Ulefone Armor X16 പരുക്കൻ സ്മാർട്ട്ഫോൺ ഉപയോക്തൃ മാനുവൽ

1. ആമുഖം

This manual provides essential information for the proper use and maintenance of your Ulefone Armor X16 Rugged Smartphone. Please read it thoroughly before operating your device.

1.1 പാക്കേജ് ഉള്ളടക്കം

• 1x Ulefone Armor X16 Rugged Phone
• 1x AC Power Charger (33W)
• 1x Type-C to Type-C Data Cable (100cm)
• 1x Protective Film (Pre-installed)
• 1x ടെമ്പർഡ് ഗ്ലാസ് സ്ക്രീൻ പ്രൊട്ടക്ടർ
• 1x SIM Needle
• 1x ലാനിയാർഡ്
• 1x Multi-language User Manual

2. സജ്ജീകരണം

2.1 സിം, മൈക്രോ എസ്ഡി കാർഡുകൾ ചേർക്കൽ

The Ulefone Armor X16 supports a 3-card slot configuration (Nano-SIM + Nano-SIM + microSD) for simultaneous use. To insert the cards:

1. ഉപകരണത്തിന്റെ വശത്ത് സിം കാർഡ് ട്രേ കണ്ടെത്തുക.
2. Use the provided SIM needle to gently eject the tray.
3. Place your Nano-SIM cards and microSD card into their respective slots on the tray. Ensure they are correctly oriented.
4. ഉപകരണ ബോഡിയുമായി ഫ്ലഷ് ആകുന്നതുവരെ ട്രേ ഫോണിലേക്ക് ശ്രദ്ധാപൂർവ്വം വീണ്ടും തിരുകുക.

2.2 പ്രാരംഭ പവർ ഓൺ

Press and hold the Power button located on the side of the device until the Ulefone logo appears. Follow the on-screen prompts to complete the initial setup, including language selection, Wi-Fi connection, and Google account setup.

3. നിങ്ങളുടെ ഉപകരണം പ്രവർത്തിപ്പിക്കുന്നു

3.1 ഡിസ്പ്ലേ സവിശേഷതകൾ

The Armor X16 features a 6.56-inch Fluid Display with 720 x 1612 resolution and a 90Hz refresh rate. It offers up to 910 nits maximum brightness for improved outdoor visibility. The display is protected by Corning Gorilla Glass 5, providing enhanced durability against drops and scratches. Widevine L1 certification allows for high-definition streaming on platforms such as Amazon Prime Video and Netflix.

3.2 ബാറ്ററിയും ചാർജിംഗും

The device is equipped with a 10360mAh battery, offering extended usage times: up to 555 hours standby, 56 hours talk time, 42 hours music playback, and 13 hours video playback. It supports 33W PD fast charging.

3.3 ക്യാമറ സവിശേഷതകൾ

The Armor X16 features a versatile camera system:

• 48MP പ്രധാന ക്യാമറ: Utilizes an OV48B sensor with an f/1.9 aperture for clear images.
• 20MP ഇൻഫ്രാറെഡ് നൈറ്റ് വിഷൻ ക്യാമറ: Equipped with a Sony IMX350 sensor and f/1.8 lens, enhanced by the Ulefone NightElf 2.0 algorithm for visibility in complete darkness.
• 2MP മാക്രോ ക്യാമറ: For close-up photography of small objects.
• 16MP മുൻ ക്യാമറ: Suitable for selfies and video calls.
• അണ്ടർവാട്ടർ ക്യാമറ മോഡ്: Allows for photography and videography underwater.

3.4 AI സവിശേഷതകൾ

The device integrates Google Gemini as an AI assistant for queries, brainstorming, and real-time assistance. An AI Recorder is also included, designed to capture voice and video calls, providing instant transcripts and summaries, particularly useful for meetings. Note: Third-party app audio recording functionality depends on the app's features and permissions.

