Futaba T6PV RC Transmitter + Receiver Combo User Manual

1. ആമുഖം

The Futaba T6PV is an ultra-modern 6-channel remote control system designed for both hobbyists and professional drivers. New for 2025, this system boasts advanced technology and versatile functions. Its F-4G system delivers exceptionally fast response times and high precision, elevating the driving experience. Key features include a user-friendly high-resolution color screen and extensive customization options, allowing for individual adjustment of your driving behavior.

The T6PV utilizes the F-4G system, offering response speeds comparable to high-end models like the T10PX. This system provides exceptional stability and directivity during control, crucial for drivers demanding maximum precision.

2 പ്രധാന സവിശേഷതകൾ

• മൾട്ടി-മോഡ് അനുയോജ്യത: The T6PV transmitter is compatible with F-4G, T-FHSS, S-FHSS, and MINIZ modes, including MINI-Z EVO, MINI-Z EVO2, and MINI-Z FHSS.
• റിസീവർ അനുയോജ്യത: The included R404SBS receiver is compatible with the F-4G system.
• High-Speed Communication: F-4G mode enables high-speed communication for precise control.
• Sensitive Servo Control: UR mode allows for sensitive control of servos and receivers.
• ക്രാളർ ക്രമീകരണങ്ങൾ: Equipped with dedicated parameters for crawler vehicles.
• അവബോധജന്യമായ ഇൻ്റർഫേസ്: Features a clear wide-angle color LCD screen and a Jog button for easy configuration and navigation.
• ടെലിമെട്രി ഡാറ്റ: Access the telemetry menu to monitor real-time data from your model (e.g., battery voltage, temperature, RPM) if your receiver and sensors support it.
• Response/Feeling Adjustment: Customize driving behavior by attenuating or intensifying control sensitivity.
• മൈക്രോ എസ്ഡി കാർഡ് സ്ലോട്ട്: For data storage and updates.

3. പാക്കേജ് ഉള്ളടക്കം

പാക്കേജ് തുറക്കുമ്പോൾ എല്ലാ ഇനങ്ങളും നിലവിലുണ്ടെന്നും നല്ല നിലയിലാണെന്നും ദയവായി പരിശോധിക്കുക.

• Futaba T6PV 6-Channel RC Transmitter
• Futaba R404SBS F-4G Receiver
• നിർദ്ദേശ മാനുവൽ (ഈ പ്രമാണം)
• (Other accessories may vary by region or specific combo)

ചിത്രം 3.1: The Futaba T6PV product packaging. This image shows the black box with "Futaba Digital Proportional Radio Control System" printed on it, indicating the product's branding and type.

4. സുരക്ഷാ മാർഗ്ഗനിർദ്ദേശങ്ങൾ

Always operate your RC equipment responsibly and safely. Failure to follow these guidelines may result in injury or damage to property.

• മാനുവൽ വായിക്കുക: Thoroughly read and understand this entire manual before operating the system.
• ബാറ്ററി സുരക്ഷ: Use only recommended batteries and chargers. Follow all battery charging and handling instructions to prevent fire or explosion.
• പ്രവർത്തന പരിസ്ഥിതി: Do not operate your RC model in public areas, near people, or in adverse weather conditions. Avoid areas with strong electromagnetic interference.
• Pre-Flight/Run Checks: Always perform a range check and verify all control surfaces/functions are operating correctly before each use.
• പവർ ഓൺ/ഓഫ് സീക്വൻസ്: Always turn on the transmitter first, then the receiver. When turning off, turn off the receiver first, then the transmitter.
• കുട്ടികൾ: This product is not a toy. Adult supervision is required for users under 14 years of age.

5. പ്രാരംഭ സജ്ജീകരണം

5.1. ട്രാൻസ്മിറ്റർ ബാറ്ററി ഇൻസ്റ്റാളേഷൻ

The T6PV transmitter requires batteries for operation. Refer to the battery compartment markings for correct polarity.

1. ട്രാൻസ്മിറ്ററിന്റെ പിൻഭാഗത്തുള്ള ബാറ്ററി കവർ തുറക്കുക.
2. Insert the recommended batteries, ensuring correct polarity (+/-).
3. ബാറ്ററി കവർ സുരക്ഷിതമായി അടയ്ക്കുക.

5.2. Receiver Installation and Connection (R404SBS)

Install the R404SBS receiver in your RC model according to the model's instructions. Ensure it is securely mounted and protected from vibrations and moisture.

1. Connect the servos and ESC (Electronic Speed Controller) to the appropriate channels on the R404SBS receiver. Refer to the receiver's port labels (e.g., CH1, CH2, etc.).
2. Ensure the receiver's antenna is positioned correctly for optimal signal reception, away from metal parts and other electronics.

ചിത്രം 5.1: The Futaba T6PV transmitter and the R404SBS receiver. This image displays the primary components of the RC system, showing the ergonomic design of the transmitter and the compact size of the receiver with its channel ports.

