AUTOPHIX 7610P+ Diagnostic Tool User Manual

ആമുഖം

The AUTOPHIX 7610P+ is a professional diagnostic scan tool specifically designed for Volkswagen, Audi, Skoda, and Seat vehicles. It provides comprehensive system diagnostics and various maintenance reset services, enabling users to identify and resolve vehicle issues efficiently. This manual will guide you through the proper setup, operation, and maintenance of your device.

സജ്ജീകരണവും പ്രാരംഭ ഉപയോഗവും

Follow these steps to prepare your AUTOPHIX 7610P+ for its first use:

1. അൺപാക്ക് ചെയ്യുന്നു: Carefully remove the AUTOPHIX 7610P+ Code Reader and the USB Cable from the packaging.
2. വാഹന കണക്ഷൻ:
   • നിങ്ങളുടെ വാഹനത്തിന്റെ എഞ്ചിൻ പ്രവർത്തിക്കുന്നുണ്ടെന്ന് ഉറപ്പാക്കുക.
   • Locate the OBD2 port in your vehicle. This is typically found under the dashboard on the driver's side.
   • Plug the diagnostic tool's OBD2 connector firmly into the vehicle's OBD2 port. The device will power on automatically.
3. Initial Device Boot-up: The device will display the main menu after powering on.

പ്രവർത്തന നിർദ്ദേശങ്ങൾ

The AUTOPHIX 7610P+ offers various functions accessible through its main menu. Use the navigation buttons (Up, Down, Left, Right, OK, ESC, I/M, READ DTC) to select and confirm options.

1. പൂർണ്ണമായ സിസ്റ്റം രോഗനിർണയം

This function allows for a comprehensive scan of all electronic control units (ECUs) in your vehicle, including Engine, Transmission, ABS, Airbag, and more. It helps identify fault codes across various systems.

1. From the main menu, select "For VW" (or similar option for VAG vehicles).
2. Choose "Full System Scan" or "Diagnosis".
3. The tool will automatically scan all available systems and display any detected fault codes.
4. Review the displayed codes and their descriptions.
5. To clear fault codes after repairs, select the "Erase Fault Codes" option. Note: Fault codes can only be cleared after the underlying issue has been repaired. This scanner does not repair vehicle issues.

2. Maintenance Reset Services

The 7610P+ supports various essential maintenance reset functions. Availability of specific functions may vary by vehicle model and year. Please confirm compatibility for your specific vehicle before performing any service.

• ഓയിൽ റീസെറ്റ്: Resets the oil life monitor after an oil change.
• Battery Registration (BMS Reset): Registers a new battery with the vehicle's ECU to ensure proper charging and system function.
• Electronic Throttle Control (ETC) Reset: Recalibrates the throttle body.
• ഇലക്ട്രോണിക് പാർക്കിംഗ് ബ്രേക്ക് (ഇപിബി) റീസെറ്റ്: Resets the EPB system after brake pad replacement or maintenance.
• ഡീസൽ പാർട്ടിക്കുലേറ്റ് ഫിൽറ്റർ (DPF) പുനരുജ്ജീവനം: Initiates DPF regeneration to clear accumulated soot.
• Steering Angle Learning: സ്റ്റിയറിംഗ് ആംഗിൾ സെൻസർ കാലിബ്രേറ്റ് ചെയ്യുന്നു.
• ഇൻജക്ടർ കോഡിംഗ്: Writes specific parameters of new injectors into the ECU.
• Fuel Pump Activation: Activates the fuel pump for diagnostic checks.
• TPMS റീസെറ്റ്: Re-initializes and calibrates the Tire Pressure Monitoring System.

To perform a reset service:

1. From the main menu, select the desired reset function (e.g., "Oil Reset").
2. Follow the on-screen prompts to complete the procedure.

3. Advanced OBD2 Modes

The tool provides standard OBD2 functions for engine diagnostics, compatible with most 1996 and newer 12V cars and light trucks (non-electric) that are OBD II-compliant with 16-Pin OBD II protocols.

