DOGLinsen 2-in-1 Bark and Shock Collar Instruction Manual

ആമുഖം

Thank you for choosing the DOGLinsen 2-in-1 Bark and Shock Collar. This device is designed to assist in training your dog and managing excessive barking through various modes including beep, vibration, and static shock. Please read this manual thoroughly before use to ensure proper and safe operation.

എന്താണ് ഉൾപ്പെടുത്തിയിരിക്കുന്നത്

The package for your DOGLinsen 2-in-1 Bark and Shock Collar includes the following items:

• വിദൂര നിയന്ത്രണം (1)
• സ്വീകർത്താവ് (1)
• Collar Strap (1)
• ലാനിയാർഡ് (1)
• USB ചാർജിംഗ് കേബിൾ (1)
• ഉപയോക്തൃ മാനുവൽ (1)
• പെട്ടി (1)
• Metal Contact Points (4)
• Black Rubber Sleeves (4)
• ടെസ്റ്റ് എൽamp (1)

Image: All components included in the DOGLinsen 2-in-1 Bark and Shock Collar package, laid out neatly.

സജ്ജമാക്കുക

Pairing the Remote Control with the Receiver

Before using the collar, ensure the remote control and receiver are paired. If they are not already paired, follow these steps:

1. Hold down the power switch button on the receiver until the indicator light starts flashing.
2. Press the Vibration button on the remote control. The receiver will receive the signal.
3. Press the Tone button on the remote control. The receiver will receive the signal again.

Successful pairing is indicated when the receiver responds to both vibration and tone commands from the remote.

കോളർ എഡിറ്റുചെയ്യുന്നു

The collar strap is adjustable to fit dogs with neck sizes from 8 to 27 inches and weights from 10 to 110 lbs. Ensure the collar is snug but not too tight, allowing two fingers to fit comfortably between the strap and your dog's neck. The contact points should touch your dog's skin for effective operation.

Image: The adjustable collar strap shown with various dog breeds and sizes, indicating its suitability for different weights and neck circumferences.

ഓപ്പറേറ്റിംഗ് മോഡുകൾ

The DOGLinsen 2-in-1 Bark and Shock Collar offers three main collar modes and four effective training functions:

കോളർ മോഡുകൾ:

• Bark Control Mode: The collar automatically detects and responds to dog barking.
• നായ പരിശീലന മോഡ്: Use the remote control to manually apply training functions.
• എല്ലാ മോഡുകളും: Combines both bark control and remote training functionalities.

Image: A dog wearing the collar, with an overlay illustrating the three available collar modes: Bark Control, Dog Training, and All Mode.

Training Functions:

• ബീപ്പ്: An audible tone.
• വൈബ്രേഷൻ: Adjustable from 1-100 levels.
• Safety Shock: Adjustable from 1-100 levels.
• യാന്ത്രിക മോഡ്: Features 5 levels of adjustable sensitivity for bark detection.

Image: The remote control displaying the four effective training modes: Beep, Vibration (1-100 levels), Safe Shock (1-100 levels), and Auto mode with adjustable sensitivity (1-5 levels).

Automatic Bark Collar & Protection Mode

In automatic bark control mode, the collar detects dog barking and activates corrective stimuli. To protect your dog from over-correction, if the bark collar is triggered 7 times in a row, it will temporarily stop working for 30 seconds.

Image: A dog wearing the collar, illustrating how it automatically detects barking and the sequence of corrective actions (Beep, Vibration, Shock) with increasinഗ്രാം തീവ്രത.

Turning Auto Mode On or Off

To activate or deactivate the Auto Mode on the receiver:

1. Press and hold the power button on the remote for about 3 seconds.
2. When you hear a single 'beep' sound from the receiver, Auto Mode is turned on.
3. To turn it off, press and hold the power button again for 3 seconds. You will hear two 'beeps' from the receiver, indicating Auto Mode is off.

സംവേദനക്ഷമത ക്രമീകരിക്കുന്നു

The automatic mode has 5 levels of adjustable sensitivity. The higher the sensitivity level, the easier the device can be triggered by barking. You can choose the appropriate sensitivity for your dog's barking habits.

To Adjust Sensitivity:

1. റിസീവർ ഓണാക്കിയിട്ടുണ്ടെന്ന് ഉറപ്പാക്കുക.
2. Press the power button on the receiver 3 times in a row.
3. Each press will cycle through the sensitivity levels, indicated by a number of beeps:
• 1 Beep: Level 1 (Lowest Sensitivity)
• 2 Beeps: Level 2
• 3 Beeps: Level 3
• 4 Beeps: Level 4
• 5 Beeps: Level 5 (Highest Sensitivity)

ബാറ്ററി ലൈഫും ചാർജിംഗും

The DOGLinsen collar features a long-lasting battery. When fully charged, the receiver can operate for up to 90 days, and the remote control for up to 30 days. The device uses a USB Type-C charging cable for convenient charging from various sources like laptops, PCs, power banks, or phone chargers.

Image: Visual representation of the long battery life for both the remote (30 days) and receiver (90 days), along with various USB-C charging options.

Checking Receiver Battery Level

To check the battery level of the receiver:

1. Press the power button on the receiver twice in a row.
2. You will hear a series of beeps indicating the battery charge level:
• 1 Beep: Below 20%
• 2 Beeps: Above 20%
• 3 Beeps: Above 40%
• 4 Beeps: Above 60%
• 5 Beeps: Above 80%

വാട്ടർപ്രൂഫിംഗ്

The receiver unit of the DOGLinsen collar is IP67 waterproof, making it suitable for use in various weather conditions and environments, including rain, seaside, and even swimming. Please ensure the remote control is kept away from water as it is not waterproof.

Image: The collar receiver submerged in water and covered in sand, demonstrating its IP67 waterproof and dust-proof capabilities for use in various outdoor settings.

സ്പെസിഫിക്കേഷനുകൾ

മെയിൻ്റനൻസ്

• Regularly check the collar for wear and tear.
• Clean the collar strap with a damp cloth and mild soap. Hand wash only.
• Ensure the contact points are clean and free of debris for optimal performance.
• ബാറ്ററിയുടെ ആരോഗ്യം നിലനിർത്താൻ ഉപകരണം പതിവായി ചാർജ് ചെയ്യുക.

ട്രബിൾഷൂട്ടിംഗ്

• Collar not responding: Ensure both the remote and receiver are charged and powered on. Re-pair the devices if necessary.
• Ineffective correction: Check that the contact points are making proper contact with your dog's skin. Adjust collar tightness or use longer contact points if your dog has thick fur.
• Accidental triggers in Auto Mode: Adjust the sensitivity level to a lower setting.
• ഹ്രസ്വ ബാറ്ററി ലൈഫ്: Ensure the device is fully charged. Battery life can vary based on usage frequency.

വാറൻ്റിയും പിന്തുണയും

The DOGLinsen 2-in-1 Bark and Shock Collar comes with a 2 വർഷത്തെ നിർമ്മാതാവിൻ്റെ വാറൻ്റി. For any questions, concerns, or support needs regarding your product, please contact DOGLinsen customer service. Refer to the contact information provided in your product packaging or visit the official DOGLinsen store online.
