GAOMON 10x15 FT Metal Carport Instruction Manual

1. ആമുഖം

This manual provides comprehensive instructions for the assembly, safe operation, and maintenance of your GAOMON 10x15 FT Metal Carport. Designed with a reinforced base and galvanized steel roof, this heavy-duty structure offers reliable shelter for vehicles such as SUVs, trucks, and boats, as well as providing a versatile canopy for outdoor activities. Please read this manual thoroughly before installation and use to ensure proper setup and long-term durability.

2 സുരക്ഷാ വിവരങ്ങൾ

മുന്നറിയിപ്പ്: ഈ സുരക്ഷാ നിർദ്ദേശങ്ങൾ പാലിക്കുന്നതിൽ പരാജയപ്പെടുന്നത് ഗുരുതരമായ പരിക്കോ സ്വത്ത് നാശമോ ഉണ്ടാക്കിയേക്കാം.

• Read the entire assembly manual thoroughly before beginning installation.
• Ensure all components are accounted for and undamaged before assembly. Do not proceed with assembly if parts are missing or damaged.
• A team of at least two to three adults is strongly recommended for safe and efficient installation.
• Wear appropriate personal protective equipment, including work gloves and eye protection, to prevent scratches and injuries from sharp edges or tools.
• അപകടങ്ങൾ തടയാൻ കുട്ടികളെയും വളർത്തുമൃഗങ്ങളെയും അസംബ്ലി ഏരിയയിൽ നിന്ന് അകറ്റി നിർത്തുക.
• Choose a level and stable surface for installation. Proper anchoring is crucial for stability, especially in areas prone to high winds or heavy snow.
• This carport is designed to withstand wind ratings of 100 MPH and snow load capacities of 35 PSF. However, in extreme weather conditions, additional precautions may be necessary.
• Regularly inspect the carport for any signs of wear, damage, or loose connections. Address any issues promptly to maintain structural integrity.

3. പാക്കേജ് ഉള്ളടക്കം

Your GAOMON Metal Carport is typically packaged in multiple cartons (e.g., 3 cartons). Please verify that all parts listed in the packing list are present and undamaged before starting assembly. Two pairs of gloves are included for your convenience.

ചിത്രം: കഴിഞ്ഞുview of the GAOMON 10x15 FT Metal Carport dimensions and package contents, including two pairs of gloves and indication of 3 cartons.

പ്രധാന ഘടകങ്ങൾ ഉൾപ്പെടുന്നു:

• ഗാൽവനൈസ്ഡ് സ്റ്റീൽ മേൽക്കൂര പാനലുകൾ
• Powder-Coated Steel Frame Components (various lengths and shapes)
• Reinforcing Support Rods
• Heavy-Duty Anchor Rods / Fixed Anchor Kits
• Waterproof Sealing Tape
• Fasteners (screws, bolts, nuts)
• Anti-Scratch Iron Strips / Corners

4. അസംബ്ലി നിർദ്ദേശങ്ങൾ

Follow these step-by-step instructions carefully. Refer to the included diagrams and the official installation video for visual guidance.

ഔദ്യോഗിക ഇൻസ്റ്റലേഷൻ വീഡിയോ

ഘട്ടം ഘട്ടമായുള്ള അസംബ്ലി

1. അടിസ്ഥാന ഫ്രെയിം കൂട്ടിച്ചേർക്കുക: Connect the bottom steel pipes using the provided fasteners. Ensure all connections are secure. The reinforced base design helps the carport withstand high winds.


   Image: Close-up of the reinforced base design, showing anchor points for enhanced stability.

2. മേൽക്കൂര ഫ്രെയിം നിർമ്മിക്കുക: Assemble the curved roof frame sections and connect them to the vertical posts. Use the designated bolts and nuts for each connection point. The frame is made of heavy-duty, corrosion-resistant steel.


   Image: Illustration highlighting the 40% thicker, heavy-duty sturdy steel frame components.

3. മേൽക്കൂര പാനലുകൾ സ്ഥാപിക്കുക: Carefully place the galvanized steel roof panels onto the assembled frame. Ensure proper overlap for water drainage. Secure the panels using the provided screws. Apply waterproof sealing tape along the roof seams to prevent leaks.


   Image: Close-up of the anti-leak design metal roof with a visible seam, demonstrating water resistance.