• കോഡുകൾ വായിക്കുക: Retrieves generic (P0, P2, P3, U0) and manufacturer specific (P1, P3, U1) codes.
• മായ്ക്കൽ കോഡുകൾ: Clears Diagnostic Trouble Codes (DTCs) and turns off the Check Engine Light (MIL).
• I/M സന്നദ്ധത: എമിഷൻ മോണിറ്ററിംഗ് സിസ്റ്റങ്ങളുടെ സന്നദ്ധത പരിശോധിക്കുന്നു.
• ഡാറ്റ സ്ട്രീം: Displays live data from the vehicle's sensors in text or graph format.
• വാഹന വിവരം: വാഹന തിരിച്ചറിയൽ നമ്പർ (VIN), കാലിബ്രേഷൻ ഐഡി (CALID), കാലിബ്രേഷൻ വെരിഫിക്കേഷൻ നമ്പർ (CVN) എന്നിവ വീണ്ടെടുക്കുന്നു.
• EVAP സിസ്റ്റം ടെസ്റ്റ്: വാഹനത്തിന്റെ ബാഷ്പീകരണ എമിഷൻ സിസ്റ്റത്തിനായുള്ള ഒരു ലീക്ക് ടെസ്റ്റ് ആരംഭിക്കുന്നു.

പരിപാലനവും അപ്‌ഡേറ്റുകളും

The AUTOPHIX 7610P+ offers lifetime free software updates to ensure compatibility with new vehicle models and to add new features or fix bugs.

1. സോഫ്റ്റ്വെയർ ഡൗൺലോഡ്: Visit the official AUTOPHIX website to download the latest update software for your device.
2. കമ്പ്യൂട്ടർ കണക്ഷൻ: Connect the diagnostic tool to a computer using the provided USB cable. This cable is solely for connecting the device to a computer for software updates or printing diagnostic reports.
3. അപ്‌ഡേറ്റ് പ്രോസസ്സ്: Follow the instructions provided with the update software to install the latest firmware and vehicle databases onto your 7610P+. Ensure the computer meets the minimum system requirements (Windows 7/8/10/11) and that the driver is installed in administrator mode.

ട്രബിൾഷൂട്ടിംഗ്

• ഉപകരണം പവർ ചെയ്യുന്നില്ല:

  Ensure the OBD2 connector is securely plugged into the vehicle's OBD2 port and the vehicle's ignition is on (or engine running). The device draws power directly from the vehicle's OBD2 port.

• ആശയവിനിമയ പിശക്:

  Verify that the vehicle is compatible with the 7610P+ (VW, Audi, Skoda, Seat). Check the OBD2 connection. If the issue persists, try the tool on another compatible vehicle to rule out a vehicle-specific problem. For specific compatibility inquiries, contact AUTOPHIX customer support with your car's brand, model, year, and the specific issue you're experiencing.

• Unable to Clear Fault Codes:

  Fault codes can only be cleared after the underlying mechanical or electrical issue has been resolved. If the problem persists, the code will reappear. This scanner does not repair vehicle issues.
• സോഫ്റ്റ്‌വെയർ അപ്‌ഡേറ്റ് പ്രശ്നങ്ങൾ:

  Ensure the USB cable is properly connected to both the device and the computer. Confirm that the update software is running in administrator mode on a compatible Windows operating system (7, 8, 10, or 11). Check for internet connectivity during the update process.

• Specific Function Not Working:

  Some advanced functions may not be supported on all vehicle models or years. Refer to the vehicle coverage list or contact AUTOPHIX customer support with your vehicle's brand, model, year, and the specific function you are trying to use for confirmation.

സ്പെസിഫിക്കേഷനുകൾ

വാറൻ്റിയും പിന്തുണയും

AUTOPHIX is committed to providing high-quality products and customer satisfaction.

• വാറൻ്റി: Please refer to the product packaging or the official AUTOPHIX webവിശദമായ വാറന്റി വിവരങ്ങൾക്ക് സൈറ്റ്.
• ഉപഭോക്തൃ പിന്തുണ: For technical assistance, compatibility inquiries, or any other questions, please contact AUTOPHIX customer support. Contact details can typically be found on the official AUTOPHIX webസൈറ്റ് അല്ലെങ്കിൽ ഉൽപ്പന്ന ഡോക്യുമെന്റേഷനിൽ.
