ആമുഖം
The 1Mii SafeFly Dot is a versatile Bluetooth 5.3 transmitter and receiver designed to bring wireless audio capabilities to a wide range of devices. Whether you want to stream audio from non-Bluetooth sources like TVs or airplane entertainment systems to your wireless headphones, or connect your smartphone to wired speakers, the SafeFly Dot offers a seamless and high-quality audio experience. Its compact design, long battery life, and support for various audio codecs make it an ideal companion for travel, home entertainment, and daily use.
പ്രധാന സവിശേഷതകൾ
- ബ്ലൂടൂത്ത് 5.3 സാങ്കേതികവിദ്യ: Supports 6 decoding formats including SBC, AAC, aptX, aptX-Low Latency, aptX-HD, and aptX-Adaptive for extensive compatibility and exceptional audio.
- Intuitive Indicator Panel: Easily identify current connection mode, audio codec, paired devices, and battery level through various light effects.
- പോർട്ടബിൾ ഡിസൈൻ: Lightweight and convenient to carry, includes a two-prong airplane adapter for international travel.
- aptX Low Latency & HD: Ensures synchronized audio and video for gaming/binge-watching and high-quality music. (Note: Your Bluetooth device should also support aptX-LL/aptX-HD).
- 2-in-1 Transmitter & Receiver: Functions as both a TX (Transmitter) to stream audio from non-Bluetooth devices to Bluetooth headphones/speakers, and an RX (Receiver) to connect smartphones to wired audio systems.
- ബിൽറ്റ്-ഇൻ മൈക്രോഫോൺ: Supports hands-free calling in RX mode. (Note: Phone calls are not supported in TX mode).
- വിപുലീകരിച്ച ബാറ്ററി ലൈഫ്: Up to 25 hours of continuous music playback on a 2-hour charge.
- വോളിയം നിയന്ത്രണം: Conveniently adjust audio volume to the appropriate level.
ഉൽപ്പന്നം കഴിഞ്ഞുview
Familiarize yourself with the components and controls of the 1Mii SafeFly Dot.
Figure 1: 1Mii SafeFly Dot Product Diagram and Included Accessories.
- Flexible Audio Cable: Integrated 3.5mm audio connection.
- TX/OFF/RX Switch: Toggles between Transmitter mode, Power Off, and Receiver mode.
- P/R (Pair/Reset) Button: Used for pairing new devices or resetting connections.
- ബാറ്ററി സൂചകം: ശേഷിക്കുന്ന ബാറ്ററി ലൈഫ് പ്രദർശിപ്പിക്കുന്നു.
- Device A/B Indicators: Show which paired device is currently connected.
- Codec Indicators (APTX, LL, HD, AD, AAC, SBC): Light up to show the active audio codec.
- Multi-function Button (M): Controls playback (play/pause) and call management.
- Volume Up (+) / Next Track Button: Increases volume and skips to the next track.
- Volume Down (-) / Previous Track Button: Decreases volume and goes to the previous track.
- മൈക്രോഫോൺ: Built-in for hands-free calling in RX mode.
- ടൈപ്പ്-സി ചാർജിംഗ് പോർട്ട്: ഉപകരണം ചാർജ് ചെയ്യുന്നതിനായി.
ഉൾപ്പെടുത്തിയ ആക്സസറികൾ: Audio Plug Protector, Charging Cable (USB-C), 3.5mm Audio Female Plug, Dual 3.5mm Male to Female Adapter (airplane adapter), User Manual.
സജ്ജീകരണവും പ്രവർത്തനവും
ഉപകരണം ചാർജ് ചെയ്യുന്നു
The SafeFly Dot features a built-in rechargeable battery providing up to 25 hours of continuous music playback. To charge the device, connect the provided USB-C cable to the charging port on the SafeFly Dot and the other end to a USB power source (e.g., computer USB port, wall adapter). A full charge typically takes about 2 hours. The battery indicator lights on the device will show the charging progress and current battery level.
Figure 2: Battery life and charging indication.
Transmitter (TX) Mode Setup
In Transmitter (TX) mode, the SafeFly Dot streams audio wirelessly from non-Bluetooth devices to your Bluetooth headphones or speakers.
- TX മോഡിലേക്ക് മാറുക: Slide the TX/OFF/RX switch to the 'TX' position. The TX LED will quickly flash red-blue, indicating it's in pairing mode.
