NARVI Ceiling Fan User Manual - Model REF. 907

സുരക്ഷാ മുന്നറിയിപ്പുകൾ

Read all safety warnings carefully before installation and use to ensure safe, durable, and efficient operation of the fan. The manufacturer is not responsible for damages caused by improper use or installations performed by unqualified personnel.

1. ഇലക്ട്രിക്കൽ ഇൻസ്റ്റലേഷൻ

• Before any intervention, always cut the power from the main circuit breaker.
• Installation must only be performed by an authorized electrician.
• Verify that the ceiling and support can withstand the total weight of the fan.
• Do not install the fan in areas with humidity or risk of water contact.

2. സുരക്ഷിതമായ ഉപയോഗം

• Keep the fan area clear of children, pets, and objects.
• The blades deploy automatically: ensure the surrounding space is clear.
• Do not touch the blades during movement or retraction.
• Do not force or manually manipulate the retractable system.

3. എൽഇഡി ലൈറ്റ്

• Do not look directly at the LED light when it is on.
• Do not attempt to replace the LEDs if they are not designed to be removable.
• Always use original and manufacturer-approved components.

4. പരിപാലനവും ശുചീകരണവും

• Clean exclusively with a dry or slightly damp തുണി.
• Avoid abrasive products, chemicals, or solvents.
• Periodically inspect screws and moving parts; tighten them if necessary.
• If you detect abnormal noises or irregular operation, turn off the fan immediately and contact technical service.

സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും

This section provides general guidelines for setting up your NARVI ceiling fan. For detailed steps, refer to the specific installation guide included with your product packaging.

• മൗണ്ടിംഗ് ലൊക്കേഷൻ: Choose a location where the ceiling can support the fan's weight (7.8 kg) and where there is sufficient clearance for the blades (132 cm diameter). Ensure no obstructions are present when blades are deployed.
• Ceiling Rods: The fan offers adjustable height with two available ceiling rods (10 cm and 20 cm). Select the appropriate rod for your ceiling height to ensure optimal airflow and safety clearance.
• ഇലക്ട്രിക്കൽ കണക്ഷൻ: As stated in the safety warnings, electrical installation must be performed by an authorized electrician. Ensure the main power is off before connecting any wires.

Image: NARVI Ceiling Fan (Model REF. 907) with blades retracted, highlighting its compact and modern design.

പ്രവർത്തന നിർദ്ദേശങ്ങൾ

Your NARVI ceiling fan is equipped with a remote control for convenient operation of its various functions.

• പവർ ഓൺ/ഓഫ്: Use the dedicated button on the remote control to turn the fan and light on or off.
• ഫാൻ സ്പീഡ് നിയന്ത്രണം: The DC motor offers 6 adjustable speeds. Select your desired airflow intensity using the speed buttons on the remote.
• LED ലൈറ്റ് കൺട്രോൾ:
  • തെളിച്ച ക്രമീകരണം: The LED light is dimmable. Use the remote to increase or decrease the light intensity.
  • വർണ്ണ താപനില ക്രമീകരണം: Adjust the color temperature between 3000K (warm white), 4200K (neutral white), and 6000K (cool white) to suit your preference.
  • മെമ്മറി പ്രവർത്തനം: The fan includes a memory function that retains your last light brightness and color temperature settings when turned off and on again.
• Summer/Winter Function: Activate the summer mode for downward airflow to create a cooling effect, or winter mode for upward airflow to circulate warm air trapped near the ceiling.
• ടൈമർ പ്രവർത്തനം: Set a timer for the fan to automatically turn off after a specified period. Refer to your remote control's specific buttons for timer settings.

Image: NARVI Ceiling Fan (Model REF. 907) with its integrated LED light illuminated, demonstrating its lighting capability.

പരിപാലനവും ശുചീകരണവും

പതിവ് അറ്റകുറ്റപ്പണികൾ നിങ്ങളുടെ സീലിംഗ് ഫാനിന്റെ ദീർഘായുസ്സും മികച്ച പ്രകടനവും ഉറപ്പാക്കുന്നു.

• വൃത്തിയാക്കൽ: Clean the fan surfaces exclusively with a dry or slightly damp cloth. Do not use abrasive products, chemicals, or solvents, as these can damage the finish or components.
• പരിശോധന: Periodically inspect all screws and moving parts. Tighten any loose screws to prevent vibrations or abnormal noises.
• ബ്ലേഡ് കെയർ: Ensure the retractable blades are free from dust and debris. Do not force or manually manipulate the blade retraction mechanism.

ട്രബിൾഷൂട്ടിംഗ്

If you encounter any issues with your NARVI ceiling fan, refer to the following common troubleshooting steps. If the problem persists, contact technical service.

ഉൽപ്പന്ന സവിശേഷതകൾ

വാറൻ്റിയും പിന്തുണയും

For warranty information, technical support, or service inquiries, please contact NARVI customer service. Keep your purchase receipt as proof of purchase.

ബന്ധപ്പെടാനുള്ള വിവരങ്ങൾ: Refer to the contact details provided in your product packaging or visit the official NARVI webസൈറ്റ്.
