ആമുഖം
The Ring Outdoor Cam Pro, Plug-In, is a high-definition security camera designed for outdoor use at homes and businesses. It provides advanced surveillance features to help monitor your property effectively.
- Retinal 4K Video: Capture clear video footage with 4K resolution.
- 10x Enhanced Zoom: Magnify details in your video feed.
- Low-Light Sight: Experience true color video in low ambient light and crisp black-and-white in total darkness.
- 3D Motion Detection: Receive precise alerts based on radar-powered motion detection.
- ദ്വിമുഖ സംസാരം: Communicate with visitors or deter intruders using the built-in speaker and microphone.
- കാലാവസ്ഥ പ്രതിരോധം: Designed for outdoor installation in various weather conditions.
ബോക്സിൽ എന്താണുള്ളത്
ഇൻസ്റ്റാളേഷൻ ആരംഭിക്കുന്നതിന് മുമ്പ് എല്ലാ ഘടകങ്ങളും നിലവിലുണ്ടെന്ന് ഉറപ്പാക്കുക:
- Ring Outdoor Cam Pro, Plug-In (2nd Gen)
- Outdoor/Indoor Power Adapter (USB-C, 17.8-ft.)
- ഇൻസ്റ്റലേഷൻ ഹാർഡ്വെയർ
- സജ്ജീകരണ ഗൈഡ്
- Warranty and Safety Document
- സുരക്ഷാ സ്റ്റിക്കർ
സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും
The estimated installation time for the Ring Outdoor Cam Pro is approximately 10 minutes. This camera requires a standard power outlet and can be mounted on a vertical or horizontal surface.
പവർ ആവശ്യകതകൾ
The camera is powered by the included USB-C 17.8-ft. (5.45-m.) 20W Outdoor/Indoor Power Adapter. This is a plug-in only model and does not support battery operation.
കണക്റ്റിവിറ്റി
The camera connects via Wifi 6 (802.11ax) with dual-band support for 2.4GHz and 5.0GHz networks. A recommended minimum upload speed of 15 Mbps is advised for optimal performance. Video resolution may vary based on internet bandwidth.
മൗണ്ടിംഗ് ഓപ്ഷനുകൾ
The Ring Outdoor Cam Pro offers flexible mounting options for various outdoor locations. Ensure the camera is positioned to cover the desired area.
Image: Easy plug-in installation of the Ring Outdoor Cam Pro. The camera is being connected to its power adapter on an exterior wall.
Image: Flexible mounting options for the Ring Outdoor Cam Pro, including tabletop, wall, and ceiling installations, along with its dimensions (2.76 in width, 5.72 in height).
പ്രവർത്തന നിർദ്ദേശങ്ങൾ
Once installed and connected to the Ring app, your Outdoor Cam Pro provides comprehensive security monitoring.
വീഡിയോ നിരീക്ഷണം
The camera records in 4K video resolution, offering a 140° horizontal and 85° vertical field of view. Utilize the 10x Enhanced Zoom to focus on specific areas within the video feed.
Image: The Ring Outdoor Cam Pro mounted on an exterior wall, highlighting its design and 4K video capability.
Image: A demonstration of the 10x Enhanced Zoom feature, showing a zoomed-in view of a person's face from a wider outdoor camera perspective.
നൈറ്റ് വിഷൻ
With Low-Light Sight, the camera provides true color video in dimly lit conditions. In complete darkness, it automatically switches to crisp black-and-white night vision to maintain clear detail.
Image: A split image demonstrating Adaptive Night Vision, showing a dark scene on the left and the same scene with a person clearly visible in black-and-white night vision on the right.
മോഷൻ ഡിറ്റക്ഷനും അലേർട്ടുകളും
The camera features radar-powered 3D Motion Detection, allowing for customizable motion zones. This helps in receiving precise alerts to your phone, reducing false alarms.
Image: A smartphone displaying the Ring app interface, showing how to set up 3D Motion Detection zones on a map of the monitored area.
Two-Way Talk and Siren
Engage in real-time conversations using the Two-Way Talk feature with Audio+ and advanced noise cancellation. A remote-activated security siren is also available for deterring unwanted activity.
മെയിൻ്റനൻസ്
To ensure optimal performance and longevity of your Ring Outdoor Cam Pro, follow these maintenance guidelines:
- ലെൻസ് ക്ലീനിംഗ്: ക്യാമറ ലെൻസ് ഇടയ്ക്കിടെ മൃദുവായ, ഡി-ടച്ച് ഉപയോഗിച്ച് വൃത്തിയാക്കുക.amp cloth to remove dust, dirt, or smudges that may affect video clarity.
- പവർ കണക്ഷൻ: Regularly check the power adapter and cable for any signs of damage or loose connections. Ensure the plug is securely seated in the outlet.
- വൈഫൈ സിഗ്നൽ: Monitor your Wi-Fi signal strength through the Ring app to ensure a stable connection. Poor signal can lead to interrupted video feeds or missed alerts.