- ഓഡിയോ ഉറവിടത്തിലേക്ക് കണക്റ്റുചെയ്യുക: Plug the 3.5mm audio cable from the SafeFly Dot into the audio output jack of your non-Bluetooth device (e.g., TV, computer, airplane entertainment system, gym equipment). For airplane use, utilize the included two-prong adapter if necessary.
- ബ്ലൂടൂത്ത് ഹെഡ്ഫോണുകൾ/സ്പീക്കറുകൾ എന്നിവയുമായി ജോടിയാക്കുക: Set your Bluetooth headphones or speakers to pairing mode. Place them close to the SafeFly Dot. The SafeFly Dot will automatically search for and connect to nearby Bluetooth devices. Once connected, the indicator light for the paired device (A or B) will turn solid blue.
- ഇരട്ട കണക്ഷൻ: To connect a second pair of Bluetooth headphones/speakers, ensure the first device is already connected. Put the second device into pairing mode. Press and hold the P/R (Pair/Reset) button on the SafeFly Dot for 2 seconds. The TX LED will flash red-blue again. Once the second device is connected, its indicator light will also turn solid blue.
Figure 3: Transmitter (TX) Mode Diagram.
Figure 4: Using SafeFly Dot for in-flight entertainment.
Figure 5: Dual connection in TX mode for shared listening.
Video 1: Demonstration of the 1Mii Bluetooth airplane adapter connecting to two AirPods or headphones for in-flight use.
Receiver (RX) Mode Setup
In Receiver (RX) mode, the SafeFly Dot allows your smartphone or tablet to connect wirelessly to wired headphones, speakers, or car/home stereo systems.
- RX മോഡിലേക്ക് മാറുക: Slide the TX/OFF/RX switch to the 'RX' position. The RX LED will quickly flash red-blue, indicating it's in pairing mode.
- Connect to Audio Output Device: Plug the 3.5mm audio cable from the SafeFly Dot into the audio input jack of your wired headphones, speakers, car stereo, or home stereo.
- Pair with Smartphone/Tablet: On your smartphone or tablet, go to Bluetooth settings and search for 'SafeFly Dot'. Select it to connect. Once connected, the indicator light for the paired device (A or B) will turn solid blue.
- ഇരട്ട കണക്ഷൻ: To connect a second smartphone or tablet, ensure the first device is already connected. Put the second device into Bluetooth pairing mode. Press and hold the P/R (Pair/Reset) button on the SafeFly Dot for 2 seconds. The RX LED will flash red-blue again. Once the second device is connected, its indicator light will also turn solid blue.
Figure 6: Receiver (RX) Mode Diagram.
Figure 7: Using SafeFly Dot for hands-free calling in RX mode.
പൊതുവായ പ്രവർത്തന നിർദ്ദേശങ്ങൾ
- മോഡ് സ്വിച്ചിംഗ്: The TX/OFF/RX switch on the side of the device allows you to easily switch between Transmitter (TX) mode, Receiver (RX) mode, or power off the device.
- Pairing/Reset Button (P/R): Press and hold the P/R button for 2 seconds to enter pairing mode for a new device or to pair a second device. A quick press can also reset the connection.
- വോളിയം നിയന്ത്രണം: Use the '+' button to increase volume and the '-' button to decrease volume. These buttons also function as next/previous track controls when briefly pressed.
- Multi-function Button (M): The 'M' button can be used for various functions depending on the mode, such as play/pause or answering/ending calls.
- ബിൽറ്റ്-ഇൻ മൈക്രോഫോൺ: In RX mode, the built-in microphone enables hands-free calling. Note that phone calls are only supported in RX mode, not in TX mode.
- Indicator Panel: The indicator panel provides visual feedback on the device's status:
- TX/RX LEDs: Indicate the current operating mode.
- A/B LEDs: Show which paired device (first or second) is active.
- APTX/LL/HD/AD/AAC/SBC LEDs: Indicate the active audio codec.
- ബാറ്ററി സൂചകം: നിലവിലെ ബാറ്ററി നില പ്രദർശിപ്പിക്കുന്നു.
