1. ഉൽപ്പന്നം കഴിഞ്ഞുview
The BODEGACOOLER 79 Quart Portable Car Refrigerator is a versatile dual-zone electric cooler designed for vehicles, camping, RVs, and outdoor use. It offers precise temperature control, powerful cooling capabilities, and multiple power options to keep your food and beverages chilled or frozen on the go.
Figure 1: BODEGACOOLER 79 Quart Portable Car Refrigerator with dual zones open, showcasing its capacity for various items and the smartphone app control interface.
2 പ്രധാന സവിശേഷതകൾ
- 79 Quart (75L) Large Capacity Dual Zone: Features two independent zones (48QT and 30QT) capable of maintaining temperatures from -4°F to 68°F (-20°C to 20°C). Each zone can be set as a refrigerator or freezer independently.
- Powerful Compressor & Rapid Cooling: Equipped with a turbo-cooled compressor that can rapidly chill the empty fridge to 32°F (0°C) in approximately 15 minutes in MAX mode. Offers up to 24 hours of insulation to maintain temperatures during power loss.
- 3-AXIS Antivibration Engineering & Silent Operation: Designed for stability with 35° incline capability, non-slip polymer dampeners, and a low center of gravity chassis. Operates quietly at less than 45dB, ensuring minimal noise.
- Dual-Path Cooling Modes: Provides "MAX" mode for rapid cooling and "ECO" mode for extended runtime and energy efficiency, suitable for various travel needs.
- ബാറ്ററി സംരക്ഷണം: Incorporates a Triple-Layer H/M/L Voltage Safeguard system that automatically adjusts to prevent battery over-discharge, supporting 10-32V DC input.
- Rugged & Portability: Constructed with a premium silver metallic body for durability and resistance to wear and tear. Features a robust handle and wheels for easy transport, along with LED interior lighting and a convenient bottom drain hole for cleaning.
- APP നിയന്ത്രണം: Allows for convenient temperature monitoring and adjustment via a smartphone application.
ചിത്രം 2: ഓവർview of the BODEGACOOLER's primary features.
Figure 3: Noise level comparison, highlighting the quiet operation of the BODEGACOOLER.
Figure 4: The silver metallic body is designed for reduced heat absorption, enhancing cooling efficiency.
3. സജ്ജീകരണ നിർദ്ദേശങ്ങൾ
3.1 പായ്ക്ക് ചെയ്യലും പ്രാരംഭ പരിശോധനയും
Carefully remove the BODEGACOOLER from its packaging. Inspect the unit for any signs of damage during transit. Ensure all included accessories are present: the 12V car fridge unit, 1 cigarette lighter connector, 1 wall plug, 1 wall plug adapter, and 1 user manual. Before initial use, it is recommended to let the unit stand upright for at least 6 hours to allow the compressor fluids to settle, especially if it was transported horizontally.
3.2 പവർ കണക്ഷൻ
The BODEGACOOLER supports multiple power supply modes:
- 12/24V DC (Car/Truck): Use the provided cigarette lighter connector to power the unit from your vehicle's 12V or 24V DC outlet.
- 100-240V AC (Wall Socket): Use the provided wall plug and adapter to connect the unit to a standard household AC outlet.
- Portable Power Station & Solar Panel: The unit is compatible with portable power stations and can be charged via a solar panel (solar input port available).
Figure 5: Power connection options for the BODEGACOOLER.
4. പ്രവർത്തന നിർദ്ദേശങ്ങൾ
4.1 കൺട്രോൾ പാനൽ ഓവർview
The control panel features a digital display showing current temperatures, battery level, and mode indicators. Buttons are available for power, temperature adjustment (+/-), mode selection (ECO/MAX), and compartment selection (L/R).
Figure 6: The intuitive control panel for manual operation.
4.2 തണുപ്പിക്കൽ പ്രകടനം
The powerful compressor allows for rapid cooling. In MAX mode, the empty refrigerator can reach 32°F (0°C) within approximately 15 minutes, ensuring quick chilling of contents.
Figure 7: Cooling performance graph, demonstrating how quickly the unit reaches desired temperatures.
4.3 താപനില ക്രമീകരണം
To adjust the temperature for a specific compartment:
- Press the 'L' or 'R' button to select the desired compartment. The selected compartment's temperature display will flash.
- Use the '+' or '-' buttons to increase or decrease the temperature.
- The unit will automatically adjust to the new setting.
4.4 Dual Zone Operation
The BODEGACOOLER features two independent compartments. You can set different temperatures for each zone, allowing one to function as a refrigerator and the other as a freezer, or both as either. This flexibility is ideal for diverse storage needs.
