications for the ENGWE Folding 4 Wheel Mobility Scooter:

9. വാറണ്ടിയും ഉപഭോക്തൃ പിന്തുണയും

മികച്ച ഉപഭോക്തൃ സേവനം നൽകുന്നതിൽ ENGWE പ്രതിജ്ഞാബദ്ധമാണ്.

• വാറൻ്റി: Your mobility scooter comes with a 1 വർഷത്തെ വാറൻ്റി from the date of purchase. This warranty covers manufacturing defects under normal use. Please retain your proof of purchase.
• ഞങ്ങളെ സമീപിക്കുക: If you encounter any problems, have questions, or require assistance, please do not hesitate to contact our customer support team. We aim to reply within 24 hours and resolve issues as quickly as possible.

For support, please refer to the contact information provided with your purchase documentation or visit the official ENGWE webസൈറ്റ്.