മെയിൻ്റനൻസ്
To ensure the longevity and optimal performance of your 1Mii SafeFly Dot, follow these maintenance guidelines:
- ഉപകരണം വരണ്ടതായി സൂക്ഷിക്കുക. ഈർപ്പം, മഴ, ദ്രാവകങ്ങൾ എന്നിവയിൽ സമ്പർക്കം പുലർത്തുന്നത് ഒഴിവാക്കുക.
- ഉപകരണം തീവ്രമായ താപനിലയിൽ (ചൂടോ തണുപ്പോ) തുറന്നുകാട്ടരുത്.
- മൃദുവായതും ഉണങ്ങിയതുമായ തുണി ഉപയോഗിച്ച് ഉപകരണം വൃത്തിയാക്കുക. കഠിനമായ രാസവസ്തുക്കളോ ഉരച്ചിലുകളുള്ള ക്ലീനറുകളോ ഉപയോഗിക്കരുത്.
- ഉപയോഗത്തിലില്ലാത്തപ്പോൾ തണുത്തതും ഉണങ്ങിയതുമായ സ്ഥലത്ത് ഉപകരണം സൂക്ഷിക്കുക.
- ശക്തമായ ആഘാതങ്ങൾക്ക് ഉപകരണം ഇടുകയോ ഇടുകയോ ചെയ്യുന്നത് ഒഴിവാക്കുക.
ട്രബിൾഷൂട്ടിംഗ്
If you encounter issues with your SafeFly Dot, refer to the following common problems and solutions:
| പ്രശ്നം | സാധ്യമായ കാരണം | പരിഹാരം |
|---|---|---|
| ഓഡിയോ ഔട്ട്പുട്ട്/ഇൻപുട്ട് ഇല്ല. | Incorrect mode, loose connection, low volume. | Ensure the device is in the correct TX or RX mode. Check that all 3.5mm audio connections are secure. Verify volume levels on both the SafeFly Dot and the connected audio device/headphones. |
| ഒരു ബ്ലൂടൂത്ത് ഉപകരണവുമായി ജോടിയാക്കാൻ കഴിയില്ല. | SafeFly Dot not in pairing mode, device too far, interference. | Ensure the SafeFly Dot's TX or RX LED is flashing red-blue (pairing mode). Place the Bluetooth device close to the SafeFly Dot. Turn off other Bluetooth devices nearby to reduce interference. Try resetting both devices. |
| Audio latency (delay). | Connected device does not support aptX Low Latency. | For minimal delay, ensure both the SafeFly Dot and your Bluetooth headphones/speakers support aptX Low Latency (aptX-LL). If not, audio will default to another codec with higher latency. |
| മോശം ഓഡിയോ നിലവാരം. | Interference, low-quality codec, source audio issue. | Ensure there are no significant obstructions or strong interference sources. Verify that both devices support high-quality codecs like aptX-HD. Test with a different audio source. |
| Phone calls not working. | Device in TX mode, incorrect connection. | The built-in microphone and call function are only available in RX mode. Ensure your phone is connected to the SafeFly Dot in RX mode. |
സ്പെസിഫിക്കേഷനുകൾ
| ഫീച്ചർ | വിശദാംശങ്ങൾ |
|---|---|
| ഉൽപ്പന്ന അളവുകൾ | 2.17 x 1.26 x 0.51 ഇഞ്ച് |
| ഇനത്തിൻ്റെ ഭാരം | 2.39 ഔൺസ് |
| മോഡൽ നമ്പർ | SafeFly Dot |
| ബാറ്ററികൾ | 2 LR44 ബാറ്ററികൾ ആവശ്യമാണ് (ഉൾപ്പെടുന്നു) |
| വയർലെസ് കമ്മ്യൂണിക്കേഷൻ സ്റ്റാൻഡേർഡ് | ബ്ലൂടൂത്ത് 5.3 |
| പവർ ഉറവിടം | ബാറ്ററി പവർ |
| നിറം | വെള്ള |
| അനുയോജ്യമായ ഉപകരണങ്ങൾ | Television, Airplane, PC, Tablet, Laptop, Gym, MP3 Player, Headphone, Speaker, Car/Home Stereo System, Smartphone |
വാറൻ്റിയും പിന്തുണയും
For warranty information, technical support, or further assistance with your 1Mii SafeFly Dot, please refer to the official 1Mii website or contact 1Mii customer service directly. Keep your purchase receipt for warranty claims.
