Champion Power Equipment 11,500-Watt Electric Start Dual Fuel Portable Generator (Model 201302) Instruction Manual

1 സുരക്ഷാ വിവരങ്ങൾ

മുന്നറിയിപ്പ്: കാർബൺ മോണോക്സൈഡ് അപകടം. Generators produce carbon monoxide (CO), a colorless, odorless, poisonous gas. Operating a generator indoors can kill you in minutes. CO Shield technology monitors CO accumulation and automatically shuts off the engine if unsafe levels are detected. However, CO Shield is not a substitute for an indoor carbon monoxide alarm or for safe operation. ALWAYS use the generator outdoors, far away from occupied buildings, with engine exhaust pointed away from people and buildings. DO NOT allow engine exhaust fumes to enter a confined area through windows, doors, vents, or other openings.

മുന്നറിയിപ്പ്: ഇലക്ട്രിക്കൽ ഷോക്ക് ആപത്ത്. Never operate the generator in wet conditions. Ensure all connections are secure and dry. Use ground fault circuit interrupter (GFCI) protected outlets when operating in damp അല്ലെങ്കിൽ നനഞ്ഞ സ്ഥലങ്ങൾ.

മുന്നറിയിപ്പ്: തീപിടുത്തം. Gasoline and propane are highly flammable. Store fuel in approved containers in a well-ventilated area away from ignition sources. Never refuel a hot or running engine. Allow the generator to cool before refueling.

Read and understand the entire instruction manual before operating the generator. Failure to follow instructions can result in serious injury or death.

Figure 1: CO Shield display indicating automatic shutoff and service status.

2. ഉൽപ്പന്നം കഴിഞ്ഞുview

സി.എച്ച്ampion Power Equipment Model 201302 is an 11,500-watt electric start dual fuel portable generator designed for home backup and various projects. It operates on both gasoline and propane, offering versatility and convenience. Equipped with CO Shield technology, Cold Start Technology, and Intelligauge, this generator provides reliable power with enhanced safety features.

ചിത്രം 2: മുൻഭാഗം view of the Champion Power Equipment Model 201302 Portable Generator.

ചിത്രം 3: വശം view of the generator, highlighting its robust frame and wheels.

ചിത്രം 4: വിശദമായ വശം view of the generator's engine and components.

ചിത്രം 5: പിൻഭാഗം view of the generator, showing exhaust and other rear components.

3. സജ്ജീകരണം

3.1 അൺബോക്‌സിംഗും അസംബ്ലിയും

Carefully remove the generator from its packaging. The unit includes a wheel kit, engine oil, oil funnel, and a propane hose with regulator. Attach the wheels and support legs as per the included assembly instructions to ensure stability and mobility.

Figure 6: Included accessories: propane hose, engine oil, and wheel kit for assembly.

3.2 എഞ്ചിൻ ഓയിൽ ചേർക്കുന്നു

Before first use, add the provided 10W-30 engine oil. Locate the oil fill cap/dipstick, remove it, and use the included funnel to slowly pour the oil into the engine until it reaches the upper mark on the dipstick. Do not overfill.

3.3 ബാറ്ററി ബന്ധിപ്പിക്കുന്നു

The generator features an electric start and comes with a battery. Connect the battery terminals following the instructions in the manual, ensuring correct polarity (red to positive, black to negative). This step is crucial for the electric start function.

3.4 ജനറേറ്ററിന് ഇന്ധനം നിറയ്ക്കൽ

This is a dual-fuel generator, capable of running on gasoline or propane.

• ഗ്യാസോലിൻ: Ensure the generator is off and cool. Fill the 7.7-gallon fuel tank with unleaded gasoline (minimum 87 octane). Do not overfill.
• പ്രൊപ്പെയ്ൻ: Connect the provided 6.5-foot propane hose with a built-in regulator to a 20-pound (or larger) propane tank and to the generator's propane inlet. Ensure all connections are tight.

Figure 7: Dual fuel capability of the generator, allowing operation on gasoline or propane.

3.5 Generator Placement

Always operate the generator outdoors in a well-ventilated area. Position it far away from windows, doors, and vents to prevent carbon monoxide from entering occupied buildings. Ensure the exhaust is directed away from people and structures.

3.6 വീഡിയോ ഗൈഡ് സജ്ജീകരിക്കുക

4. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

4.1 കൺട്രോൾ പാനൽ ഓവർview

The generator's control panel features an Intelligauge display, various power outlets, circuit breakers, and the electric start switch. Familiarize yourself with the layout before operation.

