Aquaguard Neo UV+UF Water Purifier User Manual

1. ആമുഖം

This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Aquaguard Neo UV+UF Water Purifier. Please read this manual thoroughly before using the appliance and retain it for future reference.

The Aquaguard Neo UV+UF is designed to provide purified drinking water using a multi-stage purification process, including UV and UF technologies, suitable for municipal water sources with a Total Dissolved Solids (TDS) level below 200 ppm.

2 സുരക്ഷാ വിവരങ്ങൾ

ഉപകരണത്തിന് പരിക്കേൽക്കുകയോ കേടുപാടുകൾ സംഭവിക്കുകയോ ചെയ്യാതിരിക്കാൻ ഇനിപ്പറയുന്ന സുരക്ഷാ മുൻകരുതലുകൾ പാലിക്കുക:

• Ensure the water purifier is installed by a qualified technician.
• Do not attempt to repair or modify the appliance yourself. Contact authorized service personnel.
• Use only genuine Aquaguard spare parts and filters.
• Ensure the power supply meets the specifications mentioned in this manual.
• നേരിട്ട് സൂര്യപ്രകാശത്തിൽ നിന്നും ചൂട് സ്രോതസ്സുകളിൽ നിന്നും ഉപകരണം അകറ്റി നിർത്തുക.
• This purifier is designed for municipal/soft water with TDS < 200 ppm. Do not use with borewell or tanker water (TDS > 200 ppm) as it may not provide adequate purification and could damage the unit.
• വൃത്തിയാക്കുന്നതിനോ അറ്റകുറ്റപ്പണികൾ നടത്തുന്നതിനോ മുമ്പ് ഉപകരണം അൺപ്ലഗ് ചെയ്യുക.

3. ഉൽപ്പന്നം കഴിഞ്ഞുview

The Aquaguard Neo UV+UF Water Purifier incorporates advanced technologies to deliver safe drinking water.

പ്രധാന സവിശേഷതകൾ:

• 2-Year Filter Life: Filters are designed for extended durability and performance, lasting up to 2 years or 12,000 litres under specified lab conditions.
• NanoPore Filter Technology: Provides advanced protection against microplastics, pesticides, lead, and mercury.
• 3-in-1 Patented Active Copper Technology: Infuses the correct amount of copper into the water, adhering to BIS norms, and features clean-free technology.
• 9-എസ്tagഇ ശുദ്ധീകരണം: Includes UV+UF for comprehensive purification, ensuring 99.9999% bacteria reduction and 99.99% virus reduction.
• UV e-boiling: Ensures water purity equivalent to water boiled for over 20 minutes.
• Ultra Filtration 2X: Removes ultra-fine suspended particles for crystal clear water.
• Mega Sediment Filter: An additional filter to remove fine dust, dirt, and mud particles, extending the life of internal filters.
• സംഭരണ ​​ശേഷി: 6.2 ലിറ്റർ.

ശുദ്ധീകരണം എസ്tages:

The Aquaguard Neo UV+UF employs a 9-stagഇ ശുദ്ധീകരണ പ്രക്രിയ:

1. Mega Sediment Filter
2. Sedi Shield 2X
3. കണികാ ഫിൽട്ടർ
4. Chemi Block 2X
5. യുവി ഇ-തിളപ്പിക്കൽ
6. അൾട്രാ ഫിൽട്ടറേഷൻ
7. 3-in-1 Active Copper (Stages 7-9)

ചിത്രം: 9-കളുടെ ചിത്രീകരണംtage purification process, detailing each filter component.

നൂതന സാങ്കേതികവിദ്യകൾ:

Image: Explanation of the 3-in-1 Active Copper Technology, showing copper, magnesium, and calcium infusion.

The 3-in-1 Active Copper Technology ensures the right amount of copper is infused into the water, suitable for all age groups, and utilizes clean-free technology.

Image: Visual representation of UV-E Boiling Technology, highlighting its effectiveness.

UV e-boiling technology provides water purity comparable to boiling water for over 20 minutes, effectively neutralizing harmful microorganisms.

ചിത്രം: വിശദമായത് view of Nanopore Filter Technology, demonstrating its ability to filter microplastics, pesticides, and heavy metals.

The NanoPore Filter Technology offers comprehensive protection against modern pollutants, including microplastics, pesticides, lead, and mercury, with a filter life of up to 2 years.

4. സജ്ജീകരണവും ഇൻസ്റ്റാളേഷനും

The Aquaguard Neo UV+UF Water Purifier comes with an installation kit. Professional installation by an authorized Aquaguard technician is highly recommended to ensure proper functioning and warranty validity.