- പരിസ്ഥിതി വ്യവസ്ഥകൾ: The camera is weather-resistant and designed to operate between -5°F to 120°F (-20.5°C to 48.5°C). In extreme heat and direct sunlight, the camera may temporarily turn off to prevent overheating. Ensure proper ventilation around the camera if possible.
- സോഫ്റ്റ്വെയർ അപ്ഡേറ്റുകൾ: Keep the Ring app and camera firmware updated to benefit from the latest features and security enhancements.
ട്രബിൾഷൂട്ടിംഗ്
If you encounter issues with your Ring Outdoor Cam Pro, refer to the following common troubleshooting steps:
- ക്യാമറ ഓഫ്ലൈൻ:
- Check the power connection to ensure the camera is receiving power.
- Verify your Wi-Fi network is operational and the signal strength is adequate.
- Try power cycling the camera by unplugging it for a few seconds and then plugging it back in.
- Ensure your router is within range and not obstructed.
- മോശം വീഡിയോ നിലവാരം:
- Confirm your internet upload speed meets the recommended minimum of 15 Mbps.
- ക്യാമറ ലെൻസിൽ എന്തെങ്കിലും തടസ്സങ്ങളോ പാടുകളോ ഉണ്ടോ എന്ന് വൃത്തിയാക്കുക.
- Video quality can be affected by internet bandwidth and device temperature.
- മോഷൻ ഡിറ്റക്ഷൻ പ്രശ്നങ്ങൾ:
- Review your 3D Motion Detection zone settings in the Ring app to ensure they cover the desired areas.
- Adjust motion sensitivity settings if you are receiving too many or too few alerts.
- ഓഡിയോ പ്രശ്നങ്ങൾ:
- Ensure the microphone and speaker settings are enabled in the Ring app.
- Check for any physical obstructions around the microphone or speaker.
- Environmental factors like strong winds can affect audio clarity.
- Camera Not Mounting Correctly:
- Ensure you are using the provided installation hardware.
- The camera is designed for vertical or horizontal surface mounting.
സ്പെസിഫിക്കേഷനുകൾ
| അളവുകൾ | 2.8 in x 5.7 in x 2.8 in (7 cm x 14.5 cm x 7 cm) including stand base and universal mounting plate |
| ലഭ്യമായ നിറങ്ങൾ | കറുപ്പ്, വെള്ള |
| വീഡിയോ | 4K video resolution, Low-Light Sight, up to 10x Enhanced Zoom |
| മോഷൻ ഡിറ്റക്ഷൻ | 3D Motion Detection with Customizable Motion Zones |
| ഫീൽഡ് View | 140° തിരശ്ചീനം, 85° ലംബം |
| ഓഡിയോ | Two-Way Talk with Audio+ and advanced noise cancellation |
| സൈറൺ | റിമോട്ട് ഉപയോഗിച്ച് പ്രവർത്തിപ്പിക്കാവുന്ന സുരക്ഷാ സൈറൺ |
| ശക്തി | USB-C 17.8-ft. (5.45-m.) 20W Outdoor/Indoor Power Adapter |
| ഇൻ്റർനെറ്റ് ആവശ്യകതകൾ | Recommended minimum upload speed of 15 Mbps for optimal performance. Video resolution may vary depending on internet bandwidth. |
| കണക്റ്റിവിറ്റി | Wifi 6 (802.11ax), Dual-band wifi connection @ 2.4GHz, 5.0GHz |
| Estimated Install Time | 10 മിനിറ്റ് |
| പ്രവർത്തന വ്യവസ്ഥകൾ | -5°F to 120°F (-20.5°C to 48.5°C), Weather Resistant. Camera may temporarily turn off when exposed to direct sunlight in extreme heat conditions. |
| സജ്ജീകരണ ആവശ്യകത | Vertical or horizontal surface for mounting, Standard power outlet |
വാറൻ്റി വിവരങ്ങൾ
The Ring Outdoor Cam Pro, Plug-In, comes with a 1 വർഷത്തെ പരിമിത വാറൻ്റി.
ഞങ്ങളുടെ ഉപകരണത്തിൽ ഒരു പുതിയ യൂണിറ്റായി വാങ്ങുന്നതിന് ഉപകരണം അവസാനമായി ലഭ്യമായി കുറഞ്ഞത് നാല് വർഷമെങ്കിലും കഴിഞ്ഞ് ഈ ഉപകരണത്തിന് ഗ്യാരണ്ടീഡ് സോഫ്റ്റ്വെയർ സുരക്ഷാ അപ്ഡേറ്റുകൾ ലഭിക്കും websites. For specific information regarding your device's software security updates, visit the Software Security Updates section in the Ring Control Center.
പിന്തുണ
For further assistance, detailed guides, or to contact customer support, please visit the official Ring support website. You can also access additional resources through the Ring app.
