തെറാബോഡി ജെറ്റ്ബൂട്ട്സ് പ്രൈം വയർലെസ് കംപ്രഷൻ ബൂട്ട്സ് യൂസർ മാനുവൽ

1. ആമുഖം

Thank you for choosing the Therabody JetBoots Prime. These ultra-portable, wireless compression boots are designed to provide effective leg muscle recovery through pneumatic compression therapy. This manual provides essential information for the safe and optimal use of your device, including setup, operation, maintenance, and troubleshooting.

2 പ്രധാനപ്പെട്ട സുരക്ഷാ വിവരങ്ങൾ

Please read all safety warnings and instructions before using the JetBoots Prime to prevent injury or damage to the device. Keep this manual for future reference.

• Consult your physician before using this device if you have any medical conditions, including but not limited to, heart conditions, blood clots, open wounds, or recent surgery.
• Do not use the device on swollen, inflamed, or injured areas of the skin.
• വാഹനമോടിക്കുമ്പോഴോ കനത്ത യന്ത്രങ്ങൾ പ്രവർത്തിപ്പിക്കുമ്പോഴോ ഉപകരണം ഉപയോഗിക്കരുത്.
• ഉപകരണം വെള്ളത്തിൽ നിന്നും ഉയർന്ന താപനിലയിൽ നിന്നും അകറ്റി നിർത്തുക.
• നൽകിയിരിക്കുന്ന USB-C ചാർജിംഗ് കേബിൾ മാത്രം ഉപയോഗിക്കുക.
• This device is intended for personal use only and not for medical diagnosis or treatment.

3. എന്താണ് ഉൾപ്പെടുത്തിയിരിക്കുന്നത്

Your Therabody JetBoots Prime package contains the following items:

Image: All items included with your JetBoots Prime purchase.

• 2 Connected JetBoots Prime compression boots
• Drawstring backpack for storage and portability
• USB-C ചാർജിംഗ് കേബിൾ

4. ഉൽപ്പന്നം കഴിഞ്ഞുview

4.1. ഘടകങ്ങൾ

Image: The Therabody JetBoots Prime wireless compression boots.

The JetBoots Prime consist of two compression boots connected by a central unit that houses the control panel and internal pump system. Each boot features multiple overlapping air chambers for consistent compression.

4.2. നിയന്ത്രണ പാനൽ

Image: The integrated control panel for adjusting treatment settings.

The intuitive control panel is built directly into the boots, allowing for easy access to all settings:

• പവർ ബട്ടൺ: ഉപകരണം ഓണും ഓഫും ചെയ്യുന്നു.
• Pressure Level Indicator: Displays the selected pressure level (25, 50, 75, 100 mmHg).
• Time Interval Indicator: Shows the remaining treatment time.
• ആരംഭിക്കുക/താൽക്കാലികമായി നിർത്തുക ബട്ടൺ: Initiates or temporarily stops a compression session.
• ബാറ്ററി സൂചകം: നിലവിലെ ബാറ്ററി ചാർജ് നില കാണിക്കുന്നു.

5. സൈസ് ഗൈഡ്

For optimal performance and comfort, selecting the correct size is crucial. Measure your inseam (from the bottom of the groin to the ankle bone) and refer to the chart below.

Image: Size chart for Therabody JetBoots Prime.

If you are between sizes, it is generally recommended to size down for the best fit.

6. സജ്ജീകരണം

6.1. Charging the JetBoots Prime

Before first use, fully charge your JetBoots Prime. Connect the provided USB-C charging cable to the charging port on the central unit and plug the other end into a compatible USB power adapter (not included). The battery indicator on the control panel will show charging status and full charge.

6.2. Wearing the Boots

Image: User wearing the JetBoots Prime for a recovery session.

1. Unfold the JetBoots Prime completely.
2. Sit down and slide your legs into each boot, ensuring your feet are comfortably positioned at the bottom.
3. Zip up the boots securely along the side of each leg. Ensure the fit is snug but not uncomfortably tight before inflation.

