ഉൽപ്പന്നം കഴിഞ്ഞുview
The Feit Electric Smart WiFi Dimmer Switch with Remote offers advanced control over your home lighting. This versatile dimmer allows you to adjust brightness levels for non-smart dimmable bulbs from any location, whether through the intuitive Feit Electric App, voice commands via Alexa or Google Assistant, or direct manual operation. It supports single-pole, 3-way, and 4-way configurations, making it adaptable to various home wiring setups. The included wireless remote provides additional flexibility, allowing you to place a control point wherever it's most convenient without the need for complex wiring. Designed for ease of use and installation, this dimmer switch enhances your lighting experience with smart features like scheduling and grouping, while supporting up to 600W incandescent or 200W LED lighting.
പ്രധാനപ്പെട്ട സുരക്ഷാ വിവരങ്ങൾ
⚠ WARNING: Ingestion Hazard
ഈ ഉൽപ്പന്നത്തിൽ ഒരു ബട്ടൺ സെൽ അല്ലെങ്കിൽ കോയിൻ ബാറ്ററി അടങ്ങിയിരിക്കുന്നു.
- കഴിച്ചാൽ മരണമോ ഗുരുതരമായ പരിക്കോ സംഭവിക്കാം.
- വിഴുങ്ങിയ ബട്ടൺ സെൽ അല്ലെങ്കിൽ കോയിൻ ബാറ്ററി കാരണമാകാം ആന്തരിക കെമിക്കൽ പൊള്ളൽ ചെറിയ അളവിൽ 2 മണിക്കൂർ.
- പുതിയതും ഉപയോഗിച്ചതുമായ ബാറ്ററികൾ കുട്ടികൾക്ക് ലഭ്യമാകാതെ സൂക്ഷിക്കുക.
- ബാറ്ററി വിഴുങ്ങുകയോ ശരീരത്തിന്റെ ഏതെങ്കിലും ഭാഗത്തേക്ക് തിരുകുകയോ ചെയ്തതായി സംശയം തോന്നിയാൽ ഉടൻ വൈദ്യസഹായം തേടുക.
എന്താണ് ഉൾപ്പെടുത്തിയിരിക്കുന്നത്
Your Feit Electric Smart WiFi Dimmer Switch package includes the following components:
- സ്മാർട്ട് വൈഫൈ ഡിമ്മർ സ്വിച്ച്
- Wireless Wall-Mount Remote
- Decorative Wall Plate
- വയർ പരിപ്പ്
- മൗണ്ടിംഗ് സ്ക്രൂകൾ
- Adhesive Strips (for remote mounting)

Image: All components included in the product package, laid out on a white surface.
സ്പെസിഫിക്കേഷനുകൾ
| ഫീച്ചർ | വിശദാംശങ്ങൾ |
|---|---|
| ഉൽപ്പന്ന അളവുകൾ | 4.7 x 1.2 x 3 ഇഞ്ച്; 4.8 ഔൺസ് |
| ഇനം മോഡൽ നമ്പർ | DIM/BUTTON/WIFI |
| നിർമ്മാതാവ് | Feit ഇലക്ട്രിക് |
| മാതൃരാജ്യം | ചൈന |
| ഓപ്പറേഷൻ മോഡ് | ഓൺ-ഓഫ് |
| നിലവിലെ റേറ്റിംഗ് | 2 Amps |
| ഓപ്പറേറ്റിംഗ് വോളിയംtage | 120 വോൾട്ട് |
| ബന്ധപ്പെടാനുള്ള തരം | സാധാരണയായി തുറന്നിരിക്കുന്നു |
| കണക്റ്റർ തരം | Clamp |
| അതിതീവ്രമായ | സ്ക്രൂ |
| സർക്യൂട്ട് തരം | Single-Pole/3-Way/4-Way |
| കോൺടാക്റ്റ് മെറ്റീരിയൽ | പ്ലാസ്റ്റിക് |
| Max Incandescent Wattage | 600W |
| Max Dimmable LED Wattage | 200W |

Image: Detailed specifications including dimensions, compatible wiring (Single Pole, 3-way), voltage (120V-60Hz), wattage max (600W incandescent, 200W dimmable LED), and compatible light bulbs (Incandescent, Halogen, Dimmable LED).
ഇൻസ്റ്റാളേഷനും സജ്ജീകരണവും
Neutral Wire Requirement
A neutral wire is required for the installation of the wired dimmer switch. This is crucial for proper operation.

Image: A wiring diagram highlighting the neutral wire (white) connection within a wall box.
How to Check for a Neutral Wire:
- Turn power off at your breaker box.
- Take off the wall plate over your existing switch.
- നിങ്ങളുടെ സ്വിച്ചിൽ നിന്ന് സ്ക്രൂകൾ നീക്കം ചെയ്ത് വയറുകളിലേക്ക് നോക്കാൻ നിലവിലുള്ള സ്വിച്ച് പുറത്തെടുക്കുക.
- If you see a white wire (or group of them), it is very LIKELY that you have a neutral in that switch box.
- If you do not have a neutral wire, this dimmer will not work.
വയറിംഗ് കോൺഫിഗറേഷനുകൾ
The Feit Electric Smart WiFi Dimmer Switch supports various wiring configurations, including single-pole, 3-way, and 4-way setups. The included wireless remote allows for flexible control options.