3.5 കണക്റ്റിവിറ്റി

The Ulefone Armor X16 supports dual 4G global networks (FDD-LTE: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28A/28B/32/66/71; TDD-LTE: B34/38/39/40/41; WCDMA: B1/2/4/5/6/8/19; GSM: B2/3/5/8; CDMA: BC0/BC1/BC10). It also includes Bluetooth 5.2, NFC for mobile payments, and comprehensive GPS (GPS+GLONASS+BEIDOU+Galileo+QZSS) for accurate navigation.

3.6 പ്രത്യേക സവിശേഷതകൾ

• ഇഷ്‌ടാനുസൃത കീ: A programmable side button for quick access to specific functions.
• 3.5 എംഎം ഹെഡ്‌ഫോൺ ജാക്ക്: For wired audio connectivity.
• Face Unlock + Fingerprint ID: Multiple biometric security options.
• ഗ്ലൗസ് മോഡ്: Enhances touch sensitivity for use with gloves.
• ഐആർ ബ്ലാസ്റ്റർ: Allows the device to function as a universal remote control.
• Headset-free FM: Enables FM radio listening without requiring a headset as an antenna.
• അന്തർനിർമ്മിത ഫ്ലാഷ്ലൈറ്റ്: A separate flashlight with 133 lumens brightness, adjustable via the quick-setting menu. Caution: Do not stare directly into the flashlight.

4. ഈടുനിൽപ്പും സംരക്ഷണവും

4.1 Rugged Design

The Ulefone Armor X16 is built to withstand harsh environments, boasting IP69K, IP68, and MIL-STD-810H certifications. This ensures resistance to high-pressure water jets, submersion in water up to 2 meters for 30 minutes, dust ingress, and drops.

5. പരിപാലനം

5.1 നിങ്ങളുടെ ഉപകരണം വൃത്തിയാക്കൽ

Due to its rugged and waterproof design, the Armor X16 can be cleaned with water. Use a soft cloth to wipe down the device. Ensure all port covers are securely closed before exposing the device to water.

5.2 സോഫ്റ്റ്‌വെയർ അപ്‌ഡേറ്റുകൾ

Your device runs on Android 15, which includes features like advanced theft detection and Private Space for data security. Regularly check for and install system updates to ensure optimal performance, security, and access to the latest features. Updates can typically be found in ക്രമീകരണങ്ങൾ > സിസ്റ്റം > സിസ്റ്റം അപ്ഡേറ്റ്.

6. പ്രശ്‌നപരിഹാരം

6.1 പൊതുവായ പ്രശ്നങ്ങളും പരിഹാരങ്ങളും

• Device is slow or unresponsive: Close unused applications, clear cache, or restart the device. If issues persist, consider a factory reset (back up your data first).
• Network connectivity problems: Ensure SIM cards are correctly inserted. Check network settings (Settings > Network & internet). Restart the device or contact your service provider.
• ബാറ്ററി പെട്ടെന്ന് തീർന്നു പോകുന്നു: Reduce screen brightness, disable unnecessary features (Wi-Fi, Bluetooth, GPS) when not in use, and limit background app activity.
• Camera quality not as expected: Ensure lenses are clean. Check lighting conditions. For night vision, ensure sufficient darkness for optimal performance.
• Difficulty with TalkBack or accessibility features: If you encounter issues during setup or daily use, consult the Android accessibility settings or Ulefone's official support resources for detailed guidance.

7 സ്പെസിഫിക്കേഷനുകൾ

8. വാറൻ്റിയും പിന്തുണയും

8.1 വാറൻ്റി വിവരങ്ങൾ

Please refer to the Warranty Card included in your product package for detailed information regarding warranty coverage and terms. Keep your proof of purchase for warranty claims.

8.2 ഉപഭോക്തൃ പിന്തുണ

For further assistance, technical support, or inquiries, please visit the official Ulefone website or contact their customer service department. Contact details can typically be found in the included user manual or on the Ulefone support page.