Figure 8: Control panel showing the Intelligauge, fuel select dial, ignition switch, and various outlets.

4.2 ജനറേറ്റർ ആരംഭിക്കുന്നു

1. Ensure the generator is placed outdoors and properly fueled.
2. ഇന്ധന വാൽവ് "ഓൺ" സ്ഥാനത്തേക്ക് തിരിക്കുക.
3. Select the desired fuel type (gasoline or propane) using the fuel select dial.
4. For electric start, press and hold the electric start button until the engine starts. For manual start, pull the recoil starter handle firmly.
5. Once started, allow the engine to run for a few moments before connecting loads.

4.3 ബന്ധിപ്പിക്കുന്ന ഉപകരണങ്ങൾ

The generator provides multiple outlets:

• Two 120V 20A GFCI protected household duplex outlets (5-20R).
• One 120/240V 30A locking outlet (L14-30R).
• One 120/240V 38A outlet (L14-50R).

Connect your appliances using appropriate extension cords. Do not overload the generator. Refer to the "Calculating Wattage" section for guidance.

4.4 Monitoring with Intelligauge

The Intelligauge display allows you to monitor voltage, frequency, and run-time hours. This helps in tracking power output and scheduling maintenance.

4.5 ജനറേറ്റർ നിർത്തുന്നു

1. ജനറേറ്ററിൽ നിന്ന് എല്ലാ ഇലക്ട്രിക്കൽ ലോഡുകളും വിച്ഛേദിക്കുക.
2. എഞ്ചിൻ സ്വിച്ച് "ഓഫ്" സ്ഥാനത്തേക്ക് തിരിക്കുക.
3. ഇന്ധന വാൽവ് "ഓഫ്" സ്ഥാനത്തേക്ക് തിരിക്കുക.

4.6 Operating Video Guide

5. പരിപാലനം

Regular maintenance is essential for the longevity and safe operation of your generator. Refer to the maintenance schedule in the full manual for detailed intervals.

• എണ്ണ മാറ്റം: ആദ്യത്തെ 20 മണിക്കൂർ പ്രവർത്തനത്തിനു ശേഷം എഞ്ചിൻ ഓയിൽ മാറ്റുക, പിന്നീട് ഓരോ 100 മണിക്കൂറിലും അല്ലെങ്കിൽ വർഷത്തിലൊരിക്കൽ മാറ്റുക.
• എയർ ഫിൽട്ടർ: Inspect and clean the air filter every 50 hours or more often in dusty conditions. Replace if damaged.
• സ്പാർക്ക് പ്ലഗ്: Inspect the spark plug every 100 hours. Clean or replace as needed.
• ഇന്ധന സംവിധാനം: Drain the fuel tank and carburetor if storing for more than 30 days. Use a fuel stabilizer if storing with fuel.

6. പ്രശ്‌നപരിഹാരം

If your generator experiences issues, consult the following common troubleshooting steps:

• എഞ്ചിൻ ആരംഭിക്കില്ല:
  • Check fuel level (gasoline or propane).
  • Ensure fuel valve is open and correct fuel type is selected.
  • എഞ്ചിൻ ഓയിൽ നില പരിശോധിക്കുക.
  • Verify battery connections for electric start.
  • Check spark plug for fouling or damage.
• പവർ ഔട്ട്പുട്ട് ഇല്ല:
  • Check all circuit breakers on the control panel.
  • Ensure no overload condition exists (reduce connected loads).
  • എല്ലാ കണക്ഷനുകളും സുരക്ഷിതമാണെന്ന് പരിശോധിക്കുക.
• CO Shield Shutoff:
  • Move the generator to an open, outdoor area with good ventilation.
  • Allow the unit to cool down and ventilate the area.
  • Restart the generator after ensuring safe operating conditions.

For persistent issues, contact Champion Power Equipment customer support.

7 സ്പെസിഫിക്കേഷനുകൾ

ചിത്രം 9: ജനറേറ്ററിന്റെ അളവുകളും ഭാരവും.

Figure 10: Guide for calculating running and starting wattage for connected appliances.

8. വാറൻ്റിയും പിന്തുണയും

ഈ സി.എച്ച്ampion Power Equipment generator comes with a 3-year limited warranty. For technical assistance, troubleshooting, or warranty claims, please contact Champion Power Equipment customer support.

ഉപഭോക്തൃ പിന്തുണ: FREE lifetime technical support from dedicated experts.

Refer to the official Champഅയോൺ പവർ ഉപകരണങ്ങൾ website or your purchase documentation for the most up-to-date warranty terms and contact information.