ചിത്രം 5.2: എ വിശദമായി view of the Futaba R404SBS receiver. This image highlights the channel ports (S, 1, 2, 3, 4), the F-4G logo, and the LED/SW indicators, crucial for proper wiring and binding.

5.3. Binding the Transmitter and Receiver

Binding establishes a secure communication link between your T6PV transmitter and the R404SBS receiver.

1. ട്രാൻസ്മിറ്റർ ഓണാക്കുക.
2. Power on the receiver. The receiver's LED will indicate its status (e.g., blinking for waiting to bind).
3. Access the binding function on the T6PV transmitter's menu (refer to Section 6.1 for menu navigation).
4. Follow the on-screen prompts to initiate the binding process.
5. Once bound, the receiver's LED should indicate a solid connection.

6. Operating the T6PV System

6.1. Menu Navigation and Display

The T6PV features a high-resolution color LCD screen and a Jog switch for intuitive menu navigation and parameter adjustment.

• ഉപയോഗിക്കുക ജോഗ് സ്വിച്ച് (rotary dial) to scroll through menu options.
• അമർത്തുക ജോഗ് സ്വിച്ച് to select an option or confirm a setting.
• Dedicated buttons (e.g., DSP, PWR, +/-) provide quick access to common functions or adjustments.

ചിത്രം 6.1: The T6PV transmitter's screen displaying the main System menu. This image shows options like Display, Information, Buzzer, Battery, Total time, LED setting, and Calibration, indicating the range of configurable parameters.

ചിത്രം 6.2: ഒരു വശം view of the Futaba T6PV transmitter, highlighting the angled screen for better visibility during operation. This perspective also shows the ergonomic grip and the steering wheel.

6.2. Selecting Operating Modes

The T6PV supports multiple communication modes to ensure compatibility with various Futaba receivers and models.

1. Navigate to the "System" menu on the transmitter.
2. Select "Receiver System" or a similar option.
3. Choose the desired mode: F-4G, T-FHSS, S-FHSS, or MINI-Z (EVO, EVO2, FHSS).
4. Ensure the selected mode matches your receiver's capabilities.

ചിത്രം 6.3: The T6PV transmitter's screen displaying the receiver system selection menu. This image clearly shows the selectable modes: F-4G, T-FHSS, S-FHSS, MINI-Z EVO, MINI-Z EVO2, and MINI-Z FHSS, allowing users to match their receiver type.

6.3. Advanced Settings (Telemetry, Response/Feeling, Crawler)

The T6PV offers advanced settings for fine-tuning your RC experience.

• ടെലിമെട്രി ഡാറ്റ: Access the telemetry menu to monitor real-time data from your model (e.g., battery voltage, temperature, RPM) if your receiver and sensors support it.
• Response / Feeling Adjustment: This feature allows you to customize the sensitivity of the controls. Adjust this setting to make the steering and throttle response more aggressive or smoother, depending on your driving style and track conditions.
• ക്രാളർ ക്രമീകരണങ്ങൾ: Dedicated settings are available for crawler models, optimizing control for low-speed precision and torque.

ചിത്രം 6.4: The T6PV transmitter's screen displaying a "Racing menu" with "Drag Racing" selected. This indicates the specialized settings available for different racing disciplines, allowing for optimized performance.

7. പരിപാലനം

Proper maintenance ensures the longevity and reliable performance of your Futaba T6PV system.

• വൃത്തിയാക്കൽ: Wipe the transmitter and receiver with a soft, dry cloth. Do not use solvents or abrasive cleaners.
• സംഭരണം: Store the system in a cool, dry place, away from direct sunlight and extreme temperatures. Remove batteries if storing for extended periods.
• ബാറ്ററി കെയർ: Follow the battery manufacturer's guidelines for charging, discharging, and storage.
• ഫേംവെയർ അപ്‌ഡേറ്റുകൾ: Check the official Futaba website periodically for firmware updates for your T6PV transmitter. Use the micro SD card slot for updates as per instructions.

8. പ്രശ്‌നപരിഹാരം

നിങ്ങൾ നേരിട്ടേക്കാവുന്ന പൊതുവായ പ്രശ്നങ്ങളെ ഈ വിഭാഗം അഭിസംബോധന ചെയ്യുന്നു.

9 സ്പെസിഫിക്കേഷനുകൾ

10. വാറൻ്റിയും പിന്തുണയും

വാറന്റി വിവരങ്ങൾക്കും സാങ്കേതിക പിന്തുണയ്ക്കും, ദയവായി ഔദ്യോഗിക ഫ്യൂട്ടബ കാണുക. website or contact your local Futaba distributor. Keep your proof of purchase for warranty claims.

ഓൺലൈൻ ഉറവിടങ്ങൾ:

• ഔദ്യോഗിക ഫ്യൂട്ടബ Webസൈറ്റ്: www.futabarc.com (ദയവായി പ്രാദേശികം പരിശോധിക്കുക) webസൈറ്റുകൾ)
• Product Support Pages: Look for the T6PV model on the support section of the Futaba website for FAQs, firmware updates, and additional resources.