ചിത്രം 8: ഉദാamples of dual-zone temperature configurations for different contents.
4.5 ആപ്പ് നിയന്ത്രണം
Download the BODEGACOOLER app on your smartphone to remotely monitor and control the refrigerator. The app allows you to adjust temperatures, switch modes, and check battery status from a distance of up to 32 feet.
Figure 9: Remote control via the BODEGACOOLER smartphone app.
4.6 ബാറ്ററി സംരക്ഷണം
The unit features a three-level battery protection system (H/M/L) to prevent your vehicle's battery from over-discharging. Select the appropriate level based on your battery's condition and usage scenario. The 'L' setting is recommended for older or weaker batteries.
Figure 10: Battery protection settings to prevent over-discharge.
5. പരിപാലനം
5.1 വൃത്തിയാക്കൽ
Regular cleaning is essential for optimal performance. The unit features a convenient bottom drain hole for easy water removal during cleaning. Use a soft cloth and mild detergent to wipe down the interior and exterior surfaces. Avoid abrasive cleaners or harsh chemicals.
5.2 സംഭരണം
When storing the BODEGACOOLER for extended periods, ensure it is clean and dry. Leave the lids slightly ajar to prevent odors and mildew. Store in a cool, dry place away from direct sunlight.
6. പ്രശ്നപരിഹാരം
This section addresses common issues you might encounter with your BODEGACOOLER. For problems not listed here, please contact customer support.
| പ്രശ്നം | സാധ്യമായ കാരണം | പരിഹാരം |
|---|---|---|
| യൂണിറ്റ് ഓണാക്കുന്നില്ല | വൈദ്യുതി ഇല്ല; കണക്ഷൻ നഷ്ടപ്പെട്ടു; ഫ്യൂസ് പൊട്ടി. | Check power source and connections. Ensure the power adapter is securely plugged in. Check the fuse on the unit. |
| അപര്യാപ്തമായ തണുപ്പിക്കൽ | Ventilation blocked; excessive ambient temperature; overloaded compartment; door not sealed properly. | Ensure proper ventilation around the unit. Avoid placing in direct sunlight. Do not overload compartments. Check door seals for proper closure. |
| അസാധാരണമായ ശബ്ദം | യൂണിറ്റ് നിരപ്പല്ല; ആന്തരിക ഘടകങ്ങൾ വൈബ്രേറ്റ് ചെയ്യുന്നു. | Place the unit on a stable, level surface. If noise persists, contact customer support. |
| ആപ്പ് കണക്ഷൻ പ്രശ്നങ്ങൾ | Bluetooth not enabled; unit out of range; app malfunction. | Ensure Bluetooth is active on your device. Move closer to the unit. Restart the app or reinstall if necessary. |
7 സാങ്കേതിക സവിശേഷതകൾ
| സ്പെസിഫിക്കേഷൻ | മൂല്യം |
|---|---|
| ബ്രാൻഡ് | സ്റ്റോർ |
| മോഡൽ | 79 Quart Silver (B0DZCNN436) |
| ശേഷി | 79 ക്വാർട്ട് (75 ലിറ്റർ) |
| താപനില പരിധി | -4°F മുതൽ 68°F വരെ (-20°C മുതൽ 20°C വരെ) |
| വാല്യംtage | 12/24V ഡിസി, 100-240V എസി |
| ഇനത്തിൻ്റെ ഭാരം | 58.3 പൗണ്ട് |
| ഉൽപ്പന്ന അളവുകൾ | 20.59 x 37.56 x 16.3 ഇഞ്ച് |
| ശബ്ദ നില | <45dB |
| വാതിലുകളുടെ എണ്ണം | 2 (Detachable) |
| ഡിഫ്രോസ്റ്റ് സിസ്റ്റം | ഓട്ടോമാറ്റിക് |
| പ്രത്യേക സവിശേഷതകൾ | Anti-Shake, Battery Protection (H/M/L), Max/Eco Cooling, App Control, IPX4, Internal LED Light, Drain Hole, Bottle Opener |
8. വാറൻ്റിയും പിന്തുണയും
BODEGACOOLER products are designed for durability and performance. For any questions, technical assistance, or warranty claims, please refer to the contact information provided in your product packaging or visit the official BODEGACOOLER webസൈറ്റ്. വാറന്റി സാധൂകരണത്തിനായി നിങ്ങളുടെ വാങ്ങലിന്റെ തെളിവ് സൂക്ഷിക്കുക.
For further assistance, you may contact BODEGA customer service through their official channels. The brand is committed to providing thoughtful service and high-quality products.