   ചിത്രം: View of the sloped roof design, emphasizing the high-density weatherstrip tape for enhanced waterproofing.

4. പിന്തുണ ബ്രാക്കറ്റുകൾ ഘടിപ്പിക്കുക: Install the unique detachable support brackets to the base frame. These brackets allow for firm installation on various surfaces like mud, cement, wood, or sand, ensuring stability in diverse weather conditions.


   Image: Diagram illustrating the four unique detachable support brackets designed for versatile installation.

5. Secure Anti-Scratch Strips: Install the anti-scratch iron strips and corners along the edges of the roof panels. These strips help protect the material and users from sharp edges.
6. Final Anchoring: Utilize the heavy-duty anchor rods or fixed anchor kits to firmly secure the carport to the ground. Proper anchoring is essential for stability and safety, especially in windy conditions.

Image: Simplified diagram showing the three main steps of easy assembly: assemble roof frame, place roof cover, and install reinforcing support rods.

5. ഉപയോഗം

The GAOMON Metal Carport provides a versatile and spacious shelter for various needs:

• വാഹന സംരക്ഷണം: Ideal for parking SUVs, trucks, boats, and other vehicles, protecting them from sun, rain, snow, and other weather elements.
• Outdoor Shelter: Can be used as a canopy for outdoor gatherings, parties, weddings, trade shows, or as a shaded workspace.

Image: A GAOMON Metal Carport providing shelter for a truck during a rainy day, showcasing its weather resistance.

Image: A GAOMON Metal Carport sheltering a tractor in snowy conditions, demonstrating its ability to withstand winter weather.

Image: Visual representation of the carport's resilience across various weather conditions including snow, rain, wind, and sun.

6. പരിപാലനം

To ensure the longevity and continued performance of your GAOMON Metal Carport, regular maintenance is recommended:

• പതിവ് പരിശോധന: Periodically check all bolts, screws, and connections to ensure they remain tight and secure. Tighten any loose fasteners immediately.
• ശുചിത്വം: Keep the roof panels free from excessive debris, leaves, or snow accumulation. While the roof is designed for snow load, heavy, wet snow should be removed to prevent undue stress.
• തുരുമ്പ് തടയൽ: The galvanized steel roof is rust-proof, and the powder-coated frame is corrosion-resistant. However, inspect for any scratches or chips in the coating and touch up with appropriate paint to prevent rust.
• വാട്ടർപ്രൂഫിംഗ്: Verify that the waterproof sealing tape on the roof seams remains intact. Replace or reapply if any signs of wear or leakage are observed.
• Rubber Strip Integrity: Check the soft-edged rubber strip around the roof edge for damage or displacement. This strip helps prevent cuts and extends material lifespan.

7. പ്രശ്‌നപരിഹാരം

നിങ്ങളുടെ കാർപോർട്ടിൽ നിങ്ങൾ നേരിട്ടേക്കാവുന്ന പൊതുവായ പ്രശ്നങ്ങളെ ഈ വിഭാഗം അഭിസംബോധന ചെയ്യുന്നു.

• Issue: Carport feels unstable or wobbly.
  • പരിഹാരം: Ensure all frame connections are securely tightened. Verify that the carport is installed on a level surface. Re-check and reinforce all anchor points to the ground. Consider using additional anchoring methods if in a high-wind area.
• പ്രശ്നം: മേൽക്കൂരയിൽ നിന്ന് വെള്ളം ചോർന്നൊലിക്കുന്നു.
  • പരിഹാരം: Inspect the roof panels for proper overlap and ensure all screws are tight. Check the waterproof sealing tape along the seams; reapply or replace if it is damaged or has deteriorated.
• Issue: Difficulty aligning frame components during assembly.
  • പരിഹാരം: Double-check that you are using the correct parts for each step as indicated in the manual. Loosen adjacent connections slightly to allow for more flexibility, then tighten them once the problematic connection is made. Ensure the ground is as level as possible.

8 സ്പെസിഫിക്കേഷനുകൾ

9. വാറൻ്റിയും പിന്തുണയും

For warranty information, technical support, or to inquire about replacement parts, please contact GAOMON customer service directly. Refer to your purchase documentation for specific contact details or visit the official GAOMON webസൈറ്റ്.
