ആമുഖം
Thank you for choosing the SKINACT Bellage Electric Treatment Table. This versatile and durable electric chair is designed for professional use in spa and medical environments, offering exceptional comfort and adjustability. Equipped with four independent electric motors, it allows for precise positioning of the backrest, leg rest, seat tilt, and overall height, ensuring optimal client comfort and practitioner convenience. This manual provides essential information for the safe and effective setup, operation, and maintenance of your new treatment table.
ചിത്രം 1: ഓവർview of the SKINACT Bellage Electric Treatment Table with key features labeled.
സുരക്ഷാ വിവരങ്ങൾ
Please read all safety warnings and instructions carefully before assembly and operation. Failure to do so may result in injury or damage to the product. Ensure the table is placed on a stable, level surface. Keep hands and loose clothing clear of moving parts during operation. Do not exceed the maximum weight capacity of 350 lbs. Disconnect power before performing any maintenance or cleaning.
സജ്ജമാക്കുക
1. പായ്ക്ക് ചെയ്യലും പ്ലേസ്മെന്റും
- പാക്കേജിംഗിൽ നിന്ന് എല്ലാ ഘടകങ്ങളും ശ്രദ്ധാപൂർവ്വം നീക്കം ചെയ്യുക.
- Place the base of the treatment table on a firm, level floor. Ensure there is sufficient clear space around the table for full range of motion and safe operation.
- Verify all leveling feet on the base are properly adjusted to ensure stability.
2. ഘടകം അസംബ്ലി
- Attach Headrests: The Bellage table comes with two different headrests. Select the appropriate headrest for your procedure and securely attach it to the head section of the table. One headrest includes a breather hole for clients lying face down.
- ആംറെസ്റ്റുകൾ അറ്റാച്ചുചെയ്യുക: Slide the removable armrests into their designated slots on the sides of the main body of the chair.
- Foot Rest Extension: The foot rest section can be extended as needed.
Figure 2: The two interchangeable headrests provided with the table.
3. പവർ കണക്ഷൻ
- Locate the power cord and plug it securely into the power input on the table's base.
- Plug the other end of the power cord into a grounded electrical outlet (100-120 volts, 50-60 hertz).
4. റിമോട്ട് കൺട്രോൾ കണക്ഷൻ
- Connect the remote control cable to the designated port on the underside of the table.
Figure 3: The wired remote control for the Bellage Electric Treatment Table.
സജ്ജീകരണ പ്രകടന വീഡിയോ
Video 1: A demonstration of the Bellage Electric Treatment Table's features and adjustments.
പ്രവർത്തന നിർദ്ദേശങ്ങൾ
The SKINACT Bellage Electric Treatment Table is operated using the wired remote control. Each button on the remote corresponds to a specific motor, allowing for independent adjustment of different sections of the table.
1. പവർ ഓൺ/ഓഫ്
- അമർത്തുക ശക്തി button (usually indicated by a circle with a vertical line) on the remote to turn the table on or off.
2. ഉയരം ക്രമീകരിക്കൽ
- ഉപയോഗിക്കുക മുകളിലേക്ക്/താഴേക്ക് അമ്പടയാളങ്ങൾ associated with the overall table icon to raise or lower the table's height. The height can be adjusted between 25.5 and 31.5 inches.
Figure 4: Electric height adjustment.
3. Adjusting Backrest Angle
- ഉപയോഗിക്കുക മുകളിലേക്ക്/താഴേക്ക് അമ്പടയാളങ്ങൾ associated with the backrest icon to adjust the backrest angle from 0° to 80° incline.
Figure 5: Electric backrest adjustment.
4. Adjusting Leg Rest Angle
- ഉപയോഗിക്കുക മുകളിലേക്ക്/താഴേക്ക് അമ്പടയാളങ്ങൾ associated with the leg rest icon to adjust the leg rest angle from 0° to 85° decline.
Figure 6: Electric leg rest adjustment.
5. Adjusting Bed Tilt Angle
- ഉപയോഗിക്കുക മുകളിലേക്ക്/താഴേക്ക് അമ്പടയാളങ്ങൾ associated with the full bed tilt icon to adjust the entire bed's tilt angle from 0° to 10°.