ഇൻസ്റ്റലേഷൻ ഘട്ടങ്ങൾ (കഴിഞ്ഞുview):

1. സൈറ്റ് തിരഞ്ഞെടുക്കൽ: Choose a clean, dry, and well-ventilated location, preferably on a countertop, near a water inlet and an electrical outlet. Ensure sufficient space around the unit for maintenance.
2. ജല കണക്ഷൻ: Connect the water purifier to the municipal water supply line. Ensure all connections are secure to prevent leaks.
3. ഡ്രെയിനേജ് കണക്ഷൻ: If applicable, connect the drain line as per the technician's instructions.
4. പവർ കണക്ഷൻ: ഗ്രൗണ്ടഡ് ഇലക്ട്രിക്കൽ ഔട്ട്ലെറ്റിലേക്ക് പവർ കോർഡ് പ്ലഗ് ചെയ്യുക.
5. പ്രാരംഭ ഫ്ലഷ്: The technician will perform an initial flush to remove any manufacturing residues and air from the system.
6. സിസ്റ്റം പരിശോധന: The technician will verify proper operation, check for leaks, and ensure water quality.

For detailed installation instructions, please refer to the separate installation guide provided by the technician or contact Aquaguard customer support.

5. പ്രവർത്തന നിർദ്ദേശങ്ങൾ

ആദ്യ ഉപയോഗം:

• After installation, allow the storage tank to fill completely. This may take some time.
• Discard the first few liters of purified water to ensure the system is fully flushed and ready for use.

ജലവിതരണം:

• Place a clean container under the water dispenser tap.
• Operate the tap to dispense purified water.
• The purifier will automatically refill the storage tank as water is consumed.

സൂചകങ്ങൾ:

The unit may feature LED indicators for power, purification status, and filter life. Refer to the specific indicator guide provided with your unit for detailed explanations.

6. പരിപാലനം

Regular maintenance ensures optimal performance and longevity of your water purifier.

ഫിൽട്ടർ മാറ്റിസ്ഥാപിക്കൽ:

• The filters are designed to last for 2 years or 12,000 litres, whichever comes first.
• It is crucial to replace filters at the recommended intervals to maintain water quality and system efficiency.
• Contact Aquaguard customer service to schedule filter replacement by an authorized technician. Do not attempt to replace filters yourself.

വൃത്തിയാക്കൽ:

• പുറം: പ്യൂരിഫയറിന്റെ പുറംഭാഗം മൃദുവായ, ഡി-ടച്ച് ഉപയോഗിച്ച് തുടയ്ക്കുക.amp തുണി. കഠിനമായ രാസവസ്തുക്കളോ ഉരച്ചിലുകളുള്ള ക്ലീനറുകളോ ഉപയോഗിക്കരുത്.
• സംഭരണ ​​ടാങ്ക്: The storage tank should be cleaned periodically by an authorized service technician.
• Dispenser Tap: Clean the dispenser tap regularly to prevent accumulation of dust or residue.

Aquaguard offers a Free Genuine Service Plan which includes 2 free cleaning services during the first year. Utilize these services for professional maintenance.

7. പ്രശ്‌നപരിഹാരം

If you encounter any issues with your water purifier, refer to the table below. For problems not listed or if the issue persists, contact Aquaguard customer support.

8 സ്പെസിഫിക്കേഷനുകൾ

Image: Product dimensions of the Aquaguard Neo UV+UF water purifier.

9. വാറൻ്റിയും പിന്തുണയും

വാറൻ്റി വിവരങ്ങൾ:

Your Aquaguard Neo UV+UF Water Purifier comes with a manufacturer's warranty. Please refer to the warranty card provided with your product for specific terms and conditions, including coverage period and exclusions.

A Free Genuine Service Plan is included, offering free installation, 2 free cleaning services, and unlimited repair visits during the first year of purchase.

ഉപഭോക്തൃ പിന്തുണ:

For installation requests, service appointments, filter replacements, or any technical assistance, please contact Aquaguard customer support. Aquaguard has a wide service network across India.

നിർമ്മാതാവ്: Aquaguard, Eureka Forbes Limited

Registered Office Address: B1/B2, 701, 7th Floor, Marathon Innova, Off. Ganpatrao Kadam Marg, Lower Parel (West), Mumbai, Maharashtra – 400013

For the most current contact information, please visit the official Aquaguard webസൈറ്റ് അല്ലെങ്കിൽ നിങ്ങളുടെ ഉൽപ്പന്ന പാക്കേജിംഗിൽ നൽകിയിരിക്കുന്ന കോൺടാക്റ്റ് വിശദാംശങ്ങൾ പരിശോധിക്കുക.