Image: Illustrations of various control setups: Switch & Dimmer, Dimmer & Companion Remote, Multiple Dimmers, and Single Dimmer.
Wireless Remote Installation
The wireless remote can be mounted anywhere using adhesive or mounting screws, providing convenient access to dimming control without additional wiring.

Image: A hand placing the wireless remote into its wall-mounted docking plate, indicating easy integration.

Image: Two options for securing the wireless remote: using adhesive backing for quick placement or mounting screws for a more permanent fixture.
പ്രവർത്തന നിർദ്ദേശങ്ങൾ
മാനുവൽ നിയന്ത്രണം
The dimmer switch features intuitive buttons for manual control of your lighting.

Image: A detailed diagram labeling the Max Brightness Button, Min. Brightness Button, Status Indicator, Brightness Indicator, Power Button, Dimming Button (Up), Dimming Button (Down), and Air-gap Switch Tab.
- അമർത്തുക പവർ ബട്ടൺ ലൈറ്റുകൾ ഓണാക്കാനോ ഓഫാക്കാനോ.
- ഉപയോഗിക്കുക Dimming Buttons (Up/Down) തെളിച്ച നില ക്രമീകരിക്കാൻ.
- ദി തെളിച്ച സൂചകം LEDs show the current dimming level.
- ദി Air-gap Switch Tab can be pulled out to completely cut power for maintenance.
Smooth Dimmability
The dimmer provides smooth, flicker-free dimming for compatible incandescent and LED bulbs. You can fine-tune the dimming range to suit your preference.

Image: A room with lights dimming from bright to very dim, illustrating the smooth dimmability feature.

Image: A living room scene with lighting adjusted to a comfortable dimmed level, emphasizing flicker-free operation.
App Control (Feit Electric App)
Control your lights from anywhere using the free Feit Electric App, available for Android and iOS devices. The app allows for remote access, scheduling, grouping, and more.

Image: A smartphone displaying the Feit Electric app, showing options for remote access, voice control, scheduling & timer, and grouping.

Image: A smartphone displaying the Feit Electric app's scheduling interface, highlighting features like remote access, grouping, dimming, voice control, scheduling, and device sharing.
ശബ്ദ നിയന്ത്രണം
Integrate your smart dimmer switch with Amazon Alexa or Google Assistant for convenient voice control of your lighting.

Image: An Amazon Echo Dot, illustrating that the dimmer switch works with Alexa and Hey Google when connected through the Feit app.
മെയിൻ്റനൻസ്
The Feit Electric Smart WiFi Dimmer Switch is designed for long-lasting performance with minimal maintenance. Ensure the device is kept clean and free from dust. For any cleaning, disconnect power at the circuit breaker first and use a soft, dry cloth.
The device includes overheat protection for safety and durability.

Image: A bedroom with a bedside lamp, indicating the product includes overheat protection and supports up to 600W incandescent or 200W LED lighting.
ട്രബിൾഷൂട്ടിംഗ്
If you encounter any issues with your Feit Electric Smart WiFi Dimmer Switch, please refer to the following common troubleshooting tips:
- വൈദ്യുതിയില്ല/പ്രതികരിക്കുന്നില്ല: Ensure the circuit breaker is ON and the air-gap switch tab on the dimmer is fully pushed in. Verify that a neutral wire is correctly connected.
- മിന്നുന്ന ലൈറ്റുകൾ: Ensure your bulbs are dimmable. Adjust the minimum brightness level setting within the Feit Electric app if available.
- വൈഫൈ കണക്റ്റിവിറ്റി പ്രശ്നങ്ങൾ: Ensure your Wi-Fi network is 2.4 GHz. Check your Wi-Fi signal strength at the switch location. Try restarting your router and the dimmer switch.
- App Control Not Working: Ensure your phone is connected to the internet and the Feit Electric app is updated to the latest version.
- ശബ്ദ നിയന്ത്രണം പ്രവർത്തിക്കുന്നില്ല: Verify that the Feit Electric skill/service is linked correctly in your Alexa or Google Home app. Ensure your voice commands are clear and precise.
For more detailed troubleshooting or persistent issues, please contact Feit Electric customer support.
വാറൻ്റിയും പിന്തുണയും
നിർമ്മാതാവിൻ്റെ വാറൻ്റി
This Feit Electric Smart WiFi Dimmer Switch comes with a 1 വർഷത്തെ നിർമ്മാതാവിൻ്റെ വാറൻ്റി, ensuring reliability and performance. This warranty covers defects in materials and workmanship under normal use.
ഉപഭോക്തൃ പിന്തുണ
For 24/7 customer support and additional resources, please visit the Feit Electric help center:

Image: A graphic promoting 24/7 customer support, directing users to feit.com/help via a QR code.