Figure 7: Electric bed tilt adjustment.
6. Memory Presets (P1, P2, P3)
- The remote control may feature preset buttons (P1, P2, P3) to save and recall preferred positions. Consult the remote's specific instructions for programming these presets.
മെയിൻ്റനൻസ്
Regular maintenance ensures the longevity and optimal performance of your SKINACT Bellage Electric Treatment Table.
- വൃത്തിയാക്കൽ: Wipe the surfaces of the table with a dry cloth. For deeper cleaning, use a mild, non-abrasive cleaner and a soft cloth. Avoid harsh chemicals or abrasive materials that could damage the upholstery or frame.
- പരിശോധന: Periodically inspect all electrical cords, connections, and moving parts for any signs of wear, damage, or loose fittings. If any issues are found, discontinue use and contact customer support.
- ലൂബ്രിക്കേഷൻ: The electric motors and moving mechanisms are generally maintenance-free. Do not attempt to lubricate internal components unless specifically instructed by a qualified technician.
ട്രബിൾഷൂട്ടിംഗ്
If you encounter any issues with your treatment table, refer to the following common troubleshooting steps:
| പ്രശ്നം | സാധ്യമായ കാരണം | പരിഹാരം |
|---|---|---|
| പട്ടിക റിമോട്ട് കൺട്രോളിനോട് പ്രതികരിക്കുന്നില്ല. | No power; Loose connection; Remote control malfunction. | Check if the power cord is securely plugged into the outlet and the table. Ensure the remote control cable is firmly connected. Try a different outlet. If the issue persists, contact customer support. |
| Motor makes unusual noise or movement is jerky. | Obstruction; Motor issue. | Check for any obstructions preventing smooth movement. Ensure the table is not overloaded. Discontinue use and contact customer support if the noise or jerky movement continues. |
| Table is unstable or wobbles. | Uneven floor; Unadjusted leveling feet. | Ensure the table is on a flat, level surface. Adjust the leveling feet on the base until the table is stable. |
സ്പെസിഫിക്കേഷനുകൾ
| ഫീച്ചർ | വിശദാംശങ്ങൾ |
|---|---|
| ബ്രാൻഡ് | ചർമ്മരോഗം |
| മോഡൽ നമ്പർ | SKU164247 |
| മെറ്റീരിയൽ | Metal frame, plastic cover, Foam, PU upholstery |
| നിറം | ഇരുണ്ട ചാരനിറം |
| ഇനത്തിൻ്റെ ഭാരം | 200 പൗണ്ട് |
| ഉൽപ്പന്ന അളവുകൾ (L x W x H) | 68 x 28 x 32 ഇഞ്ച് |
| Length (with headrest) | 76.8 ഇഞ്ച് |
| ഉയരം പരിധി | 25.5 / 31.5 ഇഞ്ച് |
| Width (with armrests) | 35.4 inches (24.8 inches without armrests) |
| ബാക്ക്റെസ്റ്റ് ആംഗിൾ | 0° to 80° incline |
| Bed Tilt Angle | 0° മുതൽ 10° വരെ |
| Leg Rest Angle | 0° to 85° decline |
| പവർ ആവശ്യകതകൾ | 100-120 volts, 50-60 hertz, 200 watts, 2 amp |
| പരമാവധി ഭാരം ശേഷി | 350 പൗണ്ട് |
Figure 8: Detailed dimensions of the treatment table.
വാറൻ്റി & പിന്തുണ
The SKINACT Bellage Electric Treatment Table comes with a ഒരു വർഷത്തെ വാറൻ്റി വാങ്ങിയ തീയതി മുതൽ. സാധാരണ ഉപയോഗത്തിലുള്ള നിർമ്മാണ വൈകല്യങ്ങളും തകരാറുകളും ഈ വാറന്റി ഉൾക്കൊള്ളുന്നു.
For technical support, warranty claims, or any questions regarding your product, please contact SKINACT customer service. Refer to your purchase documentation for specific contact details or visit the official SKINACT webസൈറ്റ്.
