ROBOTIME 3D Wooden Cuckoo Clock Puzzle Instruction Manual

1. ആമുഖം

Thank you for choosing the ROBOTIME LC901C 3D Wooden Cuckoo Clock Puzzle. This kit provides a rewarding building experience, culminating in a functional cuckoo clock with intricate details and a charming cuckoo sound. This manual will guide you through the assembly process, operation, and care of your new wooden model.

Figure 1.1: The ROBOTIME LC901C 3D Wooden Cuckoo Clock, fully assembled, alongside its product packaging.

2 സുരക്ഷാ വിവരങ്ങൾ

Please read all safety warnings before beginning assembly. This product contains small parts and is not suitable for children under 3 years old due to choking hazards. Keep all components away from young children.

• ശ്വാസംമുട്ടൽ അപകടം: ചെറിയ ഭാഗങ്ങൾ. 3 വയസ്സിന് താഴെയുള്ള കുട്ടികൾക്കുള്ളതല്ല.
• മൂർച്ചയുള്ള അഗ്രങ്ങൾ: Handle wooden pieces carefully to avoid splinters or cuts.
• ബാറ്ററി സുരക്ഷ: Use only specified batteries (3 x AAA, not included). Do not mix old and new batteries. Insert batteries with correct polarity.
• ഇലക്ട്രിക്കൽ ഘടകങ്ങൾ: Ensure all electrical connections are secure and dry. Do not expose to water.

Figure 2.1: Product packaging displaying important safety warnings and product information.

3. ഘടകങ്ങൾ കഴിഞ്ഞുview

Your ROBOTIME Cuckoo Clock kit includes 435 laser-cut wooden pieces, along with the necessary mechanical and electrical components to create a fully functional clock. No glue is required for assembly.

• Pre-cut Wooden Sheets (435 pieces)
• Clock Mechanism
• Cuckoo Bird Module
• LED ലൈറ്റ് മൊഡ്യൂൾ
• USB Type-C Power Cable (not included, but compatible)
• ഇൻസ്ട്രക്ഷൻ മാനുവൽ

Figure 3.1: All components of the puzzle kit, including laser-cut wooden sheets and the instruction booklet.

4. അസംബ്ലി നിർദ്ദേശങ്ങൾ

The estimated assembly time for this model is approximately 8 hours, suitable for ages 14 and up. Follow the detailed pictorial instructions provided in your kit. Each wooden piece is precisely laser-cut for easy pop-out and interlocking assembly.

4.1. തയ്യാറാക്കൽ

• Unpack all components and verify against the parts list in the instruction manual.
• വൃത്തിയുള്ളതും നല്ല വെളിച്ചമുള്ളതുമായ ഒരു ജോലിസ്ഥലം തയ്യാറാക്കുക.
• Familiarize yourself with the instruction manual's symbols and numbering system.

4.2. ഘട്ടം ഘട്ടമായുള്ള അസംബ്ലി

1. Carefully detach each wooden piece from its sheet. Use a small tool if necessary to avoid breakage.
2. Follow the numerical sequence in the instruction manual. Each step clearly indicates which pieces to use and how they interlock.
3. Pay close attention to the orientation of pieces, especially for gears and structural elements.
4. When installing the clock mechanism and cuckoo module, ensure wires are routed correctly and connections are secure.
5. Install the LED light module as instructed to enable the internal illumination.
6. Once all wooden pieces are assembled, ensure all moving parts (pendulum, cuckoo) can move freely.

Figure 4.1: Close-up of the assembly process, highlighting the precision of the laser-cut components.

5. ഓപ്പറേഷൻ

Your ROBOTIME Cuckoo Clock is designed to be a fully functional timepiece with interactive features.

5.1. Powering the Clock

The clock can be powered by either 3 x AAA batteries (not included) or a USB Type-C cable (not included) connected to a power source.

• ബാറ്ററി ഇൻസ്റ്റാളേഷൻ: Locate the hidden battery box (refer to Figure 5.1). Insert 3 AAA batteries, ensuring correct polarity.
• USB ടൈപ്പ്-സി കണക്ഷൻ: Plug a USB Type-C cable into the designated port (refer to Figure 5.1) and connect to a 5V power adapter.

5.2. സമയം ക്രമീകരിക്കുന്നു

Adjust the clock hands manually to set the correct time. The Roman dial provides clear time indication.

5.3. Cuckoo Sound and Light Features

The clock features an hourly cuckoo chime and warm internal lighting.

• Cuckoo Chime: The cuckoo bird will emerge and chirp hourly. There is a hidden switch to control this function.
• Activating Chime: Long press the hidden switch (located on the front step) until the light flashes twice to start the chime function.
• Deactivating Chime: Long press the hidden switch until the light flashes four times to turn off the chime function.
• Manual Chime: Tap the hidden switch once to make the cuckoo chime immediately.
• Internal Lights: Pull the vintage-style cord to activate the warm lights illuminating the clock's interior.

Figure 5.1: Demonstrating the cuckoo time-telling function and control buttons.

ചിത്രം 5.2: വിശദമായി views of key features including the hidden battery box.

Figure 5.3: The cuckoo clock with its internal warm lights activated.

6. പരിപാലനം

To ensure the longevity and appearance of your ROBOTIME Cuckoo Clock, follow these maintenance guidelines:

• വൃത്തിയാക്കൽ: Gently wipe the wooden surfaces with a dry, soft cloth to remove dust. Avoid using wet cloths or harsh cleaning agents.
• പ്ലേസ്മെൻ്റ്: Place the clock in a dry environment, away from direct sunlight, extreme temperatures, and high humidity, which can damage the wood.
• കൈകാര്യം ചെയ്യൽ: Handle the assembled clock with care, especially delicate parts like the pendulum and cuckoo mechanism.
• ബാറ്ററി മാറ്റിസ്ഥാപിക്കൽ: Replace batteries when the clock's functions (timekeeping, cuckoo, lights) become weak or stop working.

7. പ്രശ്‌നപരിഹാരം

If you encounter any issues with your ROBOTIME Cuckoo Clock, refer to the table below for common problems and solutions.

For more detailed assembly guidance, refer to the QR code provided in your kit, which links to helpful video tutorials.

8 സ്പെസിഫിക്കേഷനുകൾ

Figure 8.1: Dimensions of the assembled ROBOTIME LC901C Cuckoo Clock.

9. പിന്തുണ

For any questions, missing parts, or further assistance, please contact ROBOTIME customer service. Information regarding replacement parts can be found in your product packaging or by contacting the manufacturer directly.