7. ഓപ്പറേഷൻ

7.1. പവർ ഓൺ/ഓഫ്

• To power on, press and hold the Power button on the control panel until the LED indicators illuminate.
• To power off, press and hold the Power button until the LED indicators turn off.

7.2. Selecting Treatment Settings

Once powered on, you can customize your recovery session:

• സമ്മർദ്ദ നിലകൾ: Use the pressure adjustment buttons to cycle through 4 intensity levels: 25, 50, 75, and 100 mmHg. The LED indicator will show the selected level.
• Time Intervals: Use the timer adjustment buttons to select your desired session duration. Options typically include 20, 40, 60 minutes, or an 'infinity' mode for continuous use (up to battery life).

7.3. Starting and Pausing Treatment

• Press the Start/Pause button to begin the compression cycle. The boots will inflate and deflate according to the selected settings.
• To pause a session, press the Start/Pause button again. Press it once more to resume.
• The device will automatically power off once the selected time interval is complete.

7.4. TruGrade Technology

The JetBoots Prime utilize proprietary TruGrade Technology, which delivers precise, science-backed pressure levels tailored to the size of your leg. Four overlapping chambers optimize circulation and facilitate the removal of metabolic waste more effectively than traditional compression systems.

8. പരിപാലനവും പരിചരണവും

Proper care ensures the longevity and hygiene of your JetBoots Prime:

• വൃത്തിയാക്കൽ: The boots are made with medical-grade, non-porous materials. Wipe the interior and exterior surfaces with a damp cloth and mild soap. Do not submerge the device in water.
• ഉണക്കൽ: Allow the boots to air dry completely before folding or storing.
• സംഭരണം: Store the boots in the provided drawstring backpack in a cool, dry place away from direct sunlight.

9. Portability and Storage

The JetBoots Prime are designed for effortless portability, allowing you to recover anywhere.

Image: Folding the JetBoots Prime for storage in the drawstring backpack.

When not in use, fold the boots neatly and place them in the included drawstring backpack. This compact design makes them easy to transport in a gym bag or backpack.

10. പ്രശ്‌നപരിഹാരം

If you encounter issues with your JetBoots Prime, refer to the following common problems and solutions:

• ഉപകരണം ഓണാക്കുന്നില്ല: Ensure the device is fully charged. Connect the USB-C cable and allow it to charge for at least 30 minutes before attempting to power on again.
• Boots not inflating: Check that the boots are zipped up completely and securely. Ensure there are no kinks or obstructions in the air pathways.
• Uneven compression: Verify that both boots are properly worn and zipped. The TruGrade Technology should ensure synchronized inflation; if unevenness persists, contact customer support.
• Device stops during session / Yellow lights appear: This may indicate overheating. Power off the device and allow it to cool down for at least 30 minutes before attempting to use it again. Ensure the device is used in a well-ventilated area.
• നിയന്ത്രണ പാനൽ പ്രതികരിക്കുന്നില്ല: Try resetting the device by powering it off and on again. If the issue persists, ensure the battery is charged.

If these steps do not resolve the issue, please contact Therabody customer support for further assistance.

11 സ്പെസിഫിക്കേഷനുകൾ

12. വാറൻ്റിയും പിന്തുണയും

For warranty information, product registration, and customer support, please visit the official Therabody webസൈറ്റിൽ ബന്ധപ്പെടുകയോ അവരുടെ ഉപഭോക്തൃ സേവന വിഭാഗവുമായി ബന്ധപ്പെടുകയോ ചെയ്യുക. വാറന്റി ക്ലെയിമുകൾക്കായി നിങ്ങളുടെ വാങ്ങിയതിന്റെ തെളിവ് സൂക്ഷിക്കുക.

Statements regarding this device have not been evaluated by the FDA and are not intended to diagnose, treat, cure, or prevent any disease or health condition.
